HELGI HV6530 Handleiding
Lees hieronder de 📖 handleiding in het Nederlandse voor HELGI HV6530 (15 pagina's) in de categorie Monitor. Deze handleiding was nuttig voor 12 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/15
HELGI V-SERIES
Interactive Flat Panel
USER MANUAL
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: education@helgi-europe.com | business@helgi-europe.com | Web: www.HELGI-europe.com
HELGI IFP V SERIES
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: education@helgi-europe.com | business@helgi-europe.com | Web: www.HELGI-europe.com 2
HELGI IFP V SERIES
USER GUIDE
Safety Warning
Safety Warning
Positioning
Do not put heavy objects on top of the unit.
Do not put the unit near appliances that generate magnetic fields.
Do not expose the unit to direct sunlight and other sources of heat.
Do not place the unit on an unstable cart, stand, tripod, bracket, table, or shelf.
Do not put any liquid near or on the unit, make sure do not spill any liquid inside the unit.
Power Supply
Please keep power cable from physical or mechanical damage.
Please check and ensure AC source is connected with the ground.
This power cable comes with the device exclusively for this device only.
Please unplug power supply when the weather is thunder-storm or lightning.
Check that the unit’s operating voltage is identical with your local power supply.
Please use the original power cable from the accessory bag, don’t modify or lengthen it.
Please unplug power supply, when there is nobody home or the unit will be in idle for a long time.
LED Screen
Unplug the power cable before cleaning. Clean the screen with a soft, dustless and dry cloth.
For deep clean, please contact an authorized service center. Never use water or the spray type detergent to clean the unit.
Never use any other hard or sharp object to replace the touch pen. Better for the panel lifetime and the display performance, do not
display high brightness image for long time.
Temperature
Normal operating temperature is 0 ~ 40°C.
Do not place the unit near or over a radiator or a heater.
If your unit is suddenly moved from a cold to a warm place, please unplug the power
cable and do not turn it on at least 2 hours, making sure the moisture inside the unit is all evaporated.
Humidity
Do not expose the unit in rain, or place in high humidity area.
Please make sure indoor environment is dry and cool. Normal operating humidity is
10%~90%RH.
Ventilation
Please put the unit in a well-ventilated place, so the heating can be released easily.
Ensure that the unit has enough space for ventilation. Space requirement: left, right and
back >10cm, top> 20cm.
Earphones
Before using earphone, please turn down the volume in advance.
Using the earphone to listen loud sound for a long time might affect the hearing.
Standby
It will enter standby mode but not turn off the unit after press the standby key.
Battery
Please make sure the battery gets proper disposal or recycle after using.
Please keep the battery away from kids and don’t throw the battery into fire.
Notes for Cleaning
There are vents on back cover, please do not use any liquid or spray directly during
Power Switch Status Signs
“I” means power on, “O” means power off.
Notes for Maintenance
This machine can only be maintained by certified engineer.
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: education@helgi-europe.com | business@helgi-europe.com | Web: www.HELGI-europe.com
3
HELGI IFP V SERIES
USER GUIDE
Control Panel
Control Panel
Number Items Function description
1Magnetic zone Area for placing the adsorptive magnetic pen
2Tap to enter Energy Saving Function Press at least 2 seconds to enter standby mode
3Power Indicator Light Open the power supply when the power indicator light is Always is normal
4Remote control signal
receiver Do not place any object in front of the IR signal receiver, otherwise the remote control will not work
5USB USB interface for Android operating system and integrated mini PC
1. Prepare to Install
Product specificaties
Merk: | HELGI |
Categorie: | Monitor |
Model: | HV6530 |
Kleur van het product: | Black, Grey |
Gewicht verpakking: | 49700 g |
Breedte verpakking: | 1656 mm |
Diepte verpakking: | 204 mm |
Hoogte verpakking: | 1050 mm |
Materiaal behuizing: | Metaal |
Beeldschermdiagonaal: | 65 " |
Resolutie: | 3840 x 2160 Pixels |
Oorspronkelijke beeldverhouding: | 16:9 |
Grafische adapter: | Mali G51 |
Inclusief besturingssysteem: | Android |
Ethernet LAN: | Ja |
Kijkhoek, horizontaal: | 178 ° |
Meegeleverde kabels: | AC, HDMI, USB Type-A to USB Type-B, VGA |
Typische contrastverhouding: | 5000:1 |
Touch technologie: | Multi-touch |
Helderheid: | 450 cd/m² |
LED backlight: | Ja |
Aantal USB 2.0-poorten: | 5 |
VGA (D-Sub)poort(en): | 1 |
Aantal HDMI-poorten: | 3 |
PC audio ingang: | Ja |
Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
Ingebouwde luidsprekers: | Ja |
Gemiddeld vermogen: | 32 W |
Stroomverbruik (in standby): | 0.5 W |
Vermogensverbruik (max): | 300 W |
Aantal luidsprekers: | 2 |
Hoofdtelefoonuitgangen: | 1 |
Beeldscherm, aantal kleuren: | 1.073 biljoen kleuren |
RS-232C: | Ja |
Maximale refresh snelheid: | 60 Hz |
HD type: | 4K Ultra HD |
Intern geheugen: | 2048 MB |
Processor architectuur: | ARM Cortex-A73 + ARM Cortex-A53 |
RS-232 port: | 1 |
Audio-ingangen: | 1 |
Audio-uitgang: | 2 |
Operating systeem versie: | Android 8.0 |
HDMI: | Ja |
Display technologie: | LCD |
Responstijd: | 8 ms |
VESA-montage: | Ja |
Paneelmontage-interface: | 600 x 400 mm |
Duurzaamheidscertificaten: | CE, ENERGY STAR, RoHS |
Contrast ratio (dynamisch): | 6000:1 |
Effectieve beelddiameter: | 1428.48 x 803.52 mm |
Diepte ( zonder voet ): | 87 mm |
Hoogte (zonder voet ): | 897 mm |
Breedte ( zonder voet ): | 1489 mm |
Gewicht (zonder voet): | 38750 g |
Plug and play: | Ja |
Type processor: | Ja |
Meegeleverde software: | Note (Android), Note Plus (Windows), Connect (Windows), Capture (Windows).\n1 year Chimpa RDM software license included. |
Backlight type: | LED |
Soort voeding: | AC |
Soort paneel: | IPS |
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 3 |
Mac-compatibiliteit: | Ja |
Inhoud: | 1x EU / UK Power cord (3m), 1x HDMI (3m), 1x USB (5m), User Manual, 2x Passive pens\n1x Remote control (batteries included). |
Verbinding met pc: | Ja |
HDD capaciteit: | 16 GB |
Ophangsysteem voor aan de muur: | Ja |
Hoeveelheid simultane aanraakpunten: | 20 |
Touchscreen technologie: | Infrarood |
Inclusief Stylus: | Ja |
Hardheid oppervlak: | 7H |
S/PDIF-uitgang: | Ja |
OPS-modulesleuf: | Ja |
Draaien: | Nee |
Afstandsbediening inbegrepen: | Ja |
Wifi: | Nee |
Batterijen inbegrepen: | Ja |
Aantal gelijktijdige touchpoints (Windows 7): | 20 |
OTA (Over-the-air) updates: | Ja |
Locale/landinstellingen: | Arabic, Catalan, Croatian, Czech, Danish, Dutch, English, Estonian, French, German, Greek, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Swedish, Traditional Chinese, Turkish |
