Akai ABTS-V10 Handleiding

Akai Niet gecategoriseerd ABTS-V10

Lees hieronder de 📖 handleiding in het Nederlandse voor Akai ABTS-V10 (32 pagina's) in de categorie Niet gecategoriseerd. Deze handleiding was nuttig voor 11 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF
Pagina 1/32
EN-ENGLISH
ABTS-V10 Portable Speaker
User Manual
I. Features
1. Portable Bluetooth V5.0 Speaker
2. With Bluetooth, wireless stream music from any Bluetooth-enabled devices such as your mobile phone,
notebook, iPhone or iPad
3. Bluetooth operating range 10 meters
4. TWS function, achieve true wireless Bluetooth playing with double enhanced stereo sound
5. RGB Lighting
6. USB support
7. FM radio- high-quality radio with automatic channel search and storage of up to 30 channels.
8. Line-in function, suitable for PC, TV or other audio devices
9. Built-in lithium rechargeable battery 3.7V 3000mA
10. Carry handle, easy to take out
11. Microphone jack, for Karaoke function (the microphone its not included)
II. Recording function
Recording using a wired microphone (not included):
Connect a storage device (USB/TF card) and short press RECORD key to start recording. During recording,
tune the “-ECHO+” knob to the minimum. It is noticeable that the microphone should be placed in a proper
distance away from the speaker to prevent any howl-round or noise.
Note: This product shows recording time on the display.
III. The Bluetooth pairing operation and related parameters:
1.Power: switch the power ON, press the key “MODE” to enter in Bluetooth mode, and the
display screen will show “BLUE”.
2.Switch on the Bluetooth function on mobile phone and search for available devices , until the mobile
phone shows . The connection doesn`t need any password , if password is requested , please“ ”
ABTS-V10
type ”0000” to go on pairing . After success pairing , the speaker will send out a voice prompt . That
means the pairing between mobile phone and Bluetooth speaker was succesfully made.
3.Now you may play the music from your phone.
IV. TWS function
1. Turn on two identical speakers you want to pair, both under BT mode.
2. Long-press the TWS button until speaker display "BLUE" stop flashing, now both speakers paired
successfully.
EN-ENGLISH
3. Establish Bluetooth connection with your mobile phone to play music by the two paired speakers to create
more powerful surround sound effect.
4. When you want to exit the TWS mode, short-press the “TWS” button again.
V. Functional Operations and Features
1. LED Screen.
2. Master Volume: In USB/TF Card/AUX in/FM/Bluetooth mode, use it to regulate volume output from the
speaker.
3. TF Port: Read audio files in MP3 format in TF card in capacity up to 32G (FAT32).
4. USB Port: Read audio files in MP3 format in USB storage device in capacity up to 32G (FAT32).
5. : In the play status of USB/TF Card/Bluetooth, short press it to select the previous channel. In FM
receiving status, short press it to select the previous channel after a full station search has been
executed.
6. /SCAN: In USB/TF card/Bluetooth reading status, short press it to play/pause, or long press it to
select one of two playback sequencing modes (All - play all tracks in sequence; ONE - repeat one
track). In FM receiving status, long press it to execute a full search (it is recommended to execute at
least one full search before using radio receiving function. All founded stations will be saved even in
power-off). In AUX input / FM radio status, short press it to toggle between mute and normal volume.
7. : In USB/TF card/Bluetooth reading status, short press it to go to the next song. In FM receiving
status, short press it to select the next channel after a full station search has been executed.
8. MODE/TWS: Short press it to toggle between USB/TF/AUX IN/Bluetooth and FM receiving modes.
TWS interconnection mode: open the two machines that need interconnection at the same time, and
switch to Bluetooth mode at the same time. Pair one of them with the mobile phone's Bluetooth to play
music. Long press the play/pause button on the connected machine to exit the connected mode. Long
EN-ENGLISH
press the connected machine to the phone to exit the connected mode directly.
9. ECHO: short press it is Microphone reverberation control button.
10. Recording/DEL: Short press it to enable recording. During recording, reverberation should be tuned to
the minimum. Long press it to delete a recording file. Recording in Microphone mode is available.
11. EQ: In USB/TF/AUX/Bluetooth reading status short press it to select an environment mode (from NOR,
POP, ROCK, JAZZ, CLA, CV ). T
12. : Short press it is light mode button.
13. Microphone volume: Microphone volume regulating knob.
14. Power: Power switch.
15. DC 5V recharging: DC 5V recharging port.
16. Recharging indicator light: When recharger is connected, the red light turns on. When the device is
fully recharged, the blue light turns on.
17. AUX IN: External sound source input port (plug-and-play).
18. Microphone input: Microphone input jack.
VI. Technical specifications
1. Bluetooth version -V5.0
2. Bluetooth channel emission power -0.5Dbm
3. FM Radio frequency -87.5-108MHz
4. SW Radio frequency -100Hz-20KHz
5. AUX in input - 3.5mm
6. USB slot -playing function
7. Power Source -5V
8. Power Consumption -8W
9. Impedance -2Ω
10. S/N Ratio 125db≥
11. Distortion 1%≤
12. Display -LED
13. Charging time - 5 hours
14. Playing time (50% /100% volume) - 4/2 hours
15. Output power -10W
16. Speakers -4”
17. Battery -1* Li-Ion 3.7V, 3000 mAh
