Asrock Z87 OC Formula/ac Handleiding
Asrock
motherboard
Z87 OC Formula/ac
Lees hieronder de 📖 handleiding in het Nederlandse voor Asrock Z87 OC Formula/ac (122 pagina's) in de categorie motherboard. Deze handleiding was nuttig voor 44 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/122
User Manual
Version 1.0
Published May 2013
Copyright©2013 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Website: http://www.asrock.com
e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;
7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &
DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,
DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.
© DTS, Inc., All Rights Reserved.
Product specificaties
Merk: | Asrock |
Categorie: | motherboard |
Model: | Z87 OC Formula/ac |
Bluetooth: | Y |
Wi-Fi: | Y |
Ethernet LAN: | Y |
HDCP: | Y |
Processor socket: | LGA 1150 (Socket H3) |
ECC: | N |
Ethernet interface type: | Gigabit Ethernet |
PCI Express x1 slots: | 2 |
PCI Express x16 slots: | 4 |
Intel® High Definition Audio (Intel® HD Audio): | Y |
Mini PCI Express slots: | 1 |
Non-ECC: | Y |
Supported memory clock speeds: | 1066,1200,1300,1333,1500,1600,1666,1800,1866,1900,2000,2100,2133,2200,2250,2400,2450,2600,2666,2800,3000 MHz |
BIOS type: | EFI AMI |
ACPI version: | 1.1 |
ATX Power connector (24-pin): | Y |
EPS power connector (8-pin): | Y |
Consumer Infrared Headers: | Y |
Clear CMOS jumper: | Y |
Width: | - mm |
Depth: | - mm |
HDMI ports quantity: | 2 |
Headphone outputs: | 6 |
USB 2.0 ports quantity: | 2 |
Ethernet LAN (RJ-45) ports: | 1 |
Cables included: | SATA |
Audio output channels: | 7.1 channels |
Power source type: | ATX |
Certification: | FCC, CE, WHQL, ErP/EuP |
Maximum resolution: | 4096 x 2304 pixels |
Windows operating systems supported: | Y |
Bluetooth version: | 4.0 |
Maximum internal memory: | 32 GB |
Number of memory slots: | 4 |
Processor manufacturer: | Intel |
USB 2.0 connectors: | 2 |
Front panel audio connector: | Y |
PS/2 ports quantity: | 1 |
Microphone in: | Y |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 8 |
Motherboard form factor: | Extended ATX |
Audio chip: | Realtek ALC1150 |
Graphics card: | HD Graphics |
On-board graphics card: | Y |
Drivers included: | Y |
Wake-on-LAN ready: | Y |
Supported storage drive interfaces: | SATA, SATA II, SATA III |
Parallel processing technology support: | 2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 4-Way CrossFireX, Quad-GPU CrossFireX, Quad-GPU SLI |
Cooling type: | Active |
Wi-Fi standards: | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
RAID levels: | 0, 1,5, 10 |
Quick installation guide: | Y |
Motherboard chipset: | Intel® Z87 |
S/PDIF out port: | Y |
Supported memory types: | DDR3-SDRAM |
Memory slots type: | DIMM |
Memory channels: | Dual-channel |
Unbuffered memory: | Y |
Compatible processor series: | Intel Celeron, Intel Pentium |
Maximum number of SMP processors: | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 3 |
Power fan connector: | Y |
CPU fan connector: | Y |
Number of COM connectors: | 1 |
Number of EATX power connectors: | 2 |
Chassis intrusion connector: | Y |
Number of chassis fan connectors: | 5 |
Number of SATA III connectors: | 10 |
Component for: | PC |
Motherboard chipset family: | Intel |
PC health monitoring: | CPU, FAN, Temperature |
Maximum graphics card memory: | 1792 MB |
Graphics card family: | Intel |
Discrete graphics support: | Y |
Processor with Intel Graphics Technology required: | Y |
BIOS switch button: | Y |
PCI Express slots version: | 2.0, 3.0 |
PCI Express configurations: | 1x4, 1x16, 2x8 |
BIOS memory size: | 64 Mbit |
Clear CMOS button: | Y |
