Pagina 1/12
F U LLFIELD E1
®
R IF L E S C O P ES
User Guide
This user guide includes information for the
entire Fullfield E1 riflescope line. Please review
thoroughly and pay close attention to the
details pertaining to your specific
riflescope model.
FF E1 user guide_Layout 1 /24/15 8:37 AM Page 1
The Fullfield E1® riflescope line combines the
proven optical design of the legendary Burris®
Fullfield riflescopes with the state-of-the-art
Ballistic Plex E1â„¢ reticle, creating a modern optic
with a simple, yet sophisticated, reticle for
supreme accuracy. Your Fullfield E1 includes the
following features:
• Field Proven Reticle Technology. The Ballistic
Plex E1 reticle has both trajectory compensating
technology and cascading dots that can be
used to compensate for wind drift or running
animals. This reticle design is quick, simple and
accurate.
• Low Profile Adjustment Knobs. The finger-
adjustable, low profile E1 Hunter adjustment
knobs create a sleek profile. Knob adjustments
always reflect a change in the point of impact,
resulting in pinpoint accuracy. Dial is resettable
to zero once sighted in.
• High-Performance Glass. Provides excellent
brightness and clarity with lasting durability –
exactly what you expect from Burris.
• Index-Matched, Hi-Lume Multi-Coated
Lenses. Enhanced low-light performance and
glare elimination, making more shots possible
and increasing your success rate.
1
2
FF E1 user guide_Layout 1 /24/15 8:37 AM Page 2
How to Use Your Fullfield E1 Riflescope
Eyepiece Focusing
The eyepiece can be focused so that the reticle
appears sharp and black. Follow this procedure to
quickly adjust the focus:
1. Point the scope at the sky or a plain wall and
take a quick glance through the scope. If the
reticle appears sharp and black, no further
adjustment is necessary.
2. If the reticle does not appear sharp and black,
take quick glances through the scope while
rotating the focus ring until the reticle pattern
is sharp and black.
NOTE: Do not look through the eyepiece as you
turn the focus ring. Your eyes will adjust to the
out-of-focus condition.
Parallax/Focus Adjustment
– Applies to 4.5-14x and 6.5-20x models –
Parallax is the apparent
movement of the reticle in
relation to the target when
the eye is not directly in line
behind the center of the
scope. Images from different
distances focus in front of or
behind the scope’s reticle. Parallax is more
noticeable with higher magnification scopes.
To use the parallax/focus adjustment, rotate the
knob on the left side of the adjustment turret
until the numeral corresponding to the known
target distance lines up with the reference mark.
If the distance is unknown, rotate the adjustment
knob until the target image is sharply focused.
When the scope is set parallax-free for the
distance you are viewing, you should be able to
move your eye side-to-side or up and down
without seeing the reticle move appreciably in
relation to the target.
2
