Pagina 1/27
P/N: 2900-301206 Rev 2 www.kramerAV.com
USER MANUAL
MODEL:
WP-789T, WP-789R, TP-789R, TP-789Rxr
HDMI Line Transmitters and Receivers over
HDBaseT
Kramer Electronics Ltd.
WP-789T, WP-789R, TP-789R, TP-789Rxr Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Dening WP-789T, WP-789R, TP-789R, TP-789Rxr HDMI Line Transmitters and Receivers over HDBaseT 4
Mounting 7
Mounting TP-789R, TP-789Rxr 7
Mounting WP-789T 8
Mounting WP-789R 9
Connecting WP-789T, WP-789R, TP-789R, TP-789Rxr 11
Connecting WP-789T to TP-789R/TP-789Rxr 11
Connecting WP-789R to TP- 780T 12
Connecting TP-789R/TP-789Rxr to WP- 20 13
Connecting TP-789R/TP-789Rxr as PoE Acceptor 14
Connecting to Device via RS- 232 16
Grounding WP-789T, WP-789R (Optional) 16
Connecting to WP-789T, WP-789R IR Terminal Block 17
Conguring WP-789T, WP-789R, TP-789R, TP-789Rxr 19
Setting DIP-Switches 19
Setting IR Frequency 20
Setting HDBaseT Range Mode for TP- 9Rxr 78 20
Upgrading Firmware 20
Technical Specications 21
WP-789T Technical Specications 21
WP-789R Technical Specications 22
TP-789R/TP-789Rxr Technical Specications 23
Kramer Electronics Ltd.
WP-789T, WP-789R, TP-789R, TP-789Rxr Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/TP-789Rxr to check for up-to-date user manuals,
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
not secure the cables in tight bundles or roll the slack into tight coils. Do
Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
Position your Kramer WP-789T, WP-789R, TP-789R, TP-789Rxr away from moisture,
excessive sunlight and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
To ensure continuous risk protection, replace fuses only according to the rating
specied on the product label which located on the bottom of the unit.
