DIN-1DIM4

DIN Rail 4-Channel Dimmer

Operations & Installation Guide

Description

The Crestron® DIN-1DIM4 is a DIN rail mounted lighting control module with four channels

of dimming. A single model supports both 120 and 220-277 V electronic and magnetic

low-voltage, incandescent, neon/cold cathode, 2-wire dimmable uorescent, and

non-dimmable lighting loads up to 5 A per channel, 10 A total.

Additional Resources

Visit the product page on the Crestron website (www.crestron.com) or

scan the QR code to the right for additional information and the latest

rmware updates.

Hardware Hookup

Make the necessary connections as shown below. Apply power after all connections have

been made. When making connections to the DIN-1DIM4, use Crestron power supplies for

Crestron equipment.

WARNING: Prior to connecting the device, turn off power at the circuit breaker. Failure to

do so may result in serious personal injury or damage to the device. Restore power after

all connections have been made.

CAUTION: Connecting this device to the wrong type of load or short circuiting the load

can cause severe product damage. Each load should be tested to identify a short circuit

condition prior to wiring the load to the module.

NOTE: Strip the ends of the wires approximately 1/4 in (6 mm). Use care to avoid nicking

the conductors. Twist together the ends of the wires that share a connection. Apply solder

only to the ends of the twisted wires. Avoid tinning too far up the wires or the end

becomes brittle.

NOTE: High-voltage connections accept 2.5 mm

2 (12 AWG) wire. Wire should be stripped

to 8 mm (1/3 inch). Tighten terminal blocks to 0.5 Nm (5 in-lbs).

NOTE: The DIN-1DIM4 power feed must be protected by a 10 A (trip curve C) breaker or

equivalent.

NOTE: The DIN-1DIM4 outputs must be used to control permanently installed lighting

loads only.

NOTE: Do not mix magnetic and electronic transformers on the same dimmer output.

NOTE: Use copper wire only. For high-voltage connections, use wire rated for at least

75º C (167º F).

NOTE: Ensure the unit is properly grounded by connecting the chassis ground lug to an

earth ground (building steel).

Hardware Connections for the DIN-1DIM4

Installation

WARNING: To avoid re, shock, or death, turn off power at circuit breaker or fuse and

test that power is off before wiring!

CAUTION: This equipment is for indoor use only. Mount in a well-ventilated area. The

ambient temperature must be 0º to 40º C (32º to 104º F). The relative humidity must be

10% to 90% (non-condensing).

NOTE: This product should be installed and used in accordance with appropriate

electrical codes and regulations.

NOTE: This product should be installed by a qualied electrician.

NOTE: When installing in an enclosure, high-voltage devices should be grouped

separately from low-voltage devices.

Install the DIN-1DIM4

The DIN-1DIM4 installs on a DIN rail.

1. Use a at object (e.g., a at-head screwdriver) to pull the DIN rail release downward.

2. With the top of the unit tilted down, place the DIN-1DIM4 against the bottom of the

DIN rail.

NOTE: When mounting DIN rail products, it may be necessary to use a at-head

screwdriver to pull the DIN rail release tab down while snapping the device onto

the DIN rail.

3. Tilt the top of the DIN-1DIM4 toward the DIN rail until it is secure on the top edge of

the rail. Push the DIN rail release upward to lock the DIN-1DIM4 into place.

Mount DIN-1DIM4

Remove the DIN-1DIM4

To remove the DIN-1DIM4 from the DIN rail, use a at object (e.g., a at-head screwdriver)

to pull the DIN rail release and tilt the bottom of the DIN-1DIM4 away from the DIN rail.

NOTE: Certain third party DIN cabinets provide space for an informational label

between each DIN rail row. Crestron’s Engraver software (version 4.0 or later) can

generate appropriate labels for all Crestron DIN rail products.

Top

DIN Rail

(Not Supplied)

DIN Rail

Release

Neutral

Line

120/277 Volts

from Breaker

120/277 Volts

Load

Ground

Neutral

Line

Ground

NET:

To Control System

and Other

Cresnet® Devices

LIVE:

Line Power Input

from AC Power Line

OVERRIDE:

From Device

Providing Override

Signal and to Other

Devices Receiving

Override Signal

NEUTRAL:

Neutral

Connection from

AC Power LIne

DIMMED LIVE (1 - 4):

Dimmer Channel

Outputs

Ground

With the circuit breaker turned off, connect the wires to the terminal blocks per the

markings provided on the DIN-1DIM4.

