User Manual

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button and indicator light

3. TEMPERATURE button

4. DISPLAY

5. buttonCHILD LOCK

6. OPTION button

7. button DELAYED START

8. SPIN button

9. WASH CYCLE SELECTOR KNOB

10. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

2 3 5

678

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** The display will show the suggested spin speed as default value.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected. The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60

Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.

The most ecient programme in terms of energy and water consumption for washing

normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the

table.

For all testing institutes:

2) Long cotton cycle: set cycle 6 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, insert the partition

into slot .B

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the “max”

level indicated on the central pin.

! The detergent drawer is suitable only for Liquid

and Powder detergent. No Capsule Detergent allowed.

TheCapsule Detergent have to be placed into the drum before the load.

Make sure to use the correct Capsule Detergent dosage amount

recommended by Manufacturer.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever and pull the drawer outwards.C

Maximum load 7 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(***)

Energy con-

sumption kWh

Total water l

Laundry

temperature °C

Wash cycle Temperature Maxim spin

(r.p.m.)

Max.

load

(kg)

Duration

(h : m)

Wash Fabric

softener

Powder

Liquid

Capsule

(4)

Setting Range 2 3

1 Cotton 40°C 1000 7 ** – 40°C   –  – – – –

2 Shirt 40°C 600 2 ** – 40°C   –  – – – –

3ARIEL PODS 30°C 30°C 1000 4.5 ** – – – – – – –

4 Wool 40°C – 40°C 800 1.5 **   –– – – – –

5 20°C 20°C – 20°C 1400 7 1:50   –– 52 0.160 64 22

6 Cotton (2) 40°C – 60°C 1400 7 3:40     50 450.980 75

7 Synthetics (3) 40°C – 60°C 1200 4 2:55      35 0.860 60 43

8 Mixed 40°C – 40°C 1400 7 **   –  – – – –

9Eco 40-60 (1) 40 °C 40°C

1351 7 3:25      53 0.635 54 34

1351 3.5 2:40      53 0.445 44 32

1351 2 2:25      53 0.187 35 23

10 White 60°C – 90°C 1400 7 2:30      52 1.360 75 55

11 Rapid 20min 20°C 800 1.5 ** – 20°C   –– – – – –

11 Rapid 40°C – 40°C 1200 3.5 **   –– – – – –

11 Rapid 60°C – 60°C 1000 7 **      – – – –

12 Rapid 45min Full Load 40°C - 40°C 1200 7 **   –– – – – –

13 Duvet 30°C – 30°C 1000 3 **   –  – – – –

14 Delicates 30°C 30°C – 30°C 600 (****) 1 **   –– – – – –

Rinse + Spin – – 1400 7 ** – – – – – – – –

Spin + Drain * – – 1400 7 ** – – – – – – – – –

 Required dosage - Optional dosage - 4) Minimum 30°C recommended for usage of Capsule detergent.

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Cotton

Cycle designed to wash cotton garments. During the last phase of the

cycle garments will be treated with steam, that will relax the bres.

Shirt

Use the special wash cycle to wash shirts in dierent fabrics and colours

to guarantee they receive the best possible care. During the last phase of

the cycle garments will be treated with steam, that will relax the bres.

ARIEL PODS

A 30°C short cycle designed to wash a mixed load of cotton and

synthetics fabrics, recommended for the use of PODS detergent.

Wool - Wool Care

The wool wash cycle of this machine has been approved by

The Woolmark Company for the washing of machine washable

wool products provided that the products are washed

according to the instructions on the garment label and those

issued by the manufacturer of this washing machine. The

Woolmark symbol is a Certication mark in many countries.

(M2232)

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Specic for synthetic items. If the dirt is dicult to remove, the temperature

can be increased up to 60° and powder detergent can be used too.

Mixed

A 40°C cycle for washing cotton and synthetic garments together.

Suitable for lightly soiled underwear.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at 40 °C

or 60 °C, together in the same cycle. This is the standard cotton programme

and the most ecient in terms of water and energy consumption.

! As specied, this wash cycle only runs at 40 °C.

White

For heavily soiled whites and resistant colours.

Rapid 20min

Allows for varying the garment treatment duration from 20’ to 60’.

- 20’: this cycle refreshes your garments in just 20 minutes.

- 45’: a short cycle designed for washing mixed cotton-synthetic

garments.

- 60’: this cycle is designed to wash moderately soiled resistant cotton

garments at 60°C in an hour, with good washing performance. For

synthetic or mixed garments, the temperature should be lowered to 40°C.

Rapid 45min Full Load

Suitable for washing a full load of cotton clothes moderately soiled in 45

minutes.

Duvet

For washing clothing padded with goose down, such as double or single

duvets (weighing under 3 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it is

advisable to use liquid detergent to be poured into the detergent drawer.

Delicates 30°C

Suitable for washing very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed to spin and drain the water.

DISPLAY

The display is useful when programming the machine and provides a lot

of information.

C (see “Options”)

The duration of the available wash cycles and the remaining time of a

running cycle appear in section ; if the Delayed Start option has been A

set, the countdown to the start of the selected cycle will appear.

