Pagina 1/28
Quick User Guide
EN β€” Quick User Guide
1
Safety Instruction: You must carefully read this safety instructions before using and installing the product.
Warnings & Cautions:
● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end user.-
● You must be in strict compliance with electrical safety regulations of the nation and region. Firmly connect the plug to the power
socket. Do not connect several devices to one power adapter. Power off the device before connecting and disconnecting
accessories and peripherals.
● Input voltage should meet the SELV (Safety Extra Low Voltage) and the LPS (Limited Power Source) according to the IEC60950 1. -
● If smoke, odor or noise rise from the device, power off at once and unplug the power cable, and then contact the service center.
For Camera:
● Only use accessories recommended by HIKVISION.
● Do not expose the camera directly to high concentrations of X ray, laser or UV radiation. The direct exposure may cause -
permanent damage to the image sensor.
● If the product does NOT work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the
camera yourself.
For DVR/NVR:
● The device is designed for indoor use only. Install it in a well ventilated, dust free environment without liquids.- -
● Properly secure the device to a rack or shelf. Major shocks or jolts may cause damage to the sensitive electronics within the
device.
● Use the device in conjunction with an UPS, and use factory recommended HDD if possible.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED β€œAS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE -
TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM
CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.
PRODUCED BY:
Hangzhou Hikvision Digital Technology Co. Ltd.
Qianmo Road 555, Binjiang District, Hangzhou
310052, China
Made in China
CONTACT INFORMATION IN CHINA:
Hangzhou Hikvision Digital Technology Co. Ltd.
Qianmo Road 555, Binjiang District, Hangzhou
310052, China
Tel: +86 571 8807 5998- - -
Fax: +86 571 8993 5635- - -
EN β€” Quick User Guide
2
β—† Get started for the basic usage of analog/network camera, and speed dome.
Step 1. Check the installation environment including cables, tools, and the original packaging.
Step 2. Install the memory card for local storage (if needed).
Step 3. Install the camera/speed dome to the proper place.
Step 4. Connect alarm in/out to the alarm device (if needed)
Step 5. Connect the power supply cables.
Step 6. See the procedures below:
For analog camera: Connect video cable to the VIDEO IN interface in the DVR.
For analog speed dome:
a) Connect video cable to the VIDEO IN interface in the DVR.
b) Connect RS 485 to the DVR. -
c) Set DIP switch for analog speed dome.
For network camera/network speed dome:
a) Connect the network camera to a PC with a network cable.
b) Input the default IP address: 192.168.1.64.
c) Input and confirm your password and Click β€œ to finish activation.OK”
d) Connect the camera and PC to the same router or the same switch.
e) Login the camera (default IP: 192.168.1.64) via your password.
f) Modify the IP address to the same subnet with connected router/switch.
g) Re- login with the new IP address.
Notes:
⚫ For the network camera which enables the DHCP by default, you need to activate the network camera via SADP software and
search the IP address.
⚫ NVR can also be used to activate and set the network camera.
Step 7. Power on the cameras, DVR/NVR and monitor, then you can view the image on the monitor.
Notes:
⚫ For detailed information, See the Quick Start Guide or User Manual which can be downloaded from www.hikvision.com or
www.hi watch.eu-
⚫ The functions vary depending on the models of network camera.
β—† Get started for the basic usage of digital/network video recorder.
Step 1. Install the HDD.
See detailed installation in the from User Manual www.hikvision.com or
www.hi watch.eu- according to specific model.
Step 2. Connect peripheral devices to the DVR/NVR.
Step 3. Power on the DVR/NVR, and activate it by creating a strong
password and confirming it.
Step 4. Log in to the DVR/NVR, and follow the Setup Wizard to configure
basic parameters.
You can operate and configure the device, including the live view, record
schedule, playback, backup, etc.
Note: For the detailed operation of DVR/NVR, refer to the from User Manual www.hikvision.com www.hi watch.eu or - according
to the specific model.
TECHNICAL SUPPORT
In case of any problem, please immediately contact the local after sales service authorized by Hikvision.-
Analog Camera
Analog Speed Dome
Monitor
Network Speed Dome
Monitor
DVR
TCP/IP
TCP/IP
Network Camera
SYV
SYV


Product specificaties

Merk: HiLook
Categorie: Niet gecategoriseerd
Model: DVR-204U-K1
Kleur van het product: Zwart
Gewicht: 1160 g
Breedte: 315 mm
Diepte: 242 mm
Hoogte: 45 mm
Gewicht verpakking: 1855 g
Breedte verpakking: 485 mm
Diepte verpakking: 290 mm
Hoogte verpakking: 85 mm
Ethernet LAN: Ja
Videocompressieformaten: H.264, H.264+, H.265, H.265+
Audiosysteem: 2-weg
Maximale beeldsnelheid: 30 fps
Aantal USB 2.0-poorten: 2
Aantal HDMI-poorten: 1
Aantal Ethernet LAN (RJ-45)-poorten: 1
Vermogensverbruik (max): 10 W
Formaat analoog signaal: NTSC, PAL
Maximale videoresolutie: 1920 x 1080 Pixels
Audio-ingangen: 1
Audio-uitgang: 1
Aantal gebruikers: 32 gebruiker(s)
Soort voeding: DC
USB-aansluiting: Ja
Ondersteunde netwerkprotocollen: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPTM, HTTPS, ONVIF
Ethernet interface type: Fast Ethernet
HDD interface: SATA
Aantal kanalen: 4 kanalen
Videostreaming: Ja
Maximum aantal HDD's per behuizing: 1
BNC input ports: 4
VGA (D-Sub) uitgang ports: 1
Videoingangkanalen: 2 kanalen
Bedrijfstemperatuur (T-T): -10 - 55 Β°C
Relatieve vochtigheid in bedrijf (V-V): 10 - 90 procent
Gelijkspanning (DC): 12 V
Aantal gelijktijdig afgespeelde kanalen: 4 kanalen
Maximum HDD capaciteit: 8000 GB
Audiostreaming: Ja
Dual stream ondersteuning: Ja