Load Connections Example for the DIN-1DIM4

Set the Net ID

The Net ID of the DIN-1DIM4 has been factory set to 89. The Net IDs of all devices in the

same system must be unique. The Net ID can be changed from the front panel of the

DIN-1DIM4 or from a personal computer via Crestron Toolbox™.

Set the Net ID using the front panel.

1. Press the button to enter Setup mode. The SETUP LED illuminates.SETUP

2. Press the left and right button under the NET ID display to change the Net ID.

NOTE: The DIN-1DIM4 will leave Setup mode after 10 seconds of inactivity and

revert to the previously set Net ID.

3. When the desired Net ID is displayed, press the button to exit Setup mode. SETUP

The SETUP LED extinguishes.

NOTE: If an invalid Net ID is set (i.e., 00, 02, FF), “Er” will be displayed on the NET

ID display and the DIN-1DIM4 will revert to the previously set Net ID.

A small Net ID label is provided on the DIN-1DIM4 to document the unit’s Net ID in the case

where power is not available. Apply a mark over the digits that correspond to the assigned

Net ID.

NET ID Label (“3C” Shown)

Establish Override Mode Levels

Override mode disables the control system program and sets all of the output states to the

stored override values. The state of each output can be saved as an override setting,

which can be automatically recalled when Override mode is enabled.

NOTE: The control system program has a setting that can prevent locally saving the

override state. If this setting is enabled, the display shows “Er” when trying to save

override states. For more information, refer to the SIMPL Windows help le.

To save the load level as an override setting, set all of the loads to their desired levels and

then press and hold the button for three seconds. The OVR LED blinks to indicate the OVR

new override setting has been stored.

Toggle Override Mode

To enable Override mode, press the button. The OVR LED ashes slowly. Override OVR

mode can also be toggled via a remote contact closure attached to the OVERRIDE port.

NOTE: If Override mode was enabled from an external device (i.e., a contact closure

connected to the OVERRIDE port), the OVR LED will ash quickly when the local OVR

button is pressed. Pressing the local button has no effect when Override mode was OVR

toggled via the remote connection.

To disable Override mode, press the button again. The OVR LED extinguishes and OVR

the outputs return to the states set by the control system program.

NOTE: If override levels have not been saved, the factory default override level is 100%.

Reboot the DIN-1DIM4

To reboot the DIN-1DIM4, press the button. The outputs will be set to the states RESET

currently specied by the control system program. If the control system does not provide

any values, the outputs will be set to the previously set values.

Select the Operating Mode

CAUTION: Selecting an incompatible lighting load may cause damage to the

DIN-1DIM4 or the lighting load.

In the event that the DIN-1DIM4 is to be operated without a connection to a control

system, the operating mode must be set locally.

NOTE: Once a program has been downloaded to the DIN-1DIM4, the manual selection

of load types will be restricted. For example, if the program denes a channel as

NON-DIM, it cannot be set to DIM locally. Similarly, if the program denes a channel as

DIM, it cannot be set to NON-DIM locally.

Once a connection to a control system has been established, the SIMPL windows symbol

should dene the unit as DIM or NON-DIM. The operating mode must still be selected

locally on the dimmer.

The operating mode is selected locally for each channel using the recessed channel mode

select buttons. Press the recessed button for the appropriate channel until the proper

operating mode is selected. Repeat this process for each channel on the dimmer. Refer to

the table that follows for information about each operating mode and the corresponding

unit display.

Operation

NOTE: Before using the DIN-1DIM4, ensure the device is using the latest rmware.

Check for the latest rmware for the DIN-1DIM4 at www.crestron.com/rmware. Firmware

is loaded onto the device using Crestron Toolbox.

The DIN-1DIM4 can be controlled via its front panel as well as from a control system. The

following local controls are available.

Control the Loads from the Front Panel

The lighting level of each output can be manually controlled from the front panel.

To toggle the light between off and 100% (on), tap the appropriate load button. The

corresponding LED illuminates and the output level is shown on the NET ID display (“oF” for

off, “On” for on) for two seconds after the button is released.

