Pagina 1/108
User Manual
AIMB-218
AIMB-218 Intel® Pentium J6426
& Celeron J6412/J6413 &
Celeron N6210/N6211 & Atom
x6413E Mini-ITX HDMI/DP/LVDS
(or eDP), 6 COM, and Dual LAN,
8 USB, 1 M.2 B key and 1 M.2 E
key, PCIe p1-x1
AIMB-218 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2023
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgments
IBM and PC are trademarks of International Business Machines Corporation.
Intel® Pentium/Celeron/Atom J6425/J6413/N6211/x6413E is trademark of Intel Cor-
poration.
Nuvoton is a trademark of Nuvoton Corporation.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product to be defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.
Part No. 2006B21811 Edition 2
Printed in China November 2023
iii AIMB-218 User Manual
Message to the Customer
Advantech Customer Services
Every Advantech product is built with the most exact specifications to ensure reliable
performance in the harsh and demanding conditions typical of industrial environ-
ments. Whether your new Advantech equipment is destined for a laboratory or fac-
tory floor, be assured that your product can provide the reliability and ease of
operation for which the name Advantech is renowned.
Your satisfaction is our primary concern. A guide to Advantech’s customer services is
provided below. To ensure that you receive the full benefit of our services, please fol-
low the instructions below.
Technical Support
We want you to get the maximum performance from your products. Should you
encounter any technical difficulties, we are available to provide assistance. Answers
to the most frequently asked questions are provided in the product documentation.
These answers are typically a lot more detailed than the ones provided over the
phone.
So please consult this manual first. If you still cannot find the answer, gather all rele-
vant information or questions that apply to your problem, and with the product close
to hand, call your dealer. Our dealers are well trained and ready to provide the sup-
port required for you to experience the most from your Advantech products. Most of
the problems reported are minor and can be easily solved over the phone.
In addition, free technical support from Advantech engineers is available every busi-
ness day. We are always willing to give advice on application requirements or specific
information regarding the installation and operation of any of our products.
Declaration of Conformity
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.
