Mounting the camera
Posion on the license plate top screws for the best viewing angle. This should not be
directly next to or under a reverse/backup/license lamp as it may blind the camera at night.
Before drilling, determine the best way to run the power wires to the reverse lights
and the extension cable through the car. Insure that the route will not interfere with
any safety equipment, trunk release or other items in the vehicle. Look for wires,
sensors, double metal, anything that could cause a problem or damage.
The camera should lay flat against the mounng surface for proper installaon.
1.Fix the camera to the appropriate posion on the license plate and adjust the angle .
2.Follow ONE of the following wiring opons.
OPTION 1: Connect camera power wire to the vehicle's reverse lamp:
a)Locate the reverse lamp in the tail light assembly.
b)Aach the red wire to the posive 12 volt wire from the reverse lamp.Use a crimp connector or soldering tool to ensure connecon
is secure. Once this connecon is complete,note that the red power wire that is located on either end of the video RCA cable will not
be needed. The bare wire at the end of each wire lead should be capped or taped off to prevent potenal power interrupon.
c)Aîž©ach the black wire to ground(-).
d)Run video cable to the locaon of the receiver or monor(not included).Connect one yellow RCA end of the video cable to the
camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).
OPTION 2: Connect camera power wire to receiver/monitor power:
a)From camera locaon,connect red power wire from power cable to red power wire from one end of the video cable.Use a crimp
connector or soldering tool to ensure connecon is secure.
b)Aîž©ach the black wire to ground.
c)Run video cable to the locaon of the receiver or monitor(not included).Connect not yellow RCA end of the video cable to the
camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).
d)From video source(receiver/monitor) locaon,connect red power wire from end of the video cable to the reverse wire lead located
on the video source(receiver/monitor).
Camera Specifications
Image Sensor: CMOS,OV 7955
Powe 12V DC,Negave Groundr:
Power Consump 1 Waon: <
Effecve Pixels: 672H × 492V
Video Format: NTSC
Lux: 0.5<
White Balance: Auto
Viewing Angle: 170 Degrees
IP Rang: IP67
Operating Temperature: -30 ~ +70℃ ℃
P late material: Stainless Steel SUS304
Camera Body: Plastic
Camera input
of receiver
BUCAM350 BUCAM License plate style camera350
Power Cable w/ Fuse, Video Cable
Universal License Plate
Style Camera
Power/Ground Cables
Red (12V+) and Black (GND-)
(Recommended connection for 12V+ to
reverse light power wire.)
