Wolf DF3665S Handleiding

Wolf Fornuis DF3665S

Lees hieronder de 📖 handleiding in het Nederlandse voor Wolf DF3665S (2 pagina's) in de categorie Fornuis. Deze handleiding was nuttig voor 16 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/2

36" DUAL FUEL RANGE - 6 BURNERS

D F 3 6 6 5 0 / S / P

FEATURES

Patented dual-stacked, sealed burners offer precise temperature

adjustment

Burners produce up to 20,000 Btu for fast boils and intense sears and as

low as 300 Btu for true simmers and melts

For improved temperature control and safety, the spark ignition system

reignites burners automatically

Wolf’s Dual VertiFlow™ convection system provides reliably even heat,

reduces hot and cold spots, and enables consistent multi-rack cooking

Gourmet Mode features nearly 50 presets that automatically control the

oven to ensure delicious results

Take the guesswork out of cooking with 10 chef-created cooking modes,

including Bake, Broil, Convection, Convection Roast, Dehydrate,

Gourmet, Proof, Roast, Stone, and Warm

The full-color touchscreen is intuitive and easy to read, discreetly hiding

away when not in use

LED backlit control bezels illuminate when in use, indicating which

burners are active

The oven offers self-clean, delayed start, timed cook, and Sabbath

features

The temperature probe alerts you when your dish has reached the

desired temperature

Control your range from wherever you are using our convenient Owner's

App—remotely preheat, adjust temperatures, select modes, and more

ACCESSORIES

2-Burner Wok Grate

36" Dehydration Rack Set

36" Dual Fuel Brushed Brass Bezel Kit

36" Full-extension ball-bearing oven rack

36" Standard Oven Rack

Bake Stone Kit

Filler Trim

Temperature Probe

Red, black, brushed stainless, brushed brass, and brushed gray knob

kits

Rear Caster Covers

Front Leg Extension Covers

Stainless Steel Kickplates

5" and 10" stainless steel risers, and 20" riser with shelf

Accessories available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

KNO B O PTIO NS

TOP CONFIGURATION

RANGETOP SPECIFICATIONS

• 1 - 9,200 Btu burner

• 2 - 15,000 Btu burners

• 2 - 18,000 Btu burners

• 1 - 20,000 Btu burner

• Stainless-steel island trim

Specifications are subject to change without notice. This information was generated on July 11, 2024. Verify specifications prior to finalizing your cabinetry/enclosures.

36" DUAL FUEL RANGE - 6 BURNERS

PRODUCT SPECIFICATIONS

Model DF36650/S/P

Dimensions 35 7/8"W x 36 1/2"H x 29 1/2"D

Oven 1 Interior

Dimensions

31 1/4"W x 17 1/2"H x 20"D

Oven 1 Usable Capacity 4.1 cu. ft.

Oven 1 Overall Capacity 6.3 cu. ft.

Door Clearance 21"

Electrical Supply 240/208 VAC, 60 Hz

Electrical Service 30 amp dedicated circuit

Gas Supply 3/4" ID line

Gas Inlet 1/2" NPT female

ELECTRICAL GAS

NOTE: Dimensions in parenthesis are in millimeters unless otherwise

specified

DIMENS IONS

STANDARD INSTALLATION

Specifications are subject to change without notice. This information was generated on July 11, 2024. Verify specifications prior to finalizing your cabinetry/enclosures.
