Pagina 1/30

CA-15 BT

Acoustic Amplifier with Bluetooth®

Item ref: 173.012 UK

User Manual

Caution: Please read this manual carefully before operating

Damage caused by misuse is not covered by the warranty

Introduction

Thank you for choosing a Chord CA-15 acoustic guitar amplifier. BT

Ideal for practice and rehearsal, this combo includes a Bluetooth receiver for playing along to tracks from a smart phone.

Please read this manual to gain the best results from your product and avoid damage through misuse.

173.012UK User Manual

Caution

Do not cover cooling vents at the rear of the amplifier. Keep away from damp or dusty environments.

Check mains lead is in good condition and ensure mains outlet voltage is correct as indicated.

Use only approved fuse rated as shown Unplug from mains before replacing fuse. .

No user serviceable parts inside. Refer all servicing to qualified personnel.

Control panel

Operation

Connect your guitar to the input (1) via a 6.3mm jack lead.

If headphones are to be used for silent practice, connect these to the 3.5mm PHONES jack (9)

Turn the VOLUME control (7) . fully down and all other controls to the vertical (12 o’clock) position

Connect to mains power using the supplied mains lead via the rear panel IEC connector and switch POWER on (10)

Gradually turn up the VOLUME control and play until sound is heard through the speaker.

Increase VOLUME to the required level.

Adjust BASS, MIDDLE and TREBLE (2 3 4 controls to achieve the required tone character. , , )

Pressing in the CHORUS ON/OFF button (5) engages the chorus effect, which thickens the sound with a swirling detune

effect. Adjusting the CHORUS control (6) changes the depth of this effect.

For wireless playback of backing tracks from a smart phone, the CA-15BT has a built- Bluetooth receiver. in

Press the BT button (8) in and the indicator will flash. In your phone menu, search for CA-15 and select to pair. “BT”

Once pairing is completed, the indicator will stay on constantly and any tracks played on the smart phone should be

heard through the CA-15BT speaker. Once paired, the CA-15BT will connect to the paired smart phone automatically

whenever Bluetooth is switched on.

Specifications

Power supply

230Vac, 50Hz (IEC)

Output

15Wrms

Speaker

165mm (6.5“)

Controls

Bass, Middle, Treble, Chor , Volume, BT us

Connections

Guitar input, headphones out

Dimensions

310 x 295 x 1 80mm

Weight

4.328 kg

Disposal: symbol on the product means that the product is classed as Electrical or The “Crossed Wheelie Bin”

Electronic equipment and should not be disposed with other household or commercial waste

at the end of its useful life. The goods must be disposed of according to your local council guidelines.

Hereby, A L Group Ltd. declares that the radio equipment type 173.012UK is in compliance with VS Directive 2014/53/EU

The full text of the EU declaration of conformity is available at the following in rnet address: te http://www.avsl.com/assets/exportdoc/1/7/ 2 %20CE.pdf17301 UK

AVSL Group Ltd. Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ

AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland

6.3mm guitar input jack

BASS EQ control

MIDDLE EQ control

TREBLE EQ control

CHORUS effect on/off button

CHORUS depth adjustment

VOLUME control

Bluetooth on/off/pairing button

3.5mm headphones output
