Owner’s Manual
SVT-112AV & SVT-212AV
Speaker Cabinets
SVT-112AV / SVT-212AV Speaker Cabinet
2
Introduction
The Ampeg SVT-112AV and SVT-212AV bass cabinets deliver unmistakable Ampeg tone
in rugged, ported cabinet designs that bridge the gap between the fast transient response
you want and the rich low end you deserve.
The authentic Ampeg round sound is provided courtesy of stamped frame ceramic
12" Eminence® speakers. The lightweight, yet road-worthy professional grade cabinets
are made of 15 mm poplar plywood, have a ported design, vintage AV style cosmetics
and the classic Ampeg clamshell logo.
The rear panel control features two 1/4" inputs wired in parallel for flexible patching
capabilities. Also included is a 3-way level control that allows you to control how much
signal you want to pass on to the HF horn.
Rated at 300W RMS power handling at 8 ohms, the SVT-112AV is a great match with
the PF-350 or Micro-VR or for integrating with other Ampeg cabinets into a single rig.
The SVT-212AV is a 4 ohm cab rated at 600W RMS. This is perfect for the all-new V-4B,
along with other heads like the SVT-CL, SVT-VR or PF-500.
Best of luck in all of your musical endeavors!
Sincerely,
The dedicated team at Ampeg
Features
• CustomEminence® LF driver(s)
• Portedforadditionallow-frequencyextension
• Integratedsidehandle(s)
• AmpegAVfinish[Classicblackgrillesoldseparately]
Important Safety Instructions
1. Read, follow, and keep these instructions. Heed all warnings.
2. This speaker is capable of producing high sound pressure levels that may cause permanent
hearing damage. User caution is advised and ear protection is recommended during use.
3. This speaker is designed for use on a sturdy, level surface. Whenever stacking speaker
cabinets, do not stack more than two high.
4. Speaker cables are a tripping hazard and must be routed out of traffic areas and away from any
possible accidental contact.
5. Donotexposethisspeakertorainormoisture.Donotplaceliquidfilledcontainersonthis
speaker. Clean only with a dry cloth.
6. Repairorserviceofthisspeakershouldbeperformedonlybyqualifiedpersonnel.
Like us
Follow us
Watch our dang videos
SVT-112AV / SVT-212AV Speaker Cabinet
3
12" EMINENCE
8 OHM SPEAKERS
TWO
PARALLEL
JACKS
COMPRESSION
DRIVER
CROSS
OVER
12" EMINENCE
8 OHM SPEAKER
TWO
PARALLEL
JACKS
COMPRESSION
DRIVER
CROSS
OVER
Rear Panel Connector Plate
System Block Diagrams
1. 1/4" TS Full Range Input / Output Jacks: The jackplate features two 1/4" jacks wired
in parallel, allowing easy daisy-chaining from one speaker to another. Each of the jacks
may be used as an input or a through connection.
Connect the speaker-level output of your amplifier to the cabinet’s input jack using a good
quality(non-shielded)speakercable.Never use (shielded) instrument cable to connect
speakers to an amplifier.
You can utilize the unused jack as an output/through jack to connect a second speaker
cabinet in parallel.
2. High Frequency Horn Level Switch: The three-position HF Horn switch allows for:
 •Fullhighfrequencyoutput(0setting)
 •Highfrequenciesreducedby6dB(–6setting)
 •Hornshutoff(offsetting)
SVT-112AV SVT-212AV
SVT-212AVSVT-112AV
HIGH
FREQUENCY
ATTENUATO R FULL RANG E
INPUTS
OFF – 6 0
IMPEDANCE: 4 OHMS
POWER: 600W RMS
SVT-212AV
HIGH
FREQUENCY
ATTENUATO R FULL RANG E
INPUTS
OFF – 6 0
IMPEDANCE: 8 OHMS
POWER: 300W RMS
SVT-112AV
2 2 11
