OWNER’S MANUAL

Uses two AA ALKALINE batteries only.

Do not use “Heavy Duty” batteries.

Do not use ordinary Zinc Carbon batteries.

MF44 051915

ACCESSORIES

FOR COMPLETE DETAILS VISIT WWW.FISHERLAB.COM • 1-800-685-5050

Fisher

Padded Carry Bag

Rugged double stitched construction. Includes handy

exterior pocket for extra batteries or small accessories.

– 103693000C

Fisher

Camo Pouch

Camo pouch with two inside pockets, belt included. –

PCH-F

Stereo Headphones

Use with Fisher

metal detectors. Lightweight and adjustable with

true stereo sound, adjustable volume, 1/4 jack with 1/8 adaptor,

4’ cable. – 9720950000

Metal Sand Scoop

Large galvanized metal scoop with filtering holes. Strong Rubberized grip.

– SAND SCOOP

Lesche Knife

Made from high quality heat-treated tempered steel. The ultimate digging tool.

Comes with a durable sheath. 12" in length with a 7" serrated blade.

– LESCHE KNIFE

Fisher

Baseball Cap

One size fits all. – FCAP

Fisher

T-Shirt

100% cotton with Fisher

Logo. Sizes: S, M, LG, XL & XXL – FTSHIRT

Replacement/Accessory Search Coils

7” Round Elliptical Accessory Coil – 7COIL-RE-F

9” Triangulated Concentric Elliptical Accessory Coil – 9COIL-EE

11” Triangulated Concentric Elliptical Replacement Coil – 11COIL-EE

Coil Covers

Specially made to protect your coil from abrasion and damage.

9” Triangulated Concentric Elliptical Coil Cover– 9COVER-EE

11” Triangulated Concentric Elliptical Coil Cover– 11COVER-EE

Rain Cover

Neoprene protective cover specially made to protect your F11 from weather–

COV-F11

Neoprene protective cover specially made to protect your F22 or F44 from weather–

COV-F22

Gold

Prospecting Kits

TABLE OF CONTENTS

Congratulations!

Congratulations on the purchase of your new Fisher F44™ Metal Detector. The F44 is the result of

many years of software engineering and features the latest advancements in lightweight design and

target accuracy. The F44 can be used with its default modes, or use the Custom mode to create your

own setup. No longer will weather be a force that stops you from enjoying your sport, the F44 is

completely weatherproof. Laugh at the rain. Treasure hunting enthusiasts from around the world were

involved in the development of this revolutionary new detector. This manual has been written to help

you get optimal use of your detector so we hope you will read it thoroughly before your first outing.

Happy Hunting from Fisher Research Labs!

The

The The F44 operates at

F44 operates at

F44 operates atF44 operates at

a frequ

a frequa frequen

enency

cy cy of 7.

of 7.

of 7.of 7.69 kHz

69 kHz

69 kHz 69 kHz and co

and co

and coand comes

mes

mes mes with a

with a

with a with a 11”

11”

11”11” t

t triangulated concentric

riangulated concentric

riangulated concentricriangulated concentric

elliptical

elliptical elliptical sear

sear

searsearchcoil.

chcoil.

chcoil.chcoil.

The

The The F44 shares

F44 shares

F44 shares F44 shares searchcoil compatibility

searchcoil compatibility

searchcoil compatibility searchcoil compatibility w

wwi

iith the

th the

th the th the F11

F11

F11 F11 and

and

and and F22.

F22.

F22.F22.

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Contents of Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Batteries (use alkaline batteries) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Quick-Start Demonstration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

The Basics of Metal Detecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10

Using the Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Searchcoil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Operation and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

The Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Depth Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Overload Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-16

Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Notch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Pinpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

How to Pinpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Target-ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17-18

4-Tone ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Custom Mode Programmable Tones . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Depth and Target Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-20

Target Groups and ID Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Target-ID Coin Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Ground Cancelation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-22

Manual Ground Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-23

Headphone Jack / Using Headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Characteristics & Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Treasure Hunter's Code of Ethics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Page

5-YEAR LIMITED WARRANTY

FREE DETECTOR

For details, visit www.fisherlab.com

The metal detector is warranted against defects in materials and workmanshipF44

under normal use for five years from the date of purchase to the original owner.

Damage due to neglect, accidental damage or misuse of this product is not

covered under this warranty. Decisions regarding abuse or misuse of the F44

metal detector are made solely at the discretion of the manufacturer.

Proof of Purchase is required to make a claim under this warranty.

Liability under this Warranty is limited to replacing or repairing, at our option, the

metal detector returned, shipping cost prepaid, to First Texas Products. Shipping

cost to First Texas Products is the responsibility of the consumer.

To return your detector for service, please first contact First Texas Products for a

Return Authorization (RA) Number. Reference the RA number on your package

and return the detector within 15 days of calling to:

Fisher Research Labs

1465 Henry Brennan Dr.

El Paso, TX 79936

Phone: 915-225-0333 ext. 118

NOTICE TO CUSTOMERS OUTSIDE THE U.S.A.

This warranty may vary in other countries; check with your distributor for details.

Warranty does not cover shipping costs to and from the U.S.A.

