DIN-AO8

DIN Rail Analog Output Module

Installation & Operation Guide

1. Place the top of the DIN-AO8’s rail mount over the top of the DIN rail.

2. Tilt the bottom of the DIN-AO8 toward the DIN rail until it snaps into place.

NOTE: When mounting DIN rail products, it may be necessary to use a at-head

screwdriver to pull the DIN rail release tab while snapping the device onto the DIN rail.

NOTE: Certain third-party DIN cabinets provide space for an informational label

between each DIN rail row. Crestron’s Engraver software (version 4.0 or later) can

generate appropriate labels for all Crestron DIN rail products.

Description

The Crestron® DIN-AO8 is a DIN rail-mounted automation control module that provides

eight analog output ports for interfacing with third-party lighting and heating and cooling

systems.

Installation

WARNING: To avoid re, shock, or death, turn off the power at the circuit breaker or

fuse and test that the power is off before wiring!

NOTES: Observe the following points:

• This product must be installed and used in accordance with appropriate electrical

codes and regulations.

• This product must be installed by a qualied electrician.

Additional Resources

Visit the product page on the Crestron website (www.crestron.com)

for additional information and the latest rmware updates. Use a QR

reader application on your mobile device to scan the QR image.

Hardware Hookup

Make the necessary connections. Apply power after all connections have been made.

WARNING: Prior to connecting the device, turn off power at the circuit breaker. Failure

to do so may result in serious personal injury or damage to the device. Restore power

after all connections have been made.

CAUTION: Connecting this device to the wrong type of load or short-circuiting the load

can cause severe product damage. Each load should be tested to identify a short-circuit

condition prior to wiring the load to the module.

NOTE: Use copper wire only.

NOTE: Each switch leg of the DIN-AO8 may be fed from a separate circuit breaker.

When making OUTPUTS, NET, and OVERRIDE connections, strip the ends of the wires

approximately 7/16 in (11 mm). Use care to avoid nicking the conductors. Tighten the

connector to 5 in-lb (0.5 to 0.6 N-m). The wire gauge should be 14 to 26 AWG.

When making power connections to the DIN-AO8, use a Crestron power supply.

Hardware Connections for the DIN-AO8

OUTPUTS:

To Devices with

Analog Inputs

NET:

To Control System and

Other Cresnet Devices

OVERRIDE:

From Device Providing

Override Signal and to Other

Devices Receiving Override

Signal

DIN-AO8

DIN Rail (Not

Supplied)

DIN Rail

Release

Top

NOTE: To remove the DIN-AO8 from the DIN rail, use a small, at object (i.e., a

at-head screwdriver) to pull the DIN rail release and tilt the bottom of the DIN-AO8

away from the DIN rail.

TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION

The DIN-AO8 does not

function.

The device is not

communicating with the

network.

Use Crestron Toolbox to

poll the network. Verify the

network connection to the

device.

The device is not receiving

power from a Crestron

power source.

Use a Crestron power

source. Verify the

connections.

The device is not receiving

sufcient power.

Use the Crestron Power

Calculator to help

calculate how much

power is needed for the

system.

There is a loss of

functionality due to an

electrostatic discharge.

The device is not

grounded properly.

Check that all of the

ground connections have

been made properly.

As of the date of manufacture, the DIN-AO8 has been tested and foudn to comply with specications

for CE marking.

This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver is •

connected.

Consult the dealer or an experienced radio/TV technician for help. •

Crestron Electronics, Inc. Installation & Operation Guide - DOC. 6663B

15 Volvo Drive Rockleigh, NJ 07647 (2020745)

Tel: 888.CRESTRON 08.15

Fax: 201.767.7576 Specications subject to

www.crestron.com change without notice.

The product warranty can be found at www.crestron.com/warranty.

The specic patents that cover Crestron products are listed at patents.crestron.com.

Certain Crestron products contain open source software. For specic information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, Cresnet, and Crestron Toolbox are either trademarks or registered

trademarks of Crestron Electronics, Inc. in the United States and/or other countries. UL and the UL

logo are either trademarks or registered trademarks of Underwriters Laboratories, Inc. in the United

States and/or other countries. Other trademarks, registered trademarks, and trade names may be

used in this document to refer to either the entities claiming the marks and names or their products.

Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not

responsible for errors in typography or photography.

This document was written by the Technical Publications department at Crestron.

Operation

The DIN-AO8 can be controlled via its front panel as well as from a control system. The

following local controls are available.

NOTE: Before using the DIN-AO8, ensure the device is using the latest rmware. Check

for the latest rmware for the DIN-AO8 at www.crestron.com/rmware. Firmware is

loaded onto the device using Crestron Toolbox™.

Manual Load Control

The level of each of the analog outputs can be manually controlled from the front panel.

To toggle the output between off (0V) and the programmed upper limit (10V), tap an output

button. The corresponding LED illuminates, and the output level is shown on the NET ID

display (“oF” for off, “On” for on) for two seconds, after the button is released.

To ramp the voltage up or down (until it reaches a limit), press and hold the output button.

To change the ramp direction, release the output button, and then press and hold it again.

The corresponding LED illuminates, and the output level is shown on the NET ID display

as a percentage (01-99) for two seconds, after the button is released.

NOTE: The control system program may change the settings if Override mode is not

enabled.

Establish Override Mode Levels

Override mode disables the control system program and sets all of the output states to the

stored override values. The state of each output can be saved as an override setting,

which can be automatically recalled when the Override mode is enabled.

NOTE: The control system program has a setting that can prevent locally saving the

override state. If this setting is enabled, the display shows “Er” when trying to save

override states. For more information, refer to the SIMPL Windows help le.

To save the load level as an override setting, set all of the loads to either on or off, and

then press and hold the button for three seconds. The OVR LED blinks to indicate OVR

the new override setting has been stored.

Set the Net ID

The Net ID of the DIN-AO8 has been factory set to 88. The Net IDs of all devices in the

same system must be unique. The Net ID can be changed from the front panel of the

DIN-AO8 or from a personal computer via Crestron Toolbox™.

Set the Net ID using the front panel.

1. Press the button to enter Setup mode. The SETUP LED illuminates.SETUP

2. Press the left and right buttons under the NET ID display to change the Net ID.

NOTE: The DIN-AO8 will leave Setup mode after 10 seconds of inactivity and

revert to the previously set Net ID.

3. When the desired Net ID is displayed, press the button to exit the Setup SETUP

mode. The SETUP LED extinguishes.

NOTE: If an invalid Net ID is set (i.e., 00, 02, FF), “Er” will be displayed on the NET

ID display, and the DIN-AO8 will revert to the previously set Net ID.

A small Net ID label is provided on the DIN-AO8 to document the unit’s Net ID in the case

where power is not available. Apply a mark over the digits that correspond to the assigned

Net ID.

NET ID Label (“3C” Shown)

Toggle Override Mode

The Override mode overrides the control system program and sets all of the output levels

to the saved override values. For instructions on saving override levels, refer to “Establish

Override Mode Levels.”

To enable the Override mode, press and release the button. The OVR LED ashes OVR

slowly.

NOTE: If the Override mode was enabled from an external device (i.e., a contact

closure is present on the OVERRIDE terminals), the OVR LED ashes quickly. Pressing

the button has no effect.OVR

To disable the Override mode, press the button again. The OVR LED extinguishes OVR

and the output levels return to the values set by the control system program.

NOTE: The factory default override level is 100% if override levels have not been saved.

Reset

To reboot the DIN-AO8, press the button. The output levels will be set to the level RESET

currently specied by the control system program. If the control system does not provide

a value, the outputs will be set to the previously set levels.

Troubleshooting

The following table provides corrective action for possible trouble situations. If further

assistance is required, please contact a Crestron customer service representative.

Product specificaties

Merk:	Crestron
Categorie:	Niet gecategoriseerd
Model:	DIN-AO8
Gewicht:	179 g
Breedte:	106 mm
Diepte:	59.5 mm
Hoogte:	94.2 mm
Stroom:	0.25 A
DC voltage input:	24 V
Relatieve luchtvochtigheid:	10 - 90 procent
Aantal kanalen:	- kanalen
Bedrijfstemperatuur (T-T):	0 - 40 °C
Module type:	Analoog
Signaal directie:	Uitgang