Pressing the corresponding button allows for viewing the maximum spin

speed and temperature values attained by the machine during the set

wash cycle, or the values selected most recently, if these are compatible

with the set wash cycle.

The hourglass ashes while the machine processes the data on the basis

of the selected cycle. After a maximum of 10 minutes, the icon remains

steady lit and the nal time remaining is displayed. The “hourglass” icon

will then switch o approximately 1 minute after the nal time remaining

has been displayed.

The “washing phases” relative to the selected cycle and the “washing

phase” of the running cycle appear in section :B

Wash

Rinse

Spin

Drain

When lit, the symbol indicates that the set “Delayed Start” value has

appeared on the display.

There are three levels in section relative to the washing options.C

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

Rapid programming

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

STARTING CYCLE

Press the PUSH & GO button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

Traditional programming

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

- Use the WASH CYCLE selector knob to select the desired wash cycle: it

will be associated with a specic temperature and spin speed that can be

modied. The duration of the cycle will appear on the display.

- Modify the temperature and/or spin speed: the machine automatically

displays the maximum temperature and spin speed values set for the

selected cycle, or the most recently-used settings if they are compatible

with the selected cycle. Pressing the button gradually reduces the

temperature down to the cold wash “OFF” setting. Pressing the button

gradually reduces the spin speed until it is completely excluded (“OFF”

setting). Pressing these buttons again restores the maximum values.

- Select the desired options.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened. Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash amber),

then select the desired cycle and press the START/PAUSE button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

This will be indicated by the word “END” on the display; when the

symbol switches o, the door may be opened. Open the door and switch

o the machine. If you do not press ON/OFF button, the washing

machine will switch o automatically after about a 10 minutes. Close the

water tap, open the door and unload the washing machine. Leave the

door ajar to allow the drum to dry.

OPTIONS

- If the selected option is not compatible with the set wash cycle, the

indicator light will ash and the option will not be activated.

- If the selected option is not compatible with another previously

selected option, the indicator light will ash accompanied by a buzzer

(3 beeps), and only the latter option will be activated; the indicator

light corresponding to the activated option will turn on.

Stain removal

This option allows for selecting the type of dirt so as to optimally adjust the

cycle for removing the stains. The following types of dirt can be selected:

- Food: for stains caused by foodstus and beverages, for example.

- : for grease and ink stains, for example.Work

- Outdoor: for mud and grass stains, for example.

! The wash cycle duration varies according to the type of selected dirt.

Rapid

When this button is pressed the rst time, the 45’ icon lights up, when

pressed the second time the 60’ icon lights up and the third time the 20’

icon lights up.

Delayed Start

To set a delayed start for the selected cycle, press the corresponding

button repeatedly until the desired delay period has been reached. When

this option has been activated, the symbol lights up on the display. To

remove the delayed start setting, press the button until the word “OFF”

appears on the display.

Temperature

Each wash cycle has a pre-dened temperature. To modify the

temperature, press the button. The value will appear on the display.

Spin

Each wash cycle has a pre-dened spin speed. To modify the spin speed,

press the button. The value will appear on the display.

PUSH & GO

To start the PUSH & GO cycle press and hold the relative button for

2 seconds. The lit indicator light indicates that the cycle has started.

This wash cycle is ideal for cotton or synthetic fabrics, as it washes at a

temperature of 30°C and a maximum spin speed of 1,200 rpm. Max load

3,5 kg (cycle duration 59’).

During the last phase of the cycle garments will be treated with steam, that

will relax the bres making ironing easier and quicker (Steam Tecnology).

How does it work?

1. Load the laundry (cotton and/or synthetic garments) and close the door.

2. Pour the detergent and additives.

3. Start the cycle by pressing and holding the PUSH & GO button for 2

seconds. The relevant indicator light will turn green and the door will lock

(the symbol lights up).

N.B.: starting the wash cycle through the PUSH & GO button activates an

automatic non-customisable cycle recommended for cotton and synthetic

fabrics. This cycle does not allow for setting any additional options.

To open the door while an automatic cycle is under way, press the START/

PAUSE button; if the locked door symbol is o, the door may be

opened. Press the START/PAUSE button again to restart the cycle from

the point at which it was interrupted.

4. At the end of the wash cycle the word END will appear on the display.

CHILD LOCK

To activate the control panel lock, press and hold the button for

approximately 2 seconds. The lit “ “ symbol signals that the control

panel is locked. This prevents wash cycles from being modied

accidentally (except for the ON/OFF button), especially if there are

children in the home. To deactivate the control panel lock, press and hold

the button for approximately 2 seconds.

TIPS AND SUGGESTIONS

Divide the laundry according to:

Type of fabric (cotton, mixed bres, synthetics, wool, garments to be

hand-washed). Colour (separate coloured garments from whites, wash new

coloured garments separately). Delicates (small garments – such as nylon

stockings – and items with hooks – such as bras: insert them in a fabric bag).

Empty the pockets:

Objects such as coins or lighters can damage the washing machine and

the drum. Check all buttons.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus

detergent in your laundry and it saves money by avoiding waste of surplus

detergent.

