User’s Manual

USB 5.1-Chan. Audio Converter

Overview

This product adopts PCM (Pulse-Code Modulation)

sampling technology to digitize audio analog

signals. It receives audio stream from PC via USB

interface and transmits audio data according to the

consumer interface standards in digital playback

mode. It can also transmit Dolby Digital AC-3 data

streams to it’s decorder to get 5.1 channel audio

and enable USB HID (Human Interface Device) to

work. Thus a software is developed which

integrates above features to present a simulation of

5.1-channel audio surrounding effect. Listening

CD or internet music, watching DVD movies or

concerts as well as TV programs will be most

benefited by this converter.

Features

 Supports AES/EBU, IEC60958 and S/PDIF

consumer formats for stereo PCM audio

 Supports 2-channel 16-bit PCM audio at ﬁxed

48KHz sampling rate for 5.1 channel playback

 Full-duplex playback audio stream no need sound

card in PC

 Compatible with Win 98/SE/ME/2000/XP and Mac

 LED indication for power-on (red) and operation

(green)

 Play & Play and hot swapping

 Complaint with USB audio device class Spec.1.0

(HID)

 Draws power from PC USB port

 Supports suspend/resume and remote wake-up

Specification

Model No. UDA 501

Chip SONIX

Upstream USB Type A Male*1

Connector

Device Audio Jack *3

USB Compliant USB 1.1

Data Speed 12Mbps

LED 3

Cable Length 1M

Housing Plastic

Installation

1. For Windows OS, please refer to the

User’s Guidelines – Installation of

Device Application Program under

Windows OS on CD which we provided

with the product for details.

2. For MAC OS, please refer to the User’s

Guidelines – Setting-Up of Function

Program under MAC OS on CD which we

provided with the product for details.

System Requirements

 Windows 98/SE/ME/2000/XP and Mac OS

 Availability of USB Port on PC

 5.1-channel speaker preferable

Package Content

 USB 5.1-channel audio converter

 CD (Application Drivers and User’s Manual)

Product specificaties

Merk:	Equip
Categorie:	Kabels voor pc's en randapparatuur
Model:	USB > 5.1 Audio-Converter
Kleur van het product:	Grijs
Compatibele besturingssystemen:	Windows 98SE, ME, 2000, XP, Vista\nMac OS 9.2.1 / 10.1
Aansluiting(en):	USB, AES/EBU, IEC60958, S/PDIF
Aansluiting 1 type:	Mannelijk
Aansluiting 2 type:	Vrouwelijk
