SPECIFICATIONS

4022i 5022i 6022i 6022si 6522i 6522si

Type: 4" 2-Way 5-1/4" 2-Way 6-1/2" 2-Way 6-1/2" Shallow- 165mm 2-Way 165mm Shallow-

Mount 2-Way Mount 2-Way

Nominal Impedance: 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms

Power Handling, RMS: 35W 45W 60W 50W 60W 50W

Power Handling, Peak: 105W 135W 180W 150W 180W 150W

Frequency Response: 85Hz – 21kHz 67Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz 58Hz – 21kHz 58Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB 93dB 93dB 93dB 93dB

9622i 9623i 8023i 3022cf 6422cf 6422cfp 6822cf

Type: 6" x 9" 2-Way 6" x 9" 3-Way 8" 3-Way 3-1/2" 2-Way 4" x 6" 2-Way 4" x 6" 2-Way 6" x 8"/5" x 7"

Custom Fit Custom Fit Custom Fit Plate 2-Way Custom Fit

Nominal Impedance: 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms 2.65 Ohms

Power Handling, RMS: 100W 100W 75W 25W 40W 45W 60W

Power Handling, Peak: 300W 300W 225W 75W 120W 135W 180W

Frequency Response: 46Hz – 21kHz 46Hz – 21kHz 49Hz – 21kHz 85Hz – 21kHz 72Hz – 21kHz 72Hz – 21kHz 49Hz – 21kHz

Sensitivity (2.83V, 1m): 94dB 94dB 94dB 91dB 91dB 91dB 93dB

GENERAL CARE: The loudspeak er grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.

WARRANTY: Reference Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local Infinity

car audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.infinitysystems.com.
