Pagina 1/8
CS-STYX
HDSLR/DV SUPPORT SYSTEMS
INSTRUCTION MANUAL
EN
Please read this manual carefully before using the Cambo CS rig!
CAMBO | WHERE TRADITION MEETS VISION | MADE IN THE NETHERLANDS
Instruction Manual CS-
Styx
2
Thank you for purchasing a Cambo product
The Cambo CS system complies with the “Arriex
®
15mm Light Weight” standard.
This means the CS system is compatible with parts of other brands using the 15mm
light weight standard. The 15mm light weight standard characteristics are: 15mm iris
rods that are positioned 60mm apart and 85mm below the optical axis.
The Styx-rig is designed as a compact DSLR/DV rig. The handle offset and angle are
adjustable as for the distance between the shoulder pad and DSLR/DV.
Due to the modular character of the Cambo rig system, the user is fully in charge of
customizing the rig to his or her personal preferences.
The Styx-rig can be used with any follow-focus and/or matte box, this rig
configuration centers the weight of the rig on the handle axis.
Warnings
Before loosening a clamp knob, ensure that the loosened part of the rig is
supported.
Do not tighten the clamp without a rod inserted. This can deform and damage
the clamp.
Always check, after (re)assembly of the rig, if the clamps connecting the rods
are well tightened.
Do not lift the rig while holding only one handle. This could lead to excessive
force momentum on the handle joint, causing it to shift.
Instruction Manual CS-
Styx
3
Item check list
Before starting, please check if all items are included in your package. If anything is missing,
contact your dealer.
CS-H1 grip handle compact (2x)
CS-1546 iris rods 460mm (2x), CS-M1 camera/tripod mount (1x), CS-153 triple clamp (1x)
CS-P1 ergonomic pad (1x), CS-152 dual clamp (1x)
CS-1522 iris rod 220mm (1x)
