QUICK-S UIDTART G E
HAMMERHEAD
FF-2S-QR
F o l l o w F o c u s
Drive gear 43 tooth/0.8 film pitch
Lens gear wrap 152 tooth/0.8 pitch
Rail width 0.5 in. (15 mm)
Lens diameter Max: 100 mm
Min: 20 mm
Dimensions Height: 3.5 in. (8.9 cm)
Max. width: 8 in. (20 cm)
Min. width: 6.5 in. (16.5 cm)
Depth: 3 in. (7.6 cm)
Weight 9.2 oz. (260 g)
SPECIFICATIONS
T H A N K Y O U F O R C H O O S I N G A X L E R .
• Please read and follow these instructions,
and keep this manual in a safe place.
• Make sure that this product is intact and that
there are no missing parts.
• Use only parts provided by the manufacturer.
• Handle the unit with care.
• To avoid damage to this product, be careful
not to overtighten or improperly thread any
of the threaded fittings.
• Clean the unit with a soft, dry cloth.
• Make sure everything is secure before use.
• All images are for illustrative purposes only.
PRECAUTIONS
1. Marking disc: Pull to remove.
2. Focus wheel
3. Stop A: Loosen the screw to adjust.
4. Stop B: Loosen the screw to adjust.
5. Reference marker
6. Stop A/B release:
Lift to release A and B stops.
7. Dual-sided drive
8. Drive gear
9. Drive gear screw: Use a 3 mm hex
wrench to switch the drive gear to the
other side of the dual-sided drive.
10. Width adjustment:
Accommodates lens diameters from
0.78 to 3.9 inches (20 to 100 mm).
11. Width adjustment locking knob
12. Rail mount: Fits most 15 mm
rail systems.
13. Rail mount locking knob
14. Adjustable lens gear: Wraps
around your lens’s focus ring. Make
sure it’s tight to ensure a solid grip.
O V E R V I E W
12
11
1
6
8
9
2
13
10
5
4
3
7
14
