Pagina 1/9
WARNING
Important Safety Information
1
Replacing Existing Thermostat
Builder Series
Programmable Thermostats
Single Stage Heat / Cool
Conventional and Heat Pump
Multi-Stage 2 Heat / 1 Cool
Conventional and Heat Pump
• Always turn off power to the air conditioning or heating system prior to
installing, removing, cleaning or servicing thermostat.
• This thermostat requires either 24 Volts AC Power or two (2) properly installed
“AA” alkaline batteries for normal operation and control of the heating or
cooling system. Refer to “Low Battery Detection and Replacement” section for
more information.
• This thermostat also requires two (2) properly installed “AA” alkaline batteries
to retain clock setting in the event of loss of AC Power due to a power outage
or rolling blackouts when used as a hardwired thermostat.
• This thermostat should only be used as described in this manual. Any other
use is not recommended and will void the warranty.
Specifications
Installation
Testing Your New Thermostat
Programming User Settings
Setting Your Energy
Saving Program
Temperature Adjustment
Additional Operation
Features
Battery Replacement
Troubleshooting
Wiring Diagrams
1
2
3
4
5
6
7
8
9
10
1
Specifications
• Electrical Rating: 24 Volt AC (18-30 Volt AC)
1 amp maximum load per terminal
2 amp total maximum load (all terminals) (Model 2000, 2000NC)
3 amp total maximum load (all terminals) (Model 2200, 2200NC)
• Control Range: 45˚ - 90˚ F (7˚ - 32˚ C)
• Accuracy: +/- 1˚ F (+/- .5˚ C)
• AC Power: 18-30 Volt AC
• DC Power: 3.0 Volt DC (2 AA Alkaline batteries included)
• Model 2000, 2000NC: Compatibility with low voltage single stage gas, oil or
electric heating or cooling systems, including single stage heat pumps; can
also be used on 250mv to 750mv millivolt heating only systems.
• Model 2200, 2200NC: Compatibility with low voltage multi-stage gas, oil or
electric heating or cooling systems, including multi-stage heat pumps.
• Model 2000, 2000NC Terminations: Rc, Rh, B, O, Y, W, G, C
• Model 2200, 2200NC Terminations: R, O, B, C, Y1, E/W1, G, W2
1
Specifications
cont.
Installation
2
Before Installing, Programming or Operating,
PLEASE READ ALL INSTRUCTIONS
Old Terminal from
Existing Thermostat
New Terminal for
New Thermostat
(2000, 2000NC)
New Terminal for
New Thermostat
(2200, 2200NC)
Terminal
Description
V or Rc Rc Cooling
Transformer
M, 4, Rh, or R Rh Heating
Transformer
R, V-VR or VR-R R 24 VAC
B B B Reversing Valve
(Heating)
O O O Reversing Valve
(Cooling)
Y, Y1 or M Y Y1 Cooling or
Compressor for
HP System
E, H, W, W1 or 4 W E/W1 1st Stage Heat
or Emergency Heat
G or F G G Fan Control
C, X or B C C 24 VAC Common
W1, W2 or W-U W2 2nd Stage Heat
2000
2000NC
2200
2200NC Most thermostats have three parts:
• The cover, which may snap or hinge over the existing thermostat.
• The electronics or body, which controls the existing system.
• The sub-base, where the wires attach through the wall to the existing system.
1. Always turn off power to the air conditioning or heating system prior to
removing existing thermostat.
2.
Carefully remove the cover and electronics body from the old thermostat sub-base.
Depending on the brand, these parts may pull off or need to be unscrewed. The
old sub-base should remain wired and on the wall until steps 4 and 5.
3. Label every old wire with the letter of the connection to which the wire is
attached. Example letters are R, M, Y etc. Depending on the brand of the old
thermostat, your letters may be different.
4. After labeling the old wires, loosen each connection and remove them from old
sub-base. Secure the wires to prevent them from slipping into the hole in the wall.
5. Remove the old sub-base from the wall, again being careful that the wires do
not slip into the hole in the wall.
6. Use the chart below to determine the new thermostat connections. As an
example, if the old thermostat had a G connection, it goes to G on the new
thermostat. Note the chart includes information for Braeburn® 2000, 2000NC,
2200 and 2200NC thermostats. Be sure to use the correct column for the
new thermostat.
