Viewsonic VPC12-WPO Handleiding

Viewsonic Desktop VPC12-WPO

Lees hieronder de 📖 handleiding in het Nederlandse voor Viewsonic VPC12-WPO (30 pagina's) in de categorie Desktop. Deze handleiding was nuttig voor 38 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/30

VPC12-WPO

Slot in PC module

Quick Start Guid e

Line out

Mic in

HDM I USB3.0

USB2.0RJ45

HDD LED

PWR LED

Power button

3.5 Storage

WIFI AN T Key

Optional Slot in PC

Interface

Install ation

CDE7500 / IFP7500

VPC12-WPO

Slot in PC module

Quick Start Guide

Line out

Mic in

HDMI USB3.0

USB2.0RJ45

HDD LED

PWR LED

Power button

3.5 Storage

WIFI ANT Key

Optional Slot in PC

Interface

Installation

VPC12-WPO_Rev. 1c 07-16-19. Model No. VS17041

CDE7500 / IFP7500

ᳫ▻

http://www.viewsonic.com.cn

⬉䆱˖4008 988 588

桗㳭

http://www.hk.viewsonic.com

䳏䁅˖852 3102 2900

㹱搾

http://www.hk.viewsonic.com

䳏䁅˖853 2833 8407

⊮㼡

http://www.viewsonic.com.tw

䳏䁅˖0800 899 880

한국

http://ap.viewsonic.com/kr/

Tel: 080 333 2131

Singapore/Malaysia/Thailand

http://www.viewsonic.com.sg

Tel: 65 6461 6044

India

http://www.in.viewsonic.com

Tel: 1800-419-0959

United States

http://www.viewsonic.com

Tel: 1-800-688-6688

Canada

http://www.viewsonic.com

Tel: 1-866-463-4775

Europe

http://www.viewsoniceurope.com

Australia/New Zealand

http://www.viewsonic.com.au

Tel: 1800 880 818 (AUS)

0800 008 822 (NZ)

South Africa

http://ap.viewsonic.com/za/

Latin America

http://www.viewsonic.com/la/

Chile

Tel: 1230-020-7975

Mexico

Tel: 001-8882328722

Peru

Tel: 0800-54565

Argentina

Tel: 0800-4441185

Puerto Rico & Virgin Islands

http://www.viewsonic.com

Tel: 1-800-688-6688 (English)

1-866-379-1304 (Español)

Select PC1 on the General Setting

Input Selection

Select OPS from general setting

CDE8600 / CDE9800

IFP6560 / IFP7560 / IFP6530 / IFP7530

CDE7500 / IFP7500 / CDE8600

IFP6560 / IFP7560 / IFP6530 / IFP7530

Warning: You are cautioned that changes or modifications not

expressly approved by the party responsible for compliance

could void your authority to operate the equipment.

Industry Canada ICES-003 Compliance: CAN ICES-3 (B)/NMB-3(B)

Contains FCC ID: PD98260NG

IC ID: 1000M-8260NG

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste

Electrical and Electronic Equipment Directive 2012/19/EU

(WEEE).The mark indicates the requirement NOT to

dispose the equipment as unsorted municipal waste, but

use the return and collection systems according to local law.

Indian Restriction of Hazardous Substances

Restriction on Hazardous Substances statement (India) This product

complies with the “India E-waste Rule 2011” and prohibits use of lead,

mercury, hexavalent chromium, polybrominated biphenyls or polybromi-

nated diphenyl ethers in concentrations exceeding 0.1 weight % and

0.01 weight % for cadmium, except for the exemptions set in Schedule 2

of the Rule.

Compliance Information

NOTE: This section addresses all connected requirements

and statements regarding regulations. Confirmed correspond-

ing applications shall refer to nameplate labels and relevant

markings on unit.

FCC Compliance Statement

This device complies with part 15 of FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept

any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential instal-

lation. This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

• receiver.

• Connect the equipment into an outlet on a circuit different

• from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

• for help.

CE Conformity for European Countries

The device complies with the EMC Directive 2014/30/EU,

Low Voltage Directive 2014/35/EU and

Radio Equipment Directive 2014/53/EU.