According to FCC part 15.21, changes or modifications made to this device not expressly approved by the party

responsible for compliance could void the user’s authority to operate this equipment.

This device complies with FCC Part 15 Subpart B Section 15.109 Class B.

Fisher®is a registered trademark of Fisher Research Labs

www.fisherlab.com

TREASURE HUNTER’S CODE OF ETHICS:

• Always check Federal, State, County and local laws before searching.

• Respect private property and do not enter private property without the owner’s permission.

• Take care to refill all holes and leave no damage.

• Remove and dispose of any and all trash and litter found.

• Appreciate and protect our inheritance of natural resources, wildlife and private property.

•

Act as an ambassador for all treasure hunters; use thoughtfulness, consideration and courtesy at all times.

• Never destroy historical or archaeological treasures.

• All treasure hunters may be judged by the example you set; always conduct yourself with

courtesy and consideration of others.

TERMINOLOGY

The following terms are used throughout the manual and are standard

terminology among detectorists.

RELIC

A relic is an object of interest by reason of its age or its association with

the past. Many relics are made of iron, but can also be made of bronze

or precious metals.

IRON

Iron is a common, low-grade metal that is an undesirable target in certain

metal detecting applications. Examples of undesirable iron objects are

old cans, pipes, bolts and nails. Sometimes the desired target is made

of iron. Property markers, for instance, contain iron. Valuable relics can

also be composed of iron; cannon balls, old armaments and parts of old

structures and vehicles can also be composed of iron.

FERROUS

Metals which are made of, or contain iron.

ELIMINATION

Reference to a metal being "eliminated" means the detector will not emit

a tone, nor display a Target-ID, when a metal object passes through the

searchcoil's detection field.

DISCRIMINATION

When the detector emits different tones for different types of metals, and

when the detector "eliminates" certain metals, we refer to this as the

detector "discriminating" among different types of metals.

Discrimination is an important feature of professional metal detectors.

Discrimination allows the user to ignore trash and otherwise undesirable

objects.

PINPOINTING

Pinpointing is the process of finding the exact location of a buried object.

Long-buried metals can appear exactly like the surrounding soil and can

therefore be very hard to isolate from the soil.

V.C.O.

Meaning “voltage controlled oscillator,” the V.C.O. audio method causes

both the audio pitch and the volume to rise as signal strength increases.

V.C.O. improves the user's ability to interpret a target's size and depth.

Very weak signals (for small or very deeply buried objects) have the

faintest volume and the lowest pitch. Larger objects, and those closer to

the searchcoil, will induce a higher volume and higher pitch sound.

GROUND CANCELATION

Ground Cancelation is the ability of the detector to ignore, or "see

through," the earth's naturally occurring minerals, and only sound a tone

when a metal object is detected. This detector incorporates proprietary

circuitry to eliminate false signals from many mineralized soils. 3

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Consult the dealer or an experienced radio/TV technician for help.

CE The manufacturer declares that the minimum ESD performance criteria is 1) the unit shall not

be permanently damaged and 2) operator intervention is allowed.

This product is RoHS compliant.

This product meets the requirements of Industry Canada: CAN ICES-3 B/NMB-3 B.

TROUBLESHOOTING GUIDE

SYMPTOM CAUSE SOLUTION

Detector chatters, • Using detector • Use detector

beeps erratically indoors outdoors only

or has low • Using detector near • Move away

sensitivity power lines

from power lines

• Using 2 detectors in • Keep 2 detectors

close proximity at least 6 meters

(20’) apart

• Environmental • Reduce sensitivity

electromagnetic until erratic

interference signals cease

Low speaker •

Discharged battery

• Replace battery

volume

• Wrong type of • Use alkaline

battery batteries

Display does not lock

• Multiple targets •

Sweep coil at

on to one Target-ID present different angles

or detector emits • Highly mineralized • Move to a

multiple tones soil different area

• Sensitivity set

too high • Reduce sensitivity

No power, no sounds

• Dead battery • Replace batteries

• Cable not •

Check connections

connected securely

Do not mix old and new batteries. Use alkaline batteries.

Do not mix alkaline, standard (zinc-carbon), or

rechargeable (NiCad, NiMH, etc.) batteries.

Product specificaties

Merk:	Fisher
Categorie:	Detector
Model:	F44

Heb je hulp nodig?

Als je hulp nodig hebt met Fisher F44 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Detector Fisher

Fisher F22 Handleiding

27 Juli 2023

Fisher F44 Handleiding

27 Juli 2023

Fisher F11 Handleiding

27 Juli 2023

Handleiding Detector

Nieuwste handleidingen voor Detector

Techno Line WZ 1200 Handleiding

18 November 2024

PCE Instruments PCE-MPC 30 Handleiding

17 November 2024

Chauvin Arnoux C.A 1110 Handleiding

17 November 2024

Mercury MDW-01 Handleiding

16 November 2024

Toolcraft LDM D30 Handleiding

16 November 2024

IFM O5P503 Handleiding

15 November 2024

IFM OIP282 Handleiding

15 November 2024

Sauter SO 200K Handleiding

15 November 2024

Seaward LLT MK2 Handleiding

5 November 2024

K40 Platinum200 Expert Handleiding

11 September 2024