2 3
Installing New Thermostat
WARNING!
Read BEFORE Testing
Installation
2cont.
NOTE: If installing this thermostat in a new installation, locate the thermostat
4 to 5 feet above the floor in accordance with applicable building codes. Install the
thermostat in a location that provides good airflow characteristics and avoid areas
behind doors, near corners, air vents, direct sunlight or heat generating devices.
Installation in these areas could impact thermostat performance. Wiring must
conform to all building codes and ordinances as required by local and national
code authorities having jurisdiction.
1. Always turn off power to the air conditioning or heating system prior to
installing thermostat.
2. OFF Place system switch on front of thermostat to the position.
3. AUTO Place fan control switch on front of thermostat to the position.
4. Remove front of thermostat body from sub-base by pressing release latch on
bottom of thermostat.
5. Place the thermostat sub-base against wall in the desired thermostat location.
6. Guide thermostat wires through hole in sub-base and continue to hold
against wall.
7.
Mark placement of mounting holes as appropriate and drill using a 3/16" drill bit.
8. Gently tap supplied plastic anchors into the holes in the wall.
9. Place the thermostat sub-base against the wall in the desired location, making
sure the mounting holes are aligned and the thermostat wires are inserted
through the opening in sub-base.
10. Fasten sub-base to wall using supplied screws.
11.
Connect wires to quick wiring terminal block using the new terminal designations.
Refer to in section 10 of this manual for assistance.Wiring Diagram
12. Make sure all of the wire connections are secure and are not touching
any other terminal to prevent electrical shorts and potential damage to
the thermostat.
13. Turn the front thermostat body over, exposing the rear view of the circuit board.
14. Locate the internal switch on the circuit board. Using your fingers, flip ˚F / ˚C
the switch toward the preferred temperature .˚F / ˚C scale
15. Locate the internal fan option switch, (Gas) / (Elec) on the circuit board. HG HE
This switch controls the heating system fan delay. Select gas for gas or oil fired
systems. This will allow the furnace to run for a few seconds before initiating
the fan. Select electric for electric heat systems that require the fan to come on
immediately. Using your fingers, flip the switch toward (Gas) or (Elec).HG HE
16. Locate the internal / switch on the circuit board. This switch NORM HP
configures the thermostat for conventional (NORM) heating and cooling systems
or heat pump (HP) systems. Using your fingers, gently flip the switch toward
or .NORM HP
17. Attach front body of thermostat to sub-base of thermostat, being careful to
align the terminal pins on the front body with the terminal block on the sub-base.
Installation
2cont.
Testing Your New Thermostat
3
• Do not short (or jumper) across terminals on the gas valve or at the heating or
cooling system control board to test the thermostat installation. This could
damage the thermostat and void the warranty.
• Do not select COOL mode if the outside temperature is below 50˚ F (10˚ C).
This could damage the controlled cooling system and cause personal injury.
• This thermostat includes an automatic compressor protection feature to avoid
potential damage to the cooling system from short cycling. This thermostat
automatically provides a 5-minute delay after turning off the cooling or heating
system output to protect the compressor.
NOTE: Test your thermostat prior to programming any user settings. Pressing the
RESET button will erase any user entries previously programmed and return them
to their default values.
1. Place the system switch in the HEAT position.
2. Press and hold the button on the keypad until the set point temperature setting
is a minimum of 3 degrees higher than the current room temperature. The
heating system should start within several seconds. The fan may not turn on
immediately due to the heating system built-in fan delay.
3. Place the system switch in the position. The heating system should stop OFF
within several seconds with conventional heating or cooling systems. On heat
pump systems you must wait 5 minutes for the automatic compressor short
cycle protection period to expire, or press the button to bypass this RESET
feature for initial testing purposes. Pressing the button will erase any RESET
user program settings.
4. Place the system switch in the position.COOL
5. Press the button on the keypad until the set point temperature is a minimum
of 3 degrees lower than the current room temperature.
6. The cooling system should start within several seconds. Place the system switch
in the position. The cooling system should stop within a few seconds.OFF
7. Place the fan switch in the position. The system blower should start.ON
8. Place the fan switch in the position. The system blower should stop.AUTO
18. Open front thermostat door and open battery compartment door.
19. Install two new "AA" alkaline batteries. Locate the positive (+) ends of the
batteries and match them with the positive (+) terminals located in the battery
compartment. Close battery compartment.