To ramp the lighting level up or down (until it reaches a limit), press and hold the

appropriate load button. To change the ramp direction, release the load button, and then

press and hold it again. The corresponding LED illuminates and the output level is shown on

the NET ID display as a percentage (01% to 99%) for two seconds after the button is

released.

NOTE: The control system program may change the settings if Override mode is not

enabled.

OPERATING MODE UNIT DISPLAY

DIM: Channel operates as a dimmer with no

switching capabilities. The DIM LED will illuminate

when operating as a dimmer.

Operating mode should be set to DIM when

controlling dimmable xtures.

NON-DIM: Channel operates only as a switch with

no dimming capabilities. The NON-DIM LED will

illuminate when operating as a switch.

Operating mode should be set to NON-DIM when

controlling non-dimmable xtures.

As of the date of manufacture, the DIN-1DIM4 has been tested and found to comply with

specications for CE marking.

This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

CAUTION: Changes or modications not expressly approved by the manufacturer responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

Crestron Electronics, Inc. Operations & Installation Guide - DOC. 6928B

15 Volvo Drive Rockleigh, NJ 07647 (2026315)

Tel: 888.CRESTRON 04.15

Fax: 201.767.7576 Specications subject to

www.crestron.com change without notice.

protection against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada (IC) Compliance Statement

Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that may cause undesired operation

of the device.

The product warranty can be found at www.crestron.com/warranty.

The specic patents that cover Crestron products are listed at patents.crestron.com.

Crestron, the Crestron logo, Cresnet, and Crestron Toolbox are either trademarks or registered

trademarks of Crestron Electronics, Inc. in the United States and/or other countries. UL and the UL

logo are either trademarks or registered trademarks of Underwriters Laboratories, Inc. in the United

States and/or other countries. Other trademarks, registered trademarks, and trade names may be

used in this document to refer to either the entities claiming the marks and names or their products.

Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not

responsible for errors in typography or photography.

This document was written by the Technical Publications department at Crestron.

TROUBLESHOOTING

The following table provides corrective action for possible trouble situations. If further

assistance is required, please contact a Crestron customer service representative.

DIN-1DIM4 Troubleshooting

TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION

The device does not

function.

The DIN-1DIM4 is

not receiving power

from the ac line or

the Crestron power

supply.

Ensure that the circuit

breaker was not tripped.

The device is not

receiving power from

a Crestron power

supply.

Use a Crestron power

supply. Verify the

connections.

The device is not

receiving sufcient

power.

Use the Crestron Power

Calculator to help

calculate how much

power is needed for the

system.

An electrostatic

discharge occurred

due to improper

grounding.

Check that all of the

ground connections

have been made

properly.

The PWR LED blinks. The DIN-1DIM4 is

not receiving power

from the ac line.

Ensure that the circuit

breaker was not tripped.

The unit ignores Cresnet

commands.

The unit is in Override

mode.

Take the DIN-1DIM4 out

of Override mode by

pressing the button OVR

or releasing the override

contact closure.

The LOAD LED blinks 3

times, pauses for 1

second, and then

repeats.

An overload or over

temperature situation

exists.

Reduce the load on the

channel.

The Channel 1 LED blinks

and all of the channels

turn off.

The firmware upgrade

has failed.

Cycle power on the

DIN-1DIM4.

The load ickers, ashes,

or slowly varies in light

level when running on

generator or UPS power.

There is unstable

frequency due to

generator or UPS

power.

Using Crestron Toolbox,

disable the Wilson lter.

NOTE: Disabling the

Wilson lter may leave

the dimmer susceptible

to other forms of line

noise creating icker.

Product specificaties

Merk:	Crestron
Categorie:	Niet gecategoriseerd
Model:	DIN-1DIM4
Kleur van het product:	White, Black
Ingebouwd display:	Ja
Gewicht:	960 g
Breedte:	216 mm
Diepte:	60 mm
Hoogte:	95 mm
Cijfers weergeven:	2 cijfers
Rack-montage:	Nee
Aantal kanalen:	4 kanalen
AC-ingangsspanning:	120-277 V
AC-ingangsfrequentie:	50 - 60 Hz
