WATERCO POOL HEAT PUMP
WATERCO THERMOPOMPE CHAUFFE-PISCINE
Installation and
Operation Manual
Manuel d’installation
et d’utilisation
This equipment must be installed and serviced by a qualied technician.
Improper installation can create electrical hazards which could result in property damage,
serious injury or death. Improper installation will void the warranty.
Cet équipement doit être installé st réparé par un technicien qualiié.
Une mauvaise installation peut entraîner des risques électriques qui pourraient provoquer
des dommages, des blessures graves ou la mort. Une installation inadéquate annulera la
garantie.
Notice to Installer / Avis à l’installateur
This manual contains important information about the installation, operation and safe
use of this product. Once the product has been installed this manual must be given to
the owner/operator of this equipment.
Ce manual contient des informations importantes sur l’installation, I’exploitation et
l’utilisation sécuritaire de ce produit. Une fois que le produit a été installé, ce manuel doit
être remis à l’acheteur et/ou utilisateur de cet équipement.
FLOW
WARNING
!
ECO-V
IMPORTANT SAFETY INSTRUCTIONS
When using this electrical equipment, basic safety precautions should always be
followed, including the following:
READ AND FOLLOW ALL INSTRUCTIONS
! WARNING: Disconnect all AC power during installation and servicing.
! WARNING: In order to avoid the possibility of hyperthermia (heat stress) occurring
it is recommended the average temperature of the spa - pool water does not exceed
40ËšC.
! WARNING: The pool heat pump is not intended for use by persons (including
children) with reduced physical sensory or mental capabilities, or lack of experience
and knowledge, unless they have been provided supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure they do not play with the appliance.
• In certain situations unexpected start up may occur when the appliance is in
automatic mode.
• The installer should assess the risk associated with unexpected start-up of this
device which, in any circumstance should have no hazardous effect.
• The pool heat pump is not meant to provide safety protection for other devices.
• The pool heat pump should be deactivated if the pool or spa has been drained.
• Waterco pool heat pumps must be installed by a suitably qualified person in
accordance with current Regulatory Standards, the applicable Wiring Rules
(AS3000) and local statutory authority regulations.
• Parts containing live parts, except parts supplied with safety extra-low voltage not
exceeding 12V, must be inaccessible to a person in the spa – pool.
• Parts incorporating electrical components, except remote control devices, must be
located or fixed so that they cannot fall into the spa – pool.
• The appliance should be supplied through a residual current device (RCD) having
a rated residual operating current not exceeding 30mA.
• An Earth terminal is located inside the wiring enclosure. To reduce the risk of
electric shock, this terminal must be connected to the grounding means provided
in the electric supply service panel with a continuous copper wire as sized to
comply with current Standards and local statutory authorities in relation to the
circuit conductors supplying the equipment.
• A cable connector is provided on this unit to connect a suitably sized copper
conductor between this unit and any metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 1.5m of the unit via equipotential
bonding.
SAVE THESE INSTRUCTIONS.
Pool Heat Pump I 02
C
C
C
Cont
ont
ont
ontents
ents
ents
ents
Table of
IMPORTANT SAFETY INSTRUCTIONS ------------- 02
A NOTE TO YOU --------------------------------------- 03
INSTALLATION INSTRUCTIONS --------------------- 05
Location -------------------------------------------- 05
Installation Clearances --------------------------- 06
Water Piping --------------------------------------- 07
Water Flow Rate ---------------------------------- 07
Water By-pass Kit --------------------------------- 07
Plumbing Diagram -------------------------------- 08
Electrical ------------------------------------------- 09
Electrical Connection ---------------------------- 09
Breaker Size --------------------------------------- 09
Electrical Wire Size ------------------------------- 09
Bonding -------------------------------------------- 10
Bonding Diagram --------------------------------- 10
Remote Control Connections ------------------- 11
Usage Of Chemical Products -------------------- 12
OPERATION OF YOUR POOL HEAT PUMP --------- 13
CONTROLLER TYPES
Initial Heating -------------------------------------- 13
Adjustment Of The Bypass Valves ------------- 13
Pool Heat Pump Running Time ----------------- 14
Pool Solar Blanket -------------------------------- 14
Defrost Cycle -------------------------------------- 14
To Start The Pool Heat Pump ------------------- 15
To Stop The Pool Heat Pump ------------------- 15
To Check and Adjust Temperature
Settings -------------------------------------------- 16
Temperature Calibration ------------------------- 17
To Change Display From Farenheit To
Celcius ---------------------------------------------- 18
Defrost for Electroheat Ultra -------------------- 18
Protection Devices -------------------------------- 18
Codes ----------------------------------------------- 18
INVERTER POOL HEAT PUMP CONTROLLER ----- 19
Inverter Controller Operation ------------------------- 20
Timer Function ------------------------------------ 20
Function Descriptions ---------------------------- 21
Buzzer ---------------------------------------------- 21
Memory Function --------------------------------- 21
MAINTENANCE OF YOUR POOL HEAT PUMP ----- 22
Cabinet Cleaning --------------------------------------- 22
Cleaning Evaporator ----------------------------------- 22
Cleaning drainage holes ------------------------------- 22
Units Located In Coastal Locations ------------------ 22
Winterising Procedure --------------------------------- 23
GENERAL SAFETY INSTRUCTIONS -----------------24
TROUBLESHOOTING -----------------------------------25
Nothing Is Working and The
Electronic Control Does Not Operate ---------- 25
Nothing Is Working But The Electronic
Control Temperature Displays Digits
or a Code ------------------------------------------- 25
Fan Doesn’t Work (the fan blades
are not moving) -----------------------------------25
Fan Blades Turn, But Compressor Is Not
Functioning ---------------------------------------- 26
Compressor Starts and Stops ------------------- 26
There Is Water Around The Pool Heat
Pump ------------------------------------------------ 26
Pool Heat Pump Has Ice Formed On The
Evaporator Coil ------------------------------------ 27
Pool Heat Pump Is Functioning, But Does
Not Reach The Desired Temperature
Setting ---------------------------------------------- 27
Analysis Chart ------------------------------------- 28
Circuit Breaker Trips ------------------------------ 28
The Pool Heat Pump Is Noisy ------------------- 29
The Temperature Shown On Pool Heat
Pump Is Not The Same That Is
Shown The Pool Thermometer By -------------- 29
Service Analyser Codes
(Standard Models) -------------------------------- 30
WARRANTY --------------------------------------------- 35