Product specificaties

Merk:	Viewsonic
Categorie:	Desktop
Model:	VPC12-WPO
Kleur van het product:	Zwart
Gewicht:	900 g
Breedte:	180 mm
Diepte:	30 mm
Hoogte:	119 mm
Bluetooth:	Ja
Frequentie van processor:	2.4 GHz
Processorfamilie:	Zesde generatie Intel® Core™ i5
Processormodel:	i5-6300U
Aantal processorkernen:	2
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g
Bluetooth-versie:	4.1
Inclusief besturingssysteem:	Windows 10 Pro
Ethernet LAN:	Ja
Geïntegreerde geheugenkaartlezer:	Nee
Processor lithografie:	14 nm
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
Certificering:	cTUVus, FCC, ENERGY STAR 7.0, Mexico Energy, CE, CB, RoHS, ErP, WEEE
Intern geheugen:	8 GB
Opslagmedia:	SSD
Intern geheugentype:	DDR3L-SDRAM
Duurzaamheidscertificaten:	RoHS, ENERGY STAR
Ethernet LAN, data-overdrachtsnelheden:	1000 Mbit/s
Intel® Wireless Display (Intel® WiDi):	Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	LGA 1356 (Socket B2)
Stepping:	D1
Systeembus:	4 GT/s
Processor aantal threads:	4
PCI Express slots versie:	3.0
Processor operating modes:	64-bit
Processor cache:	3 MB
Tjunction:	100 °C
Bus type:	QPI
PCI Express configuraties:	1x4, 4x1
Thermal Design Power (TDP):	15 W
Codenaam processor:	Skylake
Maximaal aantal PCI Express-lijnen:	12
Processor cache type:	Smart Cache
ECC ondersteund door processor:	Nee
Configureerbare TDP-down:	7.5 W
Configureerbare TDP-downfrequentie:	0.8 GHz
Configureerbare TDP-upfrequentie:	2.5 GHz
Configureerbare TDP-up:	25 W
Maximum intern geheugen:	- GB
Totale opslagcapaciteit:	128 GB
Soort optische drive:	Nee
Ingebouwde grafische adapter:	Ja
Aparte grafische adapter:	Nee
On-board graphics adapter model:	Intel® HD Graphics 520
Basisfrequentie ingebouwde grafische adapter:	300 MHz
Graphics on-board -adapter dynamische frequentie (max):	1000 MHz
On-board grafische adapter ID:	1916
Maximaal geheugen ingebouwde grafische adapter:	1.74 GB
On-board grafische adapter OpenGL versie:	4.4
Ondersteunde instructie sets:	SSE4.1, SSE4.2, AVX 2.0
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Smart Response Technology:	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® Turbo Boost Technology:	2.0
Intel® Quick Sync Video Technology:	Ja
Intel® InTru™ 3D Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Intel® Flex Memory Access:	Ja
Intel® AES New Instructions (Intel® AES-NI):	Ja
Enhanced Intel SpeedStep Technology:	Ja
Execute Disable Bit:	Ja
Idle States:	Ja
Thermal Monitoring Technologies:	Ja
CPU configuratie (max):	1
Intel® Enhanced Halt State:	Ja
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID):	Ja
Intel® VT-x with Extended Page Tables (EPT):	Ja
Ingebouwde opties beschikbaar:	Ja
Graphics & IMC lithografie:	14 nm
Intel® Small Business Advantage (Intel® SBA):	Ja
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Clear Video-technologie:	Ja
Intel® Software Guard Extensions (Intel® SGX):	1
Intel® Virtualization Technology (VT-x):	Ja
Verpakkingsgrootte processor:	42 mm
Conflictvrije processor:	Ja
Versie Intel® Identity Protection Technology:	1.00
Versie Intel® Secure Key Technology:	1.00
Versie Intel® Smart Response Technology:	1.00
ARK ID processor:	88190
Intel® Trusted Execution Technology:	Ja
Intel® TSX-NI:	Ja
Intel® Stable Image Platform Program (SIPP):	Ja
Versie Intel® Stable Image Platform Program (SIPP):	1.00
Versie Intel® TSX-NI:	1.00
Maximale turbofrequentie van processor:	3 GHz
Processorcode:	SR2F0
Discreet grafische adapter model:	Niet beschikbaar
Aantal geïnstalleerde SSD's:	1
SSD capaciteit:	128 GB
Type behuizing:	USFF
Maximaal intern geheugen ondersteund door processor:	32 GB
Geheugentypen ondersteund door processor:	DDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor:	1866,2133,1600 MHz
Aantal displays ondersteund (door on-board grafische adapter):	3
Aantal geïnstalleerde processoren:	1
Geheugenbandbreedte ondersteund door de processor ( max):	34.1 GB/s
Inclusief monitor:	Nee
Front-side bus processor:	- MHz
Meegeleverde drivers:	Ja
Processorserie:	Intel® Core™ i5-6300 Mobile Series
Intel® Smart Cache:	Ja
Intel® Small Business Advantage (SBA)-versie:	1.00
Geheugen kanaal:	Dubbelkanaals
Wifi:	Ja
Bedrijfstemperatuur (T-T):	0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Type product:	Mini PC
Processorgeneratie:	Zesde generatie Intel® Core™ i5
