Installation Guide
Note:
1. Make sure the Power Sourcing Equipment (PSE) and PD devices are connected to the corresponding ports properly.
2. The extender supports both Auto-Negotiation mode and 10Mbps mode. In 10Mbps mode, the maximum speed will downgrade to 10 Mbps.
3. The total cable length (a+b) is not recommended to exceed 350m, and the actual transmission distance may vary due to the type and quality of cables, power
consumption of PD devices, voltage at PSE, etc. If a or b ＞ 100m, enable 10Mbps mode rst.
4. If 100m ＜ a ≤ 250m, make sure the PSE supports extend mode.
PoE+ Extender
Connection
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
To ask questions, find answers, and communicate with TP-Link users
or engineers, please visit https://community.tp-link.com to join
TP-Link Community.
© 2023 TP-Link 7106510213 REV1.0.0
PSE
(e.g. PoE Switch, PoE Injector)
PoE+ Extender
Powered Device (PD)
a (100/250m) b (100/250m)
Power LED Explanation
On: Supplying p er normallyow
No p er supplyow
Safety Information
Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
This product can be powered only by p er supplies that comply with ow
Power Source Class 2 (PS2) or Limited P er Source(LPS).ow
Please read and follow the ab e safety information when operating the device. ov
We cannot guarantee that no accidents or damage will occur due to improper
use of the device. Please use this product with care and operate at your own risk.
A:
Only PSE and PD devices compliant with IEEE 802.3 af/at can function well
with the extender. Do not use the extender with other devices to extend the
data transmission distance only.
Q1. Which devices can work normally with the extender?
A1: Ensure your network cable is in good condition.
A2: Ensure both PSE and PD devices are connected to the correct ports.
Q2. Why is the Power LED not lit?
FAQ
Q3. When should I enable the 10Mbps mode?
A: If you want to extend the transmission distance between the extender and
Ports
IEEE 802.3i, IEEE802.3uStandards
PWR
UTP/STP of Cat. 5E or ab e (based on the standards that the ov
connected devices comply with)
LED
Cable Type
Gener cationsal Speciîž®
1*10/100 Mbps Auto-Negotiation RJ45 PoE IN Port
1*10/100 Mbps Auto-Negotiation RJ45 PoE OUT Port
EU Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directives 2014/30/EU,
2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/ce.
UK Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of the Electromagnetic Compatibility
Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK Declaration of Conformity may be found at
https://www.tp-link.com/support/ukca
PoE Input Compliance with 802.3af/at devices
Maximum
PoE Output 20W
Explanation of the Symbols on
the Product Label
Operator’s manual
Caution
For indoor use only
RECYCLING
This product bears the selective sorting symbol for Waste electrical
and electronic equipment (WEEE). This means that this product must
be handled pursuant to European directive 2012/19/EU in order to be
re cled or dismantled to minimize its impact on the environment.cy
User has the choice to give his product to a competent re cling cy
organization or to the retailer when he buys a new electrical or
electronic equipment.
The product label is at the bottom of the product
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
0 C to 45 C (32 F to 113Ëš Ëš Ëš ËšF)
-40 C to 70 C (-40 F to 158Ëš Ëš Ëš ËšF)
10% to 90%RH non-condensing
5% to 90%RH non-condensing
Environmental and Physical Specications

Product specificaties

Merk: TP Link
Categorie: Niet gecategoriseerd
Model: TL-POE10E
