Pagina 1/12
1
MyQ® CONTROL PANEL
MODEL 888LM
To prevent possible SERIOUS INJURY or DEATH from electrocution:
• Be sure power is NOT connected BEFORE installing door control.
• Connect ONLY to 7-28 VOLT low voltage wires.
To prevent possible SERIOUS INJURY or DEATH from a closing
garage door:
• Install door control within sight of garage door, out of reach of
children at a minimum height of 5 feet (1.5 m), and away from ALL
moving parts of door.
• NEVER permit children to operate or play with door control push
buttons or remote control transmitters.
• Activate door ONLY when it can be seen clearly, is properly
adjusted, and there are no obstructions to door travel.
• ALWAYS keep garage door in sight until completely closed. NEVER
permit anyone to cross path of closing garage door.
• DO NOT install this door control on garage door opener systems
controlling one-piece or swing doors.
To provide an adequate visual alert, the garage door opener light
bulb(s) MUST be a minimum of 40 Watt (or equivalent).
The MyQ® Control Panel is intended to be installed with Security+™
Garage Door Openers manufactured between 1998 and present. The
MyQ® Control Panel is NOT compatible with Security+ 2.0™ Garage Door
Openers. DO NOT install this door control on garage door opener
systems controlling one-piece or swing doors.
APPLICATION
The MyQ® Control Panel offers a quick and convenient way to add
Security+ 2.0™ and MyQ® technology to your existing garage door
opener. MyQ® technology uses a 900MHz signal to provide two-way
communication between the garage door opener and MyQ
® enabled
accessories. When programmed to the Liftmaster
® Internet Gateway you
can monitor and control your garage door from any internet enabled
computer or smartphone. You may program up to 12 Security+ 2.0™
remote controls, 2 Security+ 2.0™ keyless entries and a combination of
16 MyQ® accessories to the MyQ® control panel.
COMPATIBLE ACCESSORIES
Security+ 2.0™ Accessories: MyQ® Accessories:
Model 891LM
1- Button Remote Control
Model 823LM
Remote Light Switch
Model 893LM
3-Button Remote Control
Model 825LM
Remote Light Control
Model 890MAX
3-Button Mini MAX Remote Control
Model 828LM
LiftMaster® Internet Gateway
Model 893MAX
3-Button MAX Remote Control
Model 829LM
Garage Door and Gate Monitor
Model 895MAX
3-Button Premium MAX Remote
Control
Model 877LM
Wireless Keyless Entry
Model 877MAX
Wireless MAX Keyless Entry
OVERVIEW
Install the MyQ® Control Panel in place of the existing door control. Due
to power consumption the MyQ® Control Panel cannot be used in
conjunction with another wired door control connected to your garage
door opener. If an additional door control is needed, the wireless door
control model 885LM can be programmed to the MyQ
® Control Panel.
To program the 885LM to the MyQ® Control Panel, follow the remote
control programming steps. When in battery back-up mode, any feature
using unattended operation such as Timer-to-Close, closure from a
garage door and gate monitor or remote operation utilizing the
LiftMaster® Internet Gateway will be disabled.
1. Disconnect all electrical and battery power (if applicable) to the
garage door opener.
2. Remove the existing door control from the wall.
3. Note the polarity of the wires connected to the existing door
control.
• Label the wire connected to the RED terminal.
• Label the wire connected to the WHITE terminal.
Disconnect the wires from the existing door control.
INSTALLATION Existing Door Control
Discard, donate
or recycle
Wire from
RED terminal
Connect
RED wire to
R terminal
Wire from
WHITE
terminal
Connect
WHITE
wire to W
terminal
MyQ® Control Panel
4. Connect the wires to the new MyQ
® Control Panel. Make sure the
polarity is correct.
• Red wire to the R terminal.
• White wire to the W terminal.
5. Mount the MyQ® Control Panel to the wall.
6. Reconnect power. The yellow command LED and the red learn LED
will blink quickly for up to 5 minutes as the control panel
recharges. When the control panel is operational, the yellow
command LED will glow steadily.
7. To test the control panel, press the push bar to activate the garage
door opener.
WARNING: This product can expose you to chemicals including
lead, which are known to the State of California to cause cancer or
birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
2
PIN
? ? ? ?
PROGRAMMING
REMOTE CONTROL 1. Press the MyQ® Control Panel LEARN
button twice, the red learn LED will turn
on.
2. Press the button on the remote control
that you wish to operate your garage
door.
3. The garage door opener lights will flash
(or two clicks will be heard) when the
code has been programmed.
1. Press the MyQ® Control Panel LEARN button twice, the red learn
LED will turn on.
2. Enter a 4-digit personal identification number (PIN) of your choice
on the keyless entry keypad. Then press the ENTER button.
3. The garage door opener lights will flash (or two clicks will be heard)
when the code has been programmed.
KEYLESS ENTRY
LEARN
Button
LEARN
Button
Model 825LM - Remote Light Control
Light module can be synchronized with the
garage door opener light bulbs.
Model 823LM - Remote Light Switch
Light module can be synchronized with