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are generally

those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the

“Wash Cycle Table” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning speed

in the spinning phase, the higher the noise and the lower the remaining

moisture content.

CARE AND MAINTENANCE

Before performing cleaning and maintenance, switch the washing machine

o and disconnect it from the mains power. Do not use ammable liquids to

clean the washing machine. Clean and maintain your washing machine

periodically (at least 4 times per year).

Disconnect the water and power supplies

Close the water tap after every wash. This will limit wear on the hydraulic

system inside the washing machine and help to prevent leaks.

Unplug the washing machine when cleaning it and during all

maintenance work.

Clean the washing machine

The outer parts and rubber components of the appliance can be cleaned

using a soft cloth soaked in lukewarm soapy water. Do not use solvents or

abrasives.

The washing machine has a “Auto-clean” cycle for its internal parts; it

must be run without any load in the drum.

To optimise this cycle, it is possible to use either detergent (10% of the

quantity specied for lightly soiled garments) or special additives to clean

the washing machine. We recommend running a cleaning cycle every 40

wash cycles.

To start the cycle press buttons and simultaneously for

5 seconds.

The cycle will start automatically and will run for about 70 minutes. To

stop the cycle, press the START/PAUSE button.

Clean the detergent dispenser drawer

Wash it under running water; this operation should be repeated

frequently.

Care for the door and drum

Always leave the porthole door ajar in order to prevent unpleasant odours

from forming.

Clean the pump

The washing machine is tted with a auto-cleaning pump that does not

require any maintenance. Small items (such as coins or buttons) may

sometimes fall into the protective pre-chamber situated at the base of the

pump.

! Make sure the wash cycle has ended and unplug the appliance.

To access the pre-chamber:

1. remove the cover panel on the front of the machine by rst pressing it

in the centre then pushing downwards on both sides to extract it;

2. loosen the drainage pump cover by turning it anti-clockwise: it is

normal for some water to leak out;

3. clean the inside thoroughly;

4. screw the cover back on;

5. put the panel back in place, making sure the hooks slot in place before

pushing the panel onto the appliance.

Check the water inlet hose

Check the water inlet hose at least once a year. If it is cracked or broken, it

must be replaced: during wash cycles, the high pressure of the water

could suddenly split the hose open.

! Never use hoses that have already been used.

LOAD BALANCING SYSTEM

Before every spin cycle, to avoid excessive vibrations before every

spin and to distribute the load in a uniform manner, the drum rotates

continuously at a speed which is slightly greater than the washing

rotation speed. If, after several attempts, the load is not balanced

correctly, the machine spins at a reduced spin speed. If the load is

excessively unbalanced, the washing machine performs the distribution

process instead of spinning. To encourage improved load distribution and

balance, we recommend small and large garments are mixed in the load.

ACCESSORIES

Contact our Technical Assistance Service to check whether the following

accessories are available for this washing machine model.

Stacking kit

With this accessory you can secure the tumble dryer to the upper part of

your washing machine to save space and facilitate loading and unloading

of the tumble dryer.

TRANSPORT AND HANDLING

Do not lift the washing machine by gripping it from the upper section.

Unplug the appliance and close the water tap. Check that the door and

detergent dispenser drawer are tightly closed. Detach the lling hose

from the water tap then detach the drain hose. Empty all the water

remaining in the hoses and secure the latter so that they do not get

damaged during transport. Apply the transport bolts back on. Repeat, in

reverse order, the transport bolt removal procedure described in the

“Health & Safety and Installation Guides”.

Product specificaties

Merk:	Indesit
Categorie:	Wasmachine
Model:	BWE 71496X SV UK

Heb je hulp nodig?

Als je hulp nodig hebt met Indesit BWE 71496X SV UK stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Wasmachine Indesit

Indesit BI WMIL 81485 UK Handleiding

15 November 2024

Indesit MTWSA 61294 W EE Handleiding

15 November 2024

Indesit BWE 91285X Handleiding

15 November 2024

Indesit MTWSA 61294 WK EE Handleiding

15 November 2024

Indesit IM 762 MY TIME EE Handleiding

20 Oktober 2024

Indesit IM 864 MY TIME EE Handleiding

20 Oktober 2024

Indesit BWE 81496X WV UK Handleiding

3 September 2024

Indesit BWE 101496X WV UK Handleiding

3 September 2024

Indesit BWA 81496X KV UK Handleiding

3 September 2024

Indesit BWE 71496X SV UK Handleiding

3 September 2024

Handleiding Wasmachine

Nieuwste handleidingen voor Wasmachine

Otsein LB LTO129A Handleiding

21 November 2024

Otsein LB LTO109A Handleiding

21 November 2024

Otsein-Hoover LB HV16ESALU Handleiding

21 November 2024

Sangiorgio ST6512EL Handleiding

21 November 2024

Sangiorgio FS614D9 Handleiding

21 November 2024

Sangiorgio PROGETTO F4 Handleiding

21 November 2024

Sangiorgio SG710 Handleiding

21 November 2024

Sangiorgio F814DIBC Handleiding

21 November 2024

Sangiorgio F812D Handleiding

21 November 2024

Sangiorgio F812L Handleiding

21 November 2024