20. Restore system power so you can test installation.
NOTE: If batteries were installed prior to accomplishing steps 14 through 16,
you will need to reset the thermostat to register thermostat switch configurations
prior to programming any user settings. Gently press the button on the RESET
front of the thermostat using a paperclip or a small pencil tip.
NOTE – MODEL 2200, 2200NC:
If the thermostat is configured for a conventional
system and the system switch is in the position, the unit will still function EMER
in a conventional 2 stage HEAT NO AUX SET mode, but the display will flash .
NOTE–MODEL 2000, 2000NC: This thermostat is designed for use with 24
Volt-AC low voltage single stage gas, oil or electric heating or cooling systems,
including single stage heat pumps and can also be used on 250mv to 750mv
millivolt heating only systems. Do not use this thermostat on applications with
voltages above 30 Volts AC.
NOTE–MODEL 2200, 2200NC: This thermostat is designed for use with 24
Volt-AC low voltage multi-stage gas, oil or electric heating or cooling systems,
including multi-stage heat pump systems. Do not use this thermostat on
applications with voltages above 30 Volts AC.
NOTE: COOL HEAT When you place the system switch in the or modes of
operation, the appropriate indicator will also appear in the LCD display when the
system is running. When you place the system switch in the mode, the OFF
display will indicate .OFF
4
Default Thermostat Settings Setting Thermostat User Options
Setting Current Time of Day and Day of Week
5
cont.
Programming User Settings
4
NOTE: It is important for you to set the current time of day (note AM/PM indicator
in display), and the current day of week correctly to avoid problems with
program execution.
1. When in normal operating mode, press the
DAY/TIME keypad button. The LCD display
will be cleared except for the time, am/pm
indicator and the day of the week. The
hour portion of the time will flash. Press
the or button to set the current hour.
2. DAY/TIME Press the button again. The minute portion of the time will flash.
Press the or button to set the current minute.
3. Press the DAY/TIME button again. The day of the week indicator will flash.
Press the or button to set the current day of the week.
4. DAY/TIME Press the button again and the thermostat will return to normal
operating mode.
Programming User Settings
NOTE: The thermostat will return to normal operating mode automatically after
30 seconds if no key is pressed. It will also return to normal operating mode
immediately if the button is pressed.RETURN
The default user options are compatible with most systems and applications.
They are normally set at the time of installation and usually do not require
modification under normal operating conditions. If you wish to change these
settings, simply follow the instructions below.
Setting First Stage Differential
NOTE: The temperature differential settings are the same for both the heating
and cooling systems.
The default setting is 0.5˚ F (0.25˚ C).
The room temperature must change .5˚ F
(0.25˚ C) from the set point temperature
before the thermostat will initiate the
system in heating or cooling.
1. RETURN In normal operating mode, press and hold the button for 4 seconds.
The LCD display will show " ", where " " equals the ˚F / ˚C SET D1 x˚ x
differential setting. This is the current first stage differential setting.
2. Press the or buttons to set the first stage differential to your desired
setting of .5˚, 1˚, or 2˚ F (.2˚, .5˚ or 1˚ C).
NOTE – MODEL 2000, 2000NC: Once you have finished setting the first stage
differential, you can wait 15 seconds and the thermostat will return to the
normal operating mode. Or you can press the button to return to normal RETURN
operating mode.
NOTE – MODEL 2200, 2200NC:
If you do not wish to change the second stage
differential,
wait 30 seconds and the thermostat will automatically return to the
normal operating mode.
Setting Second Stage Differential (Model 2200, 2200NC)
The default setting is 2˚ F (1.0˚ C). The room
temperature must change 2˚ F (1.0˚ C) in
addition to the first stage differential setting
before the thermostat will initiate the
second stage of the system in heating.
1. RETURN SET Press and hold the button again and the LCD display will show “
D2 x˚”, where “ ” equals the ˚F / ˚C differential setting. This is the current x
second stage differential setting.
