Pagina 1/10
PDM4.0 EI Setup
PA28091A01
Rev. 02 2- 7 201
PAT 4.0 AUTOMATIC CABLE TIE INSTALLATION SYSTEM
ELECTRONIC INTERFACE USER MANUAL
© Panduit Corp. 2017
Original Instructions
EI (Electronic Interface) Instructions
For use with the following Systems &
respective Operational Manuals:
PAT 4.0 FAMILY TOOLS: Automatic Cable Tie Installation Tools
PDM4.0: Dispenser
PHM: Feeder Hoses
Operation Manual (PA27647A01)
PDM4.0 Data Manager Operations Manual (PA25060 ) A01
EI I/O port (25 is internally connected Pin Connector)
to Optically Isolated Modules,
WARNING
• TO REDUCE THE RISK OF INJURY,
USER MUST READ INSTRUCTION
MANUAL
Email:
techsupport@panduit.com
EU Website:
www.panduit.com/emea
EU Email: emeatoolservicecenter
@panduit.com
www.panduit.com
Panduit Corp. • Tinley Park, IL USA
Technical Support
Tel: 1- - - 800 777 3300
Panduit Europe • EMEA Service Center
Almelo, Netherlands
Tel: +31 546 580 452 • Fax: +31 546 580 441
PAT 4.0 AUTOMATIC CABLE TIE INSTALLATION SYSTEM
ELECTRONIC INTERFACE USER MANUAL
© Panduit Corp. 2017
PA28091A01_02 Page of 017 1 9 2-2
1: INTRODUCTION
The PAT Fully Automatic Cable Tie Installation System was designed by Panduit Corporation to install
Panduit continuously molded cable ties for high volume wire harnessing applications.
NOTE: In the interest of higher quality and valu products are e, Panduit
continually being improved and updated.
Consequently, pictures may vary from the enclosed product.
2: SYSTEM SPECIFICATIONS
The Panduit Corporation PAT Cable Tie Installation System consists of four compatible units: the PAT
Ins Panduittallation Tool, the PDM Dispenser, the PHM Feeder Hose, and - Pan Ty XMR Cable Ties.
Cable ties are available in reels of 5000 pcs.
NOTE: Any substitution may cause damage to the system and/or injury to the operator.serious
SYMBOL EXPLANATION
Warning: Hazardous Voltage
Disconnect power before servicing
Warning: Head Obstruction
Warning: Sever Hand
Warning: Wear Safety Glasses
Caution: Air Inlet
WEEE Compliance
Read the Manual
VAC
FUSE
PAT 4.0 AUTOMATIC CABLE TIE INSTALLATION SYSTEM
ELECTRONIC INTERFACE USER MANUAL
© Panduit Corp. 2017
PA28091A01_02 Page of 017 2 9 2-2
Automatic Cable Tie Tool & Tool CycleSystem Overview :
( Applies to all Panduit Automatic Cable Tie Tool Systems, Listed on Page 1)
Tool Cycle with Customer Controlled Tool Actuator / Robot
& Use of EI- : Port
1. Head Customer Controlled Actuator closes Tool Jaw lever, closing Jaw & S1 switch, to enable -EI
Port to receive remote trigger input at 5 pin D sub. Connector. EI 2 -
{NOTE: Customer Actuator must hold Tool Jaw Lever closed during entire cycle for proper Cable
Tie Application}
2. Short “primary” air burst sends tie past “Gate” and Tie Exit Sensor, , andDispenser Dispenser S2 into
Tie Transfer Hose, then “primary” air burst stops.
3. Dispenser “Gate” in closes and second air burst transports tie through Tie Transfer Hose toward
Tool Head.
4. Tie enters Tool Head, passing through Tie En , stopping in jaws of Tool Head, and try Sensor, S3
Dispenser moves the next tie into position ready for next cycle.
5. Upper Jaw moves to thread tie strap through tie head, then tensioning around wire bundle takes
place.
6. Tie reaches desired tension and excess tie strap is cut-off, activating Detent Sensor to end S4
cycle.
