Pagina 1/32

Full HD LED touchscreen monitor

QUICK SETUP GUIDE

PROFESSIONAL e-Screen 65" ETD

E N G L I S H

D E U T S C H

F R A N Ç A I S

NEDERLANDS

T ü R k Ç E

For further information, see the User

Manual that is downloadable from the

e-legamaster.com website. Please retain

this Quick setup guide for future reference.

Please contact Legamaster directly if you

have questions on the use of the touch

monitor after reading the Setup Guide

and User Manual.

Important:

Please read the PRECAUTIONS, SAFETY

INSTRUCTIONS and this SETUP GUIDE

carefully before installing the touch

monitor.

Before using the touch monitor, please read this quick setup

guide thoroughly to help protect against damage to your own

and other people's property and ensure your own and other

people's personal safety.

Be sure to observe the following instructions.

For your safety, be sure to observe the warnings contained

in this guide.

For installation or adjustment, please follow this quick setup

guide and refer all servicing to qualiﬁed service personnel.

Safety Precautions

If smoke or a peculiar smell comes from the monitor, remove the

power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If the monitor has been turned on but there isn’t a picture,

remove the power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If water is spilled or objects are dropped inside the monitor,

remove the power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If the monitor is dropped or the cabinet is damaged, remove the

power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

To turn off the power of the monitor, press ” ” on the main

power switch at side of monitor.

The power standby/on indicator will go off and the monitor

cannot to be turned on/off by using the POWER button on the

remote control. (To turn on/off the monitor by the remote control,

press the main power switch again and the power standby/on

indicator light will come on again.)

When turning off the monitor by pressing the POWER button

on the remote control, the main power of the monitor is not

turned off completely.

To disconnect the monitor completely from the power supply,

remove the plug from the socket.

Press “ ” to turn off

the monitor completely

If the power cord or plug is damaged or becomes hot, turn off the

main power switch of the monitor, make sure the plug has cooled

down and remove the plug from the socket.

If the monitor is still used in this condition, it may cause a ﬁre or

an electric shock. Contact your dealer for replacement.

Moving and Carrying Notice

Moving Notice:

Moving the monitor requires at least two people. If not, it may drop and a serious

injury may result. When moving/shipping the monitor, please hold the white handles.

Carrying Notice:

This monitor is heavy; please follow the instructions below when you are ready to

carry the monitor. Failure to do so may cause injury.

Installation

(when installing the monitor, please follow the instructions in this

quick setup guide)

Don't install in a high-temperature environment.

If the monitor is used in a high-temperature environment or in

direct sunlight, it may cause the case or other parts to become

distorted or damaged resulting in overheating or electric shock.

Don't install in a high-humidity environment.

This may cause overheating or electric shock.

Don't install near any heat sources such as radiators, hot-air

outlets, stoves, or other apparatus that produce heat.

This may cause a ﬁre or electric shock.

Don't overload sockets or cables beyond electrical capacity.

Don't use extension leads as this may cause a ﬁre or electric shock.

Don't insert the power plug into an socket other than 100~240V AC.

This may cause a ﬁre or electric shock.

Don’t use a damaged power plug or worn socket.

Don't insert the wrong plug as it may cause a ﬁre or electric

shock.

QUICK SETUP GUIDE

1 Precautions and safety instructions

Do not place monitors on unstable shelves or surfaces. They could

collapse and cause damage.

Only install the unit on vertical, stable and level surfaces.

Don't place objects on the touch monitor.

If the touch monitor is covered or the vents are blocked, the

monitor could overheat and cause a ﬁre.

If metal or liquid gets into the monitor, it may cause a ﬁre

or an electric shock.

Do not place heavy objects on the monitor as they may fall

causing injury.

Please keep a minimum distance of 10 cm between the monitor

and the other objects for sufﬁcient ventilation.

Don't move the touch monitor when it is connected to the power

cord and AV cables.

When moving the monitor, make sure you remove the plug

and cables from the socket or source.

When unpacking or carrying the monitor, at least 2 people

are needed. Make sure the monitor is carried upright.