the garage door opener light bulbs.
LEARN
Button
Model 829LM - Garage Door and Gate Monitor
Indicates the status of your garage door from inside
the home and allows you to close an open garage door
from inside the house.
MyQ® ENABLED
ACCESSORIES
1. Press the MyQ® Control Panel LEARN
button twice, the red learn LED will
turn on.
2. Press the LEARN button on the MyQ®
device.*
* MyQ® accessories may be programmed to the
LiftMaster® Internet Gateway (Model 828LM)
or the MyQ® control panel. For instructions on
programming to the internet gateway refer to
the manual.
INTERNET GATEWAY
The LiftMaster® Internet Gateway gives you control of your garage door
from your internet connected computer or mobile device. You must have
your internet gateway registered to your customer account at
myliftmaster.com in order to use it with the MyQ
® Control Panel. Go to
myliftmaster.com and follow the instructions to create an account and
register your device if you have not already.
To program your control panel to the LiftMaster®
Internet Gateway:
1. Go to myliftmaster.com from a computer or mobile device.
2. Click on “Manage Places>Add New Device>Garage Door Opener”
and follow the directions.
3. Once you click ADD you have 3 minutes to press the LEARN button
two times on the MyQ® control panel. The red learn LED will turn
on.
4. The red learn LED will turn off when programming is complete.
Once the control panel is learned, it will appear on your screen. You
can then name the device (e.g., My Control Panel, etc.).
Model 828LM
LiftMaster® Internet Gateway
myliftmaster.com
Command
LED (yellow)
Learn
LED
(Red)
3
PUSH BAR
Press the push bar to open/close the door.
LIGHTS
Press the LIGHT button to turn the garage door opener lights on or off.
When the lights are turned on they will stay on until the LIGHT button is
pressed again, or until the garage door opener is activated. Once the
garage door opener is activated the lights will turn off after the specified
period of time (the factory setting is 4-1/2 minutes). The LIGHT button
will not control the lights when the door is in motion.
To change the amount of time the garage door opener lights will stay on:
Press and hold the LOCK button until the garage door opener lights flash.
The time interval is indicated by the number of flashes.
Light Feature
The lights will turn on when someone enters through the open garage
door and the safety reversing sensor infrared beam is broken.
Activate:
Start with the garage door opener lights on. Press and hold the LIGHT
button until the garage door opener lights turn off, then on again.*
Deactivate:
Press and hold the LIGHT button until the garage door opener lights
turn on, then off again.*
* Approximately 10 seconds
FUNCTIONS
NUMBER OF TIMES GARAGE
DOOR OPENER LIGHTS FLASH 1 2 3 4
TIME THE GARAGE DOOR
OPENER LIGHT STAYS ON 1 ½
Minutes 2 ½
Minutes 3 ½
Minutes 4 ½
Minutes
MOTION SENSOR
This feature will automatically turn on the garage door opener lights when
motion is sensed. The lights will come on for the set period of time, then
shut off.
Activate/Deactivate:
Slide the motion sensor switch ON or OFF.
TIMER-TO-CLOSE (TTC)
NOTE: DO NOT install this door control on garage door opener systems
controlling one-piece or swing doors.
The TTC feature automatically closes the door after a specified time
period (1, 5, or 10 minutes). Once the TTC has been set and the door is
open, the LED for the selected close interval will blink and begin to count
down to close the door. The control panel will beep and the garage door
opener lights will flash before closing the door.
The TTC feature will deactivate if the garage door encounters an
obstruction twice; or the safety reversing sensors are incorrectly installed.
The garage door will reverse open and WILL NOT close until the
obstructions are clear or the safety reversing sensors are correctly
installed. When the obstruction has been cleared or the safety reversing
sensors have been aligned, the door will close when the garage door
opener is activated.
Activate:
Press and hold the ON button until one of the TTC LEDs light up. Then
press the ON button again to cycle through the time interval options
(the corresponding TTC LED will light for each time interval). The
garage door opener light bulbs will blink as confirmation.
Deactivate:
Press and hold the OFF button until all TTC LEDs turn off and a beep is
heard from the control panel.
Temporarily hold door open (suspend TTC):
Press and release the HOLD OPEN button. The HOLD OPEN button will
begin to flash. Press the HOLD OPEN button again to resume normal
TTC operation.
LOCK
Activate*:
Press and hold the LOCK button for 2 seconds. The command LED will
flash as long as the lock feature is activated and your handheld remote
control will not operate your door at this time.
Deactivate:
Press and hold the LOCK button again for 2 seconds. The command
LED will stop flashing and normal operation will resume.
* Your LiftMaster® keypad will continue to work when the LOCK has been
activated.
LIGHT
Button
1 Minute
TTC LED
5 Minute
TTC LED
10 Minute
TTC LED
ON Button
Command
LED (yellow)
OFF Button
HOLD OPEN
Button
Motion
Sensor
LEARN
button
Learn LED
(Red)
LOCK
button
Push Bar

