Pagina 1/4

“GREAT SOUND FROM

YOUR FACTORY RADIO!”

TWO CHANNEL LINE OUTPUT

CONVERTER WITH ACCUBASS

FACTORY SYSTE M UP GR A DE

“Maximum Processing with Minimal Eort”

AudioControl’s new Matrix DSP processors

When you require total control and optimization to

achieve great sound quality, AudioControl Digital

Signal Processors are the solution. The powerful

DM-810™ DM-608™ and DSP processors allow users to

truly optimize the performance of their audio system, regardless

of whether they are using a factory or aftermarket source, and

to truly achieve our goal “Making Good Sound Great”. These

highly versatile Digital Signal processors are equipped with

key features, such as active speaker-level inputs, line-level and

digital audio inputs, providing up to 10 channels of output.

AudioControl’s “smart user” interface contains the power

of AudioControl processing through a exible PC interface

packed full of features and simply laid out. Includes signal

summing, 30 bands of equalization, signal time-alignment, in-

put delay and phase correction, plus AudioControl proprietary features like

AccuBASS®, GTO™ Signal Sense, and MILC™ as well as integrated input and output RTA’s.

AccuBASS® Level control

AccuBASS®

Threshold control

3. If you hear a spot where the bass just drops right out…stop.

Leave the volume there and go to your LC2i.

4. Set the AccuBASS Level control on the top of LC2i to the ®

center detent.

5. Now, use a small screwdriver to turn the Threshold control

clockwise slowly until you hear the bass pop back in.

6. Re-adjust the AccuBASS Level control on the top of the unit ®

to get the proper amount of bass compensation, and you’re

ready for some ground pounding bass. OK, what if your bass

doesn’t roll o, but you still want more?

No problem! Turn the AccuBASS Level control fully down, ®

rotate the threshold control fully clockwise to lock in the bass

equalization. Now you can turn up the AccuBASS Level con®-

trol for the amount of bass you want.

Level Matching:

For a video on Level Matching go to:

https://youtu.be/fmR2VrXHfbg or scan the

code at the left.

GTO™ Selector

GTO™ Great Turn On: No need to look for a trigger wire.

However you still need power and ground.

Connect the speaker level inputs and as soon as you turn on

the factory audio system the LC2i will power up as well. After

the LC2i turns on, it provides a 12 volt trigger output to turn

on your amplier. A Jumper which you can reach from the

end panel allows you to set this feature on/o for specialized

installations. The factory default setting for the GTO™ circuit is

always ON.

Setting the AccuBASS® Bass Compensation:

Factory speaker systems have trouble reproducing loud

clean bass. Some companies systems limit the bass at higher

volumes so as not to damage speakers. The AccuBASS circuit ®

puts that bass back.

Here’s how you set it up. After the LC2i /Amps/ and speakers

are installed and ready go:

1. Turn the system on and play some music with a good bass

track.

2. Turn the volume up while listening for the bass.

TWO CHANNEL LINE OUTPUT

CONVERTER WITH ACCUBASS

3. Your LC2i must have originally been purchased from an au-

thorized AudioControl dealer. You do not have to be the original

owner, but you do need a copy of the original sales slip.

4. You cannot let anybody who isn’t (A) the AudioControl

factory; (B) somebody authorized in writing by AudioControl to

service your LC2i

If anyone other than (A) or (B) messes with your LC2i , that

voids your warranty.

5. The warranty is also void if the serial number is altered or re -

moved, or if the LC2i has been used improperly. Now these sound

like big loopholes, but here is all we mean by it.

Unwarranted abuse is (A) physical damage (don’t use the LC2i

for a jack stand); (B) improper connections (120 volts into the

power jack can fry the poor thing); (C) sadistic things. This is the

best mobile product we know how to build, but if you mount it to

the front bumper of your car, something will go wrong.

6. If an authorized United States AudioControl dealer installs

your LC2i, the warranty is ve years, otherwise the warranty is one

year.

Assuming you conform to 1 through 6, and it really isn’t all that

hard to do, we get the option of xing your old unit or replacing it

with a new one.

Validate your warranty: Visit audiocontrolregistration.com to

Legalese Section

This is the only warranty given by AudioControl. This

warranty gives you specic legal rights, which vary from state to

state.

Promises of how well your LC2i will work are not implied by

this warranty. Other than what we’ve covered in this warranty,

we have no obligation, express or implied. Also, we will not be

obligated for direct or indirect consequential damage to your

system caused by hooking up the AudioControl LC2i.

Failure to send in a properly completed warranty card, negates

any service claims.

Specications:

Maximum speaker level input . . .400 watts per channel @4 Ohms

Maximum Preamp output 9.5Vrms/13V peak . . . . . . . . . . . . . . . . . . .

Optional Dash Level Control Remote . . . . . . . . . . . . . . .+0dB / -19dB

Frequency response. . . . . . . . . . . . . . . . . . . . . . . 33 Hz - 100 kHz; ±1dB

Total harmonic distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.01%

Signal to Noise ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >110dB

Input Impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20K ohms

Output Impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150 ohms

Power draw .............................................150 mA

Recommended fuse rating.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Amp

Size (Chassis). . . . . . . . 3.25” x 1.5” x 5.4” (6.5” L including mounting)

Weight 1 pound ................................................

Conditional Warranty

People are scared of warranties. Lots of ne print, lots of

noncooperation, months of waiting around. Well, don’t be scared

of this warranty. It’s designed to make you rave about us to your

friends. It’s a warranty that looks out for you and helps you resist

the temptation to have your friend “who’s good with electronics”

try to repair your AudioControl LC2i. So go ahead and read this

warranty, then enjoy your new component for a few days before

sending in the warranty card and comments.

“Conditional” doesn’t mean anything ominous. The Federal

Trade Commission tells all manufacturers to use the term to indi-

cate that certain conditions have to be met before they’ll honor

the warranty. If you honor these conditions, we will warrant all

materials and workmanship on your LC2i for ve years from the

date you bought it, if installed by an authorized AudioControl

dealer, and will x or replace it, at our option, during that time.

Here are the conditions that make this warranty conditional:

1. We need to know that you bought your product from an

authorized AudioControl dealer. So go to

www.audiocontrol.com or audiocontrolregistration.com right

away, and register your LC2i.

2. You must keep your sales receipt for proof of purchase,

showing when and from whom the unit was bought. We’re not

the only ones who require this, so it’s a good habit to get into

with any major purchase.