2. Press the or buttons to set the second stage differential to your desired
setting of 2˚, 3˚, 4˚, 5˚ or 6˚ F (1˚, 1.5˚, 2˚, 2.5˚ or 3˚ C).
NOTE – MODEL 2200, 2200NC: Once you have finished setting the second
stage differential, wait 30 seconds and the thermostat will return to the normal
operating mode.
NOTE: To erase all user program settings, gently press button using a RESET
paper clip or a small pencil tip. This will return all thermostat settings to their
default values, erasing all program settings entered by the user.
4
Function Status After Reset
Operation Mode Normal Operating Mode
Temperature Hold Permanent and Temporary Hold Cleared
Clock 12:00 p.m., Monday
Room Temperature 70˚ F (21.0˚ C), to be renewed within
5 seconds
Set Point Temperature According to System Switch
62˚ F (17.0˚ C) for Heat and Off
83˚ F (28.0˚ C) for Cool
Temperature Scale ˚F or ˚C dependent on switch setting
Operating Program DAY program, Monday
Low Battery Warning Off, to be renewed within 5 seconds
1st Stage Differential 0.5˚ F (0.25˚ C)
2nd Stage Differential 2˚ F (1.0˚ C)
Short Cycle Protection Timer Reset
Output Relays Off
Filter Check Monitor 0 days-off
Extended Hold Indefinite
Adaptive Recovery Mode Off
Product specificaties
Merk: | Braeburn |
Categorie: | Thermostaat |
Model: | 2000NC |
Heb je hulp nodig?
Als je hulp nodig hebt met Braeburn 2000NC stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Thermostaat Braeburn
11 November 2024
11 November 2024
11 November 2024
11 November 2024
Handleiding Thermostaat
- Thermostaat Bosch
- Thermostaat Panasonic
- Thermostaat Bticino
- Thermostaat AEG
- Thermostaat ATAG
- Thermostaat Honeywell
- Thermostaat Junkers
- Thermostaat Nefit
- Thermostaat Remeha
- Thermostaat Siemens
- Thermostaat Vaillant
- Thermostaat ACV
- Thermostaat Agpo Ferroli
- Thermostaat Alecto
- Thermostaat Ambiano
- Thermostaat Amfra
- Thermostaat Arnold Rak
- Thermostaat AVM
- Thermostaat AWB
- Thermostaat Basetech
- Thermostaat Berker
- Thermostaat Boneco
- Thermostaat Brennenstuhl
- Thermostaat Brink
- Thermostaat Bryant
- Thermostaat Buderus
- Thermostaat Bulex
- Thermostaat Daikin
- Thermostaat Danfoss
- Thermostaat De Dietrich
- Thermostaat Devi
- Thermostaat Devolo
- Thermostaat Dimplex
- Thermostaat Drayton
- Thermostaat Drayton Erie
- Thermostaat Easy Timer
- Thermostaat EasyTemp
- Thermostaat EBERLE
- Thermostaat Econo-Heat
- Thermostaat Elco
- Thermostaat Elektrobock
- Thermostaat Elgato
- Thermostaat Eliwell
- Thermostaat Elro
- Thermostaat ELV
- Thermostaat Emerson
- Thermostaat Emmeti
- Thermostaat Enda
- Thermostaat Eneco
- Thermostaat EQ-3
- Thermostaat Eqiva
- Thermostaat Essent
- Thermostaat Etherma
- Thermostaat Eurotronic
- Thermostaat Extraflame
- Thermostaat Ferguson
- Thermostaat Ferroli
- Thermostaat Finder
- Thermostaat GE
- Thermostaat Gira
- Thermostaat Go Green
- Thermostaat Google
- Thermostaat Grasslin
- Thermostaat Grohe
- Thermostaat Hager
- Thermostaat Hama
- Thermostaat Helios (Amfra)
- Thermostaat HomeMatic
- Thermostaat Hornbach
- Thermostaat HQ
- Thermostaat Hugo Muller
- Thermostaat Hunter
- Thermostaat ICY
- Thermostaat Intergas
- Thermostaat IR-V
- Thermostaat Itho