Product specificaties

Merk: Liftmaster
Categorie: Niet gecategoriseerd
Model: 888LM

Heb je hulp nodig?

Als je hulp nodig hebt met Liftmaster 888LM stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Niet gecategoriseerd Liftmaster

Liftmaster

Liftmaster CAPXLV2MC Handleiding

5 Augustus 2024
Liftmaster

Liftmaster BG770 Handleiding

8 Juli 2024
Liftmaster

Liftmaster LMHNTG Handleiding

8 Juli 2024
Liftmaster

Liftmaster SL585 Handleiding

11 Juni 2024
Liftmaster

Liftmaster SL590 Handleiding

11 Juni 2024
Liftmaster

Liftmaster BG3000 Handleiding

11 Juni 2024
Liftmaster

Liftmaster CAPXSTKPL Handleiding

9 Juni 2024
Liftmaster

Liftmaster BG790 Handleiding

9 Juni 2024
Liftmaster

Liftmaster 64LM Handleiding

27 Mei 2024
Liftmaster

Liftmaster CAPXSHOOD Handleiding

8 December 2023

Handleiding Niet gecategoriseerd

Nieuwste handleidingen voor Niet gecategoriseerd

Protector

Protector AS-5030.3 V2 Handleiding

21 December 2024
Sabrent

Sabrent AU-MMCW Handleiding

21 December 2024
Sabrent

Sabrent AU-2X35 Handleiding

21 December 2024
Sabrent

Sabrent CB-RS232 Handleiding

21 December 2024
Owon

Owon 500W Handleiding

21 December 2024
Owon

Owon 300W Handleiding

21 December 2024
Sabrent

Sabrent SB-RKTQ4-1TB Handleiding

21 December 2024
Sabrent

Sabrent SB-RKTQ-1TB Handleiding

21 December 2024
Sabrent

Sabrent SB-ROCKET-1TB Handleiding

21 December 2024
Sabrent

Sabrent SB-HTSS Handleiding

21 December 2024
