INSTRUCTION BOOK FOR

Parallax™ Thin

Preparation

Note: It requires two people to install a Parallax Thin. To maintain

optimal projected image geometry and screen alignment, a lat

and straight wall free from obstructions and angular distortions

should be used.

Tools Required For Assembly

Level Measuring Tape

Choose a clean work area for assembly using padded material or

other soft, clean materials. The work area should be larger than

the overall screen size and directly in front of the location where

the screen is to be installed.

Hardware Provided

44” Wall Bracket

(2) 92”, 96” and 105½” Wide Screens

28” Wall Bracket

(2) 80” and 87” Wide Screens

Cleaning

Parallax screen surface can be cleaned as follows:

Using a white clean cloth (100% cotton preferred) that is dampened with clean water, gently wipe the area in a horizontal direction. Do

not wipe in a vertical direction or with a circular motion. Using a dry 100% cotton cloth, wipe screen surface dry in horizontal direction

after each cleaning. Windex Original spray cleaner can be used on tough to clean areas.

Drill Drill Bits

(1) Striker plate with countersunk hole for #10 screw

Figure 1

Wall Mounting Instructions

NOTE: The screen is shipped with two wall brackets. Screens in

widths of 88¾” and below receive (2) 28” wall brackets. Screens

above 88¾” in width receive (2) 44” wall brackets. Use appropriate

mounting hardware for the wall type and to accommodate for

the screen’s hanging weight (Figure 1).

1. Secure the two wall brackets to wall studs at the desired height.

The outside edge of each wall bracket must be no greater than 5”

away from the left and right edges of the frame. You will need at

least 2” clearance above the drilled holes to hang the screen

(Figure 1) .

2. To install the striker plate, take your screens overall height

(including frame) and subtract 1¼”. Using that dimension, measure

down from the top edge of the wall brackets and mark the wall

for a screw hole (Figure 1).

NOTE: Make sure your mark corresponds with where you intend

the center of your image to be once the screen is fully installed.

3. Secure the striker plate to the wall at the marked locations.

NOTE: Make sure the screw head is lush to the face of the striker

plate so that the full pull force of the magnet is acheived.

4. With two people, one on either end of the screen, lift the screen

onto the wall. Making sure the wall brackets are securely seated in

the back of the screens frame.

5. Slowly lower the bottom of the screen, making sure the center of

the screen is aligned with the striker plate on the wall.

CAUTION: Pinch Hazard. While lowering the screen, be

careful to keep your ingers clear of the magnet and striker

plate.

Overall Height Less 1¼”

Striker Plate

Product specificaties

Merk:	Da-Lite
Categorie:	Projectiescherm
Model:	Parallax Thin 29170
Kleur van het product:	Zwart
Oorspronkelijke beeldverhouding:	16:9
Montagewijze:	Muur
Aantal per verpakking:	1 stuk(s)
Gemakkelijk te installeren:	Ja
Zichtbare schermhoogte (h):	1320 mm
Zichtbare schermbreedte (b):	2340 mm
Diagonaal:	106 "
Formaat:	HDTV
Schermoppervlak:	Parallax 0.8
Spanscherm:	Ja