- Thermostaat Itho-Daalderop
- Thermostaat Landis Gyr
- Thermostaat Levica
- Thermostaat Lowes
- Thermostaat Magnum
- Thermostaat Max
- Thermostaat Muller
- Thermostaat Nest
- Thermostaat Netatmo
- Thermostaat Niko
- Thermostaat Nobo
- Thermostaat Noma
- Thermostaat Perel
- Thermostaat Plieger
- Thermostaat Plugwise
- Thermostaat Profile
- Thermostaat Radson
- Thermostaat REMKO
- Thermostaat Renkforce
- Thermostaat RWE
- Thermostaat Salus
- Thermostaat Saunier Duval
- Thermostaat Schneider
- Thermostaat Silvercrest
- Thermostaat Somfy
- Thermostaat Stiebel Eltron
- Thermostaat Sygonix
- Thermostaat Tado
- Thermostaat Taurus
- Thermostaat Techno Line
- Thermostaat Technoline
- Thermostaat Tesla
- Thermostaat TFA
- Thermostaat Theben
- Thermostaat THERMAFLEX
- Thermostaat Thermy
- Thermostaat TP Link
- Thermostaat Trotec
- Thermostaat Truma
- Thermostaat UPM
- Thermostaat Vasco
- Thermostaat VDH
- Thermostaat Velleman
- Thermostaat Viessmann
- Thermostaat Wachendorff
- Thermostaat Watts
- Thermostaat Webasto
- Thermostaat Weishaupt
- Thermostaat Westfalia
- Thermostaat Wolf
- Thermostaat Worcester-Bosch
- Thermostaat Xavax
- Thermostaat Z-Wave
- Thermostaat Zehnder
- Thermostaat Johnson Control
- Thermostaat Jung
- Thermostaat Oertli
- Thermostaat OJ ELECTRONICS
- Thermostaat Orbis
- Thermostaat Oregon Scientific
- Thermostaat Otio
- Thermostaat Schwaiger
- Thermostaat Fenix
- Thermostaat Conrad
- Thermostaat Corberó
- Thermostaat EMOS
- Thermostaat King
- Thermostaat Cotech
- Thermostaat Avidsen
- Thermostaat Hive
- Thermostaat Kemot
- Thermostaat Coati
- Thermostaat Nexa
- Thermostaat SPC
- Thermostaat Baxi
- Thermostaat Aube
- Thermostaat Carrier
- Thermostaat Cepra
- Thermostaat Delta Dore
- Thermostaat ELKO
- Thermostaat Fantini Cosmi
- Thermostaat Heatmiser
- Thermostaat Heimeier
- Thermostaat Horstmann
- Thermostaat IMIT
- Thermostaat Oventrop
- Thermostaat Seitron
- Thermostaat TrickleStar
- Thermostaat Tylö
- Thermostaat Vemer
- Thermostaat Warmup
- Thermostaat Fibaro
- Thermostaat Energenie
- Thermostaat Mikoterm
- Thermostaat Ariston Thermo
- Thermostaat Carel
- Thermostaat Busch-Jaeger
- Thermostaat EVE
- Thermostaat Optima
- Thermostaat Frico
- Thermostaat EQ3
- Thermostaat Homematic IP
- Thermostaat Computherm
- Thermostaat Wattio
- Thermostaat Crestron
- Thermostaat ORNO
- Thermostaat POER
- Thermostaat Heatit
- Thermostaat 2Heat
- Thermostaat Veria
- Thermostaat ThermoSmart
- Thermostaat Yokis
- Thermostaat Vimar
- Thermostaat PECO
- Thermostaat H-Tronic
- Thermostaat Intertechno
- Thermostaat Tru Components
- Thermostaat Emko
- Thermostaat Innogy
- Thermostaat Wallair
- Thermostaat Maico
- Thermostaat HomePilot
- Thermostaat Ouellet
- Thermostaat ChiliTec
- Thermostaat Tellur
- Thermostaat Jumo
- Thermostaat Qubino
- Thermostaat STI
- Thermostaat Gewiss
- Thermostaat Sinustec
- Thermostaat Rose LM
- Thermostaat MundoControl
- Thermostaat Bearware
- Thermostaat GENERAL Life
- Thermostaat Oreg
Nieuwste handleidingen voor Thermostaat
18 November 2024
17 November 2024
16 November 2024
16 November 2024
16 November 2024
16 November 2024
16 November 2024
16 November 2024
16 November 2024
16 November 2024
