CSD45M
Congratulations!
Thank you for purchasing this Carlsbro digital drum set This drum set has been developed to act and play .
like an acoustic drum set but with greater ease and much lower volume Before you use the instrument . ,
we recommend that you take the time to carefully read through this user guide to familiarise yourself with ,
the controls and get the best out of your new drum set It also contains important safety information and .
practical hints and tips to perfectly setup and conf gure your drum set .
Taking care of your digital drum set
Location
- Please set up your drum set in a spacious area on a carpet or rug where available .
- , Do not expose the unit to the following conditions to avoid deformation discolouration or more
serious damage 󰿉 :
Direct sunlight high temperatures next to a heat source in a car during the day time or in a cold , , , ,
damp environment .
Power supply
- Make sure to use a correct AC adaptor and that the AC outlet voltage of your country matches
the input voltage specif ed on the AC adaptor and label on the underside of the sound module , .
- Turn the power switch OFF when the Instrument is not in use .
- The AC adaptor should be unplugged from the AC outlet if the instrument is not to be used for
an extended period of time .
- . Unplug the AC adaptor during electrical storms
- Avoid plugging the AC adaptor into the same AC outlet as appliances with high power
consumption such as electric heaters or ovens, .
-Try to avoid using multi plug adaptors as these can result in a reduction of sound quality - ,
operational errors and possibly damage , .
Turn power OFF when making connections
- To avoid damage to the instrument and connected devices turn the power switches of all ,
related devices OFF prior to connecting or disconnecting any cables .
Handling and transport
- Never apply excessive force to the controls buttons connectors or other parts of the, ,
instrument.
- Always unplug cables by gripping the plugf rmly not by pulling on the cable, .
- .Disconnect all cables before moving the instrument
- , , Physical shocks caused by dropping bumping or placing heavy objects on the instrument will
result in scratches and more serious damage .
- . Do not disassemble any components or try to analyse any internal parts by yourself There are
no user serviceable parts for this drum set If any malfunction occurs during use stop using it and - . ,
refer to the trouble shooting page towards the end of this user guide .
Cleaning
- . Unplug the power plug before cleaning this drum set Do not touch the power plug with wet
hands or materials .
- .Clean with a dry soft cloth
- . A slightly damp cloth may be used to remove stubborn grime and dirt
- , Never use cleaners such as alcohol detergents or thinners .
- ( ).Avoid placing vinyl objects on top of the unit vinyl can stick to and discolour the surface
Electrical interference
- This instrument contains digital circuitry and may cause interference if placed too close to radio
or television receivers If this occurs move the instrument further away from the affected . ,
equipment.
Unpacking
- Please retain the packaging for this product in the unfortunate event that the product or any
individual part needs to be returned for service or repair Please complete the warranty card .
included with this product and also write your product serial number in the box at the end of this
user guide Returning the completed warranty card does not diminish your statutory rights in .
anyway.
1
Drum kit assembly
1 Open the drum frame as illustrated. .
* : , , note for left handed assembly open the frame legs backwards so the snare arm is to the right
hand side .
2 Once your frame is in position slightly tighten the frame bolts with your supplied drum key to. , ,
reduce movement .
3 Place cymbal poles/Hi-Hat stand and L shape drum arms on the drum frame as illustrated. .
4 Fix the mesh drum pads to the L arms The snare pad is a larger 10 pad. . ? .
5 Place the cymbals on top of the cymbal poles and fasten with the cymbal nuts and felt.
washer above the cymbal Do not over tighten the cymbal should have slight movement and not . ,
be rigid .
* : - note The Hi Hat Cymbal pad is different to the Crash and Ride cymbal pads please pay close ,
attention to the labels on the underside of the cymbal pads .
6 Place the sound module in the remaining frame bracket either side of the Hi Hat cymbal. - .
* : -note It is ideal for younger drummers to have the module to the front of the frame so that the Hi
Hat is closer to reach For adults the Hi Hat and Module position can be reversed to give a much . -
larger playing area .
7 Place the bass tower on the floor to your required position usually under TOM2 position. , .
8 Adjust the Hi-Hat stand floor spikes so the Hi-Hat stand grip to your carpet or rug to reduce. ,
2
movement.
Cymbal pole
Hi-Hat stand
Snare arm
Frame bolts
L shape arm
Cymbal pole
