Infinity Reference 6032CF Handleiding
Infinity
Autospeaker
Reference 6032CF
Lees hieronder de 📖 handleiding in het Nederlandse voor Infinity Reference 6032CF (2 pagina's) in de categorie Autospeaker. Deze handleiding was nuttig voor 8 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/2
4-1/4"
110mm
6-1/4"
159mm
3-9/16"
90mm
5"
127mm
2-1/16"
52mm
3/4"
19mm
1-3/4"
44mm
4-1/4"
110mm
6-1/4"
159mm
3-3/16"
80mm
5"
127mm
1-15/16"
49mm
7/16"
11mm
1-3/4"
44mm
6032i/6032cf 6032si
R E F E R E N C E
6032i
6032cf
6032si
6032gr
Declaration of Conformity
We, Harman International, Consumer Division
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 1/09
6032i 6032cf 6032si
BL (T-m) 4.00 4.00 4.30
DCR (ohms) 2.30 2.30 2.30
Mms (g) 12.98 12.98 12.69
Sd (sq cm) 132.7 132.7 132.7
Cms (μm/N) 277 277 221
Vas (l) 6.85 6.85 5.47
Fs (Hz) 83.9 83.9 95.0
Qes 0.98 0.98 0.94
Qms 6.16 6.16 7.89
Qt 0.85 0.85 0.84
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage. Un numéro de série valable est exigé pour la couverture de la garantie.
Features, specifications and appearance are subject to change without notice.
Les dispositifs, les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division, 8500 Balboa Blvd., Northridge, CA 91329 USA
www.infinitysystems.com
¥(ARMAN)NTERNATIONAL)NDUSTRIES)NCORPORATED!LLRIGHTSRESERVED4OUSDROITSRÏSERVÏSs0ART.O2%&/-
Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries, Incorporated, déposée aux États-Unis et/ou dans d’autres pays.
2x
6032gr
1x
2x2x 2x 2x
6032i/6032si
6032i/6032cf/6032si 6032i/6032cf
1x
6032cf
2x2x 2x
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
Product specificaties
| Merk: | Infinity |
| Categorie: | Autospeaker |
| Model: | Reference 6032CF |
Heb je hulp nodig?
Als je hulp nodig hebt met Infinity Reference 6032CF stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Autospeaker Infinity
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
26 November 2024
Handleiding Autospeaker
- Autospeaker Philips
- Autospeaker Sony
- Autospeaker JVC
- Autospeaker JBL
- Autospeaker Kenwood
- Autospeaker Pioneer
- Autospeaker Alpine
- Autospeaker Auna
- Autospeaker Autotek
- Autospeaker Axton
- Autospeaker Blaupunkt
- Autospeaker Boss
- Autospeaker DLS
- Autospeaker Dnt
- Autospeaker Emphaser
- Autospeaker ESX
- Autospeaker Focal
- Autospeaker Fusion
- Autospeaker Hertz
- Autospeaker Hifonics
- Autospeaker Ices
- Autospeaker Kicker
- Autospeaker Lanzar
- Autospeaker Mac Audio
- Autospeaker Magnat
- Autospeaker Marquant
- Autospeaker Mr Handsfree
- Autospeaker Mtx Audio
- Autospeaker Pyle
- Autospeaker Renegade
- Autospeaker Renkforce
- Autospeaker Rockford Fosgate
- Autospeaker Soundstream
- Autospeaker JL Audio
- Autospeaker Clatronic
- Autospeaker Caliber
- Autospeaker Exibel
- Autospeaker Clarion
- Autospeaker Crunch
- Autospeaker Metra
- Autospeaker AudioControl
- Autospeaker Deaf Bonce
- Autospeaker Aquatic AV
- Autospeaker Planet Audio
- Autospeaker SoundMAX
- Autospeaker Memphis Audio
- Autospeaker Sinustec
- Autospeaker Sinus Live
- Autospeaker Audiotec Fischer
Nieuwste handleidingen voor Autospeaker
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
25 November 2024