Transport the monitor upright. Avoid placing the monitor

face up or face down.

Handle the monitor gently. Do not drop.

Wall mounting safety notes

1. Please make sure the bracket is ﬁxed to a solid wall.

2. After assembling, please don't pull or shake violently.

3. Please don't install the bracket in direct sunslight or areas

of humidity / high temperature for fear that the quality

is affected.

4. Install the bracket at a minimum distance of 10 cm from other

objects / walls on either side. Only attach to vertical walls.

Unpacking

The e-Screen is packed in a cardboard box and may be banded

to 2 types of custom pallet depending on the number of units

shipped. The e-Screen is packed using cushions to protect

the monitor during shipping.

Before unpacking your monitor, prepare a stable, level, and

clean surface near a wall socket.

Set the LCD Monitor box in an upright position and open

from the top of the box before removing the top cushions.

Step 1: Remove the white handle and cut the banding.

Step 2: Remove the top cushion and take

the accessories bag out.

Packing list

Item Q’ty

1 e-Screen 1

2 Carton 1

3 Bottom cushion 1

4 Top cushion 1

5 Packing bag 1

6 Accessories bag 1

7 Ergonomic stylus 1 set

8 Carton lock 6

Contents of the Accessories Bag

- VGA Cable (D-sub)

- Power cord black

- OSD Remote control (2 batteries (AAA) included)

- USB cable

- IR-Extender

- CD-Disk Ethernet VCOM driver

2 Package contents

Product specificaties

Merk:	Legamaster
Categorie:	Monitor
Model:	7-194115
Kleur van het product:	Wit
Beeldschermdiagonaal:	65 "
Resolutie:	1920 x 1080 Pixels
Touchscreen:	Ja
Kijkhoek, horizontaal:	178 °
Kijkhoek, verticaal:	178 °
Beeldscherm vorm:	Flat
Typische contrastverhouding:	4000:1
Helderheid:	360 cd/m²
Touch screen type:	Tafelblad
LED backlight:	Ja
Frequentiebereik horizontaal:	23 - 92 kHz
Frequentiebereik verticaal:	49 - 86 Hz
Aantal USB 2.0-poorten:	1
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	2
Componentingang video (YPbPr/YCbCr):	1
S-Video ingang:	1
DVI-poort:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	20 W
Stroomverbruik (in standby):	1 W
Aantal luidsprekers:	2
Beeldscherm, aantal kleuren:	1.073 biljoen kleuren
Volledige HD:	Ja
HD type:	Full HD
RS-232 port:	1
3D:	Nee
Audio-uitgang:	1
HDMI:	Ja
Display technologie:	LED
Responstijd:	5.5 ms
Paneelmontage-interface:	400 x 400,600 x 400 mm
Picture-in-Picture:	Ja
DVI-D poorten:	1
Beeldverhouding:	16:9
Digitale horizontale frequentie:	15 - 94 kHz
Digitale verticale frequentie:	23 - 85 Hz
Diepte ( zonder voet ):	113 mm
Hoogte (zonder voet ):	909.8 mm
Breedte ( zonder voet ):	1539.8 mm
Gewicht (zonder voet):	70000 g
Plug and play:	Ja
Aantal DisplayPorts:	1
Schermdiameter in centimeters:	165.1 cm
AMD FreeSync:	Nee
NVIDIA G-SYNC:	Nee
On Screen Display (OSD):	Ja
Soort voeding:	AC
Temperatuur bij opslag:	-20 - 60 °C
Compatibele besturingssystemen:	Windows XP/Vista/7\r\nMac OS X \r\nLinux
Luchtvochtigheid bij opslag:	0 - 85 procent
AV-ingang:	Ja
Soort aansluiting:	USB
Ophangsysteem voor aan de muur:	Ja
Afmetingen (B x D x H):	1539.8 x 113 x 909.8 mm
Afstandsbediening inbegrepen:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	226 W
Bedrijfstemperatuur (T-T):	0 - 35 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 85 procent
Aantal producten inbegrepen:	1 stuk(s)
