Master Clock Generator G-05
The Ultimate Five
The Master Sound Discrete Clock, a completely in-house developed OCXO* clock module,
has been designed to enable the combined digital source equipment to take musical expression one step further.
The G-05 Master Clock Generator is now available with this in-house developed module,
which will bring out the full musical reproduction potential of the Esoteric K and N series,
as well as a wide range of other digital players.
* OCXO = Oven Controlled Crystal Oscillator
Clock Output Frequency: 10MHz
Frequency Precision: Within ± 0.01ppm
(when shipped new)
Connectors: BNC x 4
Output Level: Sine wave 0.5 ±0.1Vrms / 5
Power: 120V AC 60Hz, 220 -240V AC 50/60Hz
Power Consumption: 10W (when stable)
Overall Dimensions 380 x 128 x 350mm (W×H×D):
(include protrusions)
Weight: 10kg
G-05 Master Clock Generator
Printed in Japan 0723WEB TECD-0352
ESOTERIC COMPANY
1-47, Ochiai, Tama-shi, Tokyo Japan 206-8530
https://www.esoteric.jp/en
Please note that not all models are available in every country. Design and specications subject to change without notice.
©2023 Esoteric Company. All Rights Reserved. All text, images, graphics and other materials on this brochure are subject to the copyright and other intellectual proper ty rights of Esoteric Company.
These materials shall not directly or indirectly be published, reproduced, modied or distributed in any medium. Esoteric is a trademark of TEAC Corporation, registered in the U.S. and other
countries. Grandioso is a trademark of TEAC Corporation. All other brand or product names are trademarks or registered trademarks of their respective holders.
This product is available in two dierent power supply variations as shown in the Speciations section.. Make sure that the voltage shown on the rear panel matches the AC line voltage in your area.
The shape of the AC inlet and plug of the supplied power cord depends on the voltage rating and destination country.
Authorized Dealer
Esoteric-HCLD Output Buer Circuit
The G-05 is equipped with the highly acclaimed Esoteric-HCLD” output buer amplier circuit
found in the Grandioso C1X preamplifier. It takes adva ntage of its powerful current transfer
capability and 180MHz wide frequency response to deliver pure 10MHz sine wave clock signal
to connected digital players.
Equipped with Four 10 MHz Clock Outputs
Four 10 MHz sine wave clock outputs are provided to supply clocks to up to four digital devices.
Custom Designed Coaxial Cables with MIL-standard SMA connectors
Special custom coa xial cables, carefully selected for sound quality, are used for the critical
wiring inside the G-05. The connectors are gold-plated SMA connectors that comply with MIL
standards. The output connectors are gold-plated BNC connectors with precisely matched
impedance = 5to increase transmission reliability and reduce loss.
Unique Chassis Construction
The chassis construction is also specially designed for vibration-sensitive master clocks. The
fro nt and side panels a re made of heavy-duty, thick-walled aluminum to suppress external
vibrations. The Master Sound Discrete Clock module inside the chassis is freely mounted and
grounded by its own weight without the use of mounting screws. The isolation feet, machined
from steel and suppor ted at three points, use a special mounting method that uses the weight
of the chassis to connect to the bottom plate. By eliminating as many screws as possible for
mounting the clock module and isolation feet, and by avoiding the stress concentration caused
by screwing these vibration-sensitive components together, a natural vibration damping eect
can be achieved, resulting in superior sound quality. In addition, the top plate has a semi-oating
structure that is not xed with screws, resulting in an open sound.
