Pagina 1/74

Elinchrom SA RQ Li-Ion Battery Box - Printed in Switzerland - 01.03.2012 (73014)

USER MANUAL

GEBRAUCHSANLEITUNG

MANUEL D’UTILISATION

MANUALE D’USO

MANUAL DE INSTRUCCIONES

is a registered trademark of ELINCHROM LTD, RENENS, SWITZERLAND

Ranger Quadra Lithium Ion

Battery Box - 19295

User Manual

Table of contents

Introduction 2

Declaration of conformity 3

CE / Disposal 3

Notational Conventions 4

User Safety Information 4

Travelling in general and by Air 6

Outdoors 6

Battery Li-Ion Characteristics 6

Before You Start 7

Troubleshooting 9

Li-Ion Compatibility Chart for Ranger Quadra Models 11

Li-Ion Compatibility Chart for Ranger Quadra Heads A & S 12

Ranger Quadra 13

Warranty Information 14

Warranty 71

User Manual

INTRODUCTION

Dear photographer

Thank you for buying the ELINCHROM Ranger Lithium Ion Battery Box. All

Elinchrom products are manufactured using the most advanced technology.

Carefully selected components are used to ensure the highest quality and the

equipment is submitted to many tests both during and after manufacture. We

trust that it will give you many years of reliable service.

Please read the instructions carefully, before use, for your safety and to

obtain maximum beneﬁt from the many features.

Your Elinchrom-Team

Please read carefully the notes about this manual…

This manual may show images of products with accessories, which are not part

of Sets or single units.

Elinchrom set and single unit conﬁgurations may change without advice and

may differ in other countries.

Please ﬁnd actual conﬁgurations at www.elinchrom.com

For further details, upgrades, news and the latest information about the

Elinchrom System, please regularly visit the Elinchrom website. The latest user

guides and technical speciﬁcations can be downloaded in the “Support” area.

Technical data, features and functions of Elinchrom ﬂash units, accessories and

the EL-Skyport system may change without advice.

The listed values can differ due to tolerances in components, or measuring

instruments.

Technical data, subject to change. No guarantee for misprints.

Keep this user manual for later information and reference.

Product specificaties

Merk:	Elinchrom
Categorie:	Batterij-oplader
Model:	Li-Ion Charger Set
Kleur van het product:	Zwart
Ingebouwd display:	Nee
Aantal per verpakking:	1 stuk(s)
Kleur kabel:	Zwart
Aantal inbegrepen batterijen:	1 stuk(s)
Compatibele batterij technologiën:	Lithium-Ion (Li-Ion)
Batterijen inbegrepen:	Ja
Batterijtechnologie:	Lithium-Ion (Li-Ion)
