Pagina 1/68

GLUE GUN

16W

GGM1002

WWW.FERM.COM

Original instructions 02

Übersetzung der Originalbetriebsanleitung 04

Vertaling van de oorspronkelijke gebruiksaanwijzing

Traduction de la notice originale 10

Traducción del manual original 13

Tradução do manual original 16

Traduzione delle istruzioni originali 19

Översättning av bruksanvisning i original 22

Alkuperäisten ohjeiden käännös 25

Oversatt fra orginal veiledning 28

Oversættelse af den originale brugsanvisning 30

Eredeti használati utasítás fordítása 33

Překlad püvodního návodu k používání 36

Preklad pôvodného návodu na použitie 38

Tłumaczenie instrukcji oryginalnej 41

Originalios instrukcijos vertimas 44

Instrukciju tulkojums no oriģinālvalodas 46

Prevedeno s izvornih uputa 49

Перевод исходных инструкций 52

Переклад оригінальних інструкцій 55

Μετάφραση του πρωτοτύπου των οδηγιών χρήσης

2Ferm

ELECTRICAL GLUE GUN

Thank you for buying this Ferm product.

By doing so you now have an excellent product,

delivered by one of Europe’s leading suppliers.

All products delivered to you by Ferm are

manufactured according to the highest standards

of performance and safety. As part of our

philosophy we also provide an excellent customer

service, backed by our comprehensive warranty.

We hope you will enjoy using this product for many

years to come.

Read the operating instructions carefully

before using this device. Familiarise

yourself with its functions and basic

operation. Service the device as per the

instructions to ensure that it always

functions properly. The operating

instructions and the accompanying

documentation must be kept in the

vicinity of the device.

Contents

1. Machine information

2. Safety instructions

3. Operation

4. Service & maintenance

1. Machine information

Technical specifications

Voltage 230 - 240 V~

Frequency 50 Hz

Power input 16 W

Diameter glue stick 11.2 mm

Weight ca. 0.24 kg

Contents of the package

1 Glue gun

6 Glue sticks

1 Kit

1 Manual

1 Safety instructions

1 Guarantee card

Check the machine, loose parts and accessories

for transport damage.

2. Safety instructions

Explanation of symbols

Denotes risk of personal injury, loss of

life or damage to the tool in case of non-

observance of the instructions in this

manual.

Indicates the presence of an electrical

voltage.

Immediately unplug the plug from the

mains electricity in the case that the cord

gets damaged and during maintenance.

Specific safety instructions

Before operating the glue gun:

• Check the following points:

• Do the voltage of glue gun correspond to the

mains voltage.

• Are the mains lead and the mains plug in a

good condition: solid, without any loose ends

or damage.

• Mount the bracket before plugging in the tool.

• As hot glue can cause burns, avoid contact.

• Always allow the gun to cool down by itself.

• Never immerse the tool in water.

Immediately unplug the glue gun in case of:

• The glue gun is overheated.

• Malfunction of the mains plug, -socket or

damaged cables.

• Broken switch.

• Smoke or smell caused by scorched

insulation.

Electrical safety

When using electric machines always observe the

safety regulations applicable in your country to

reduce the risk of fire, electric shock and personal

injury. Read the following safety instructions and

also the enclosed safety instructions.

Always check that the power supply

corresponds to the voltage on the rating

plate.

Class ll machine. Your machine is double

insulated; therefore no earthwire is

required.

Ferm

Replacing cables or plugs

Immediately throw away old cables or plugs when

they have been replaced by new ones. It is

dangerous to insert the plug of a loose cable in the

wall outlet.

Using extension cables

Only use an approved extension cable suitable for

the power input of the machine. The minimum

conductor size is 1.5 mm

2. When using a cable

reel always unwind the reel completely.

3. Operation

Always observe the safety instructions

and applicable regulations.

This glue gun (kit) has been especially designed

for glueing products such as wood, plastic, foam,

rubber, fabric, cardboard, tiles, ceramics, etc.

Quickly setting, the glue is perfect for repairing

carpets, bookbinding, fixing soles, etc. The glue is

waterproof and resistant to the action of many

liquids. The glue gun is quick, environmentally-

friendly, energy-saving and together with the glue

facilitates and quickens any job.

Due operating the glow gun

• The normal setting time of the hot glue is 30

seconds. After 30 seconds the glue starts to

set. Having applied the glue on the relevant

surfaces, wait 15 - 20 seconds before joining

them.

• After about 1 minute the joint has reached

90% of its adhesive strength.

• The setting time can be extended to 50 to 60

seconds by applying the glue in thick drops or

shortened by applying the glue in short, fine

lines.

• Joining large surfaces is difficult, as the glue

tends to set before the entire surface has been

covered with glue.

• Preheating the surfaces to be joined

guarantees a strong joint. Sun rays have the

same impact.

• The glue melts from a temperature of approx.

140°C and must never be used on material

that is sensitive to heat.

• The glue gun can be used to replace nails,

paper tape, liquid glue, but not for heavy-duty

jobs.

• The electric glue gun features accurate

temperature control. It is fitted with a special

design feed system that ensures no glue is left

behind inside the mechanism.

• The glue gun requires Ø 11.2 mm glue

cartridges.

• The glue gun comes standard with a bracket

that enables you to put the gun safely on the

table when it is not used.

Operation

• Plug in the tool.

• Insert a glue cartridge into the gun, two when

using it for the first time.

• Wait 5 minutes for the glue to heat.

• Squeeze the trigger to release the glue.

• Replace the glue cartridge as soon as you

notice little if any glue is released from the

gun.

• Disconnect the tool if you do not intend to use

it for some time.

Replacing the nozzle

• Loosen the orange nozzle.

• Fit the nozzle on the glue gun.

Before removing the nozzle, allow the

glue gun to cool down completely to

avoid injuries. Always disconnect the

tool.

4. Service and maintenance

Make sure that the machine is not live

when carrying out maintenance work on

the motor.

This machine has been designed to operate over

a long period of time with a minimum of

maintenance. Continuous satisfactory operation

depends upon proper machine care and regular

cleaning.

Always disconnect the tool before

cleaning and maintenance work. Never

use inflammable liquids to clean the tool.

Use a brush to clean the glue gun.

• Keep the nozzle clean. Check before every

use there is no glue left on the nozzle.

• Remove any glue left inside the nozzle with a

pin.

Malfunction

Should the machine fail to function correctly, a

number of possible causes and the appropriate
