Pagina 1/2

7106510322 REV1.0.2

Power On

Quick Installation Guide

Range Extender

Next to

Solid Blue

Relocate

Set Up

1. Plug in the extender about between your router and the Wi-Fi dead halfway

zone. The location you choose must be within the range of your router.

2. Wait for about 2 minutes until the LED turns solid blue. If it doesn't,

relocate the extender closer to the router to achieve better signal quality.

Enjoy!

Connect your devices to the extender wirelessly, then enjoy the internet.

The password of your extended network is the same as your main router.

Router Devices

Halfway

Via the Tether App

1. Get the up-to-date Tether app from the

Apple App Store or Google Play, or simply

scan the QR code.

Via the Tether App

4. Follow app instructions to complete the setup.

The LED should turn solid on (blue or red)

for over 30 seconds, indicating successful

connection to your router.

Note: If the LED does not turn solid on, please refer to

FAQ > .Q2

2. Launch the Tether app and log in with your

TP-Link ID. If you don’t have an account,

create one first.

Welcome to Tether

TP-Link ID (Email)

Password

3. Tap the button and select .Range Extender

Tether

Scan for Tether

Note: If you cannot find your device, please refer to

FAQ > .Q1

For more details, please refer to the user guide at

https://www.tp-link.com/support/download.

More Setup Methods

Via a Web Browser

1. Connect your computer or smartphone to

the extender’s network TP-Link_Extender.

2. Visit http://www.tplinkrepeater.net or

http://192.168.0.254 in a web browser.

Create a password to log in.

3. Follow web instructions to complete the setup.

2. Within 2 minutes, press the WPS button on

the extender for 1 second. The LED should

change from pulsing blue to solid blue,

indicating successful connection.

1. Press the WPS button on your router.

Via the WPS Button

3. If the extender connects to a dual band router,

repeat steps 1 and 2 to connect to the other

band.

Extended Network Names:

Router’s network name with

EXT

at the end

Same as your EasyMesh router

(See back for EasyMesh details)

Passwords:

Same as your router

* Images may differ from your actual product.

Plug the extender into a power outlet next to your router. Wait until

the LED turns solid blue.

Tip: To place the extender for optimal Wi-Fi performance, access extender settings

via the Tether app and go to Tools Location Assistant> , or simply scan the QR code

to visit https://www.tp-link.com/support/faq/3103/.

Mount

Method 1: Via 3M adhesives*

1. Tear off the protective paper from the 3M

adhesives on the back of the extender.

My Devices

No devices found.

Choose Your Device Type

Wireless Router

Gaming Router

Range Extender

Solid On

Solid Blue: Suitable location

Solid Red: Too far from router

Note: The back area of the extender is used for heat dissipation. It works best when the extender is mounted on a wall.

2. Adhere the extender vertically to a flat surface

that is out of children’s reach.

3M adhesives

Caution: Double-sided tape may

damage the wall or leave adhesive

residue on the wall when removed.

Method 2: Via mounting bracket

1. Mount the bracket on the wall in the correct

direction with the two provided screws.

2. Attach the extender on the bracket as shown below.

Tip: You can use the

included spirit level to

help install the bracket

horizontally.

The air bubble in the

level is centered.

Anchor

Screw

Caution, Hot Surface

When the extender is working, the temperature on its

back is high. Do not touch the extender with bare

hands, and do not stick or directly mount it to

wallpaper, paper, wood, glass, non-heat-resistant

paint, foam board, flammable and explosive materials,

etc, to avoid burns, discoloration, breakage or other

accidental injury.

It is recommended to mount the extender to flat

and smooth painted walls, tile walls, and other

objects. Do not stick it on metal surfaces, so as not

to shield the wireless signal.

Notes:

1. Do not mount the extender until it is connected and relocated to a suitable location.

2. The extender can be powered by a USB Type-C PD fast charger.

3. For more information about LED statuses, see on the back page. LED Explanation

*Two extra 3M adhesives are provided

for future use.

The extender should be used within a temperature

range of 0°C-40°C.

Note: This equipment shall be

installed at a height of less than

2 meters.

Q1. What should I do if the Tether app cannot nd my device during

setup?

Try another method by following the steps below:

1. Connect your smartphone to the extender’s network .TP-Link_Extender

2. Launch the Tether app, and select your extender.

3. Follow app instructions to complete the setup.

If you are still having problems, contact our technical support.

Q2. What should I do if the LED doesn’t turn solid on after

completing setup via the Tether app or web browser?

You may have entered incorrect Wi-Fi password for your main router during the

conguration. Check the password and try again.

Make sure the extender is close to your router, preferably within 16 feet, and away

from large electrical appliances.

If you have enabled wireless MAC ltering, wireless access control, or access

control list (ACL) on your router, disable them rst, then follow any method on the

front page to complete the conguration.

Try setting it up via the WPS button.

Reset the extender and go through the conguration again.

If you are still having problems, contact our technical support.

Tip: If you have connected to the extender’s Wi-Fi but still cannot nd your device, try turning o

your cellular data.

You can experience strong, stable, and seamless wireless connections throughout your home with EasyMesh, a whole home mesh standard that works across dierent

access points for ultimate exibility.

EasyMesh-Compatible

One-Click Settings

Within 2 minutes, press the WPS button on the main router and the extender, then the

EasyMesh network is all set up. TP-Link extenders in factory settings can be connected to

form an EasyMesh network directly without any redundant setup.

Seamless Roaming

Connects mobile devices to your routers or extenders that provide the best coverage. Devices

compatible with EasyMesh also share a single Wi-Fi name so you stay connected in every room.

Flexible Scalability

Flexibly scale your home networking with dierent vendors,* dierent topologies, dierent

Protocols and dierent product categories.

*Failure may occur due to rmware conicts of dierent vendors. A better network connection can

be established between all APs from TP-Link.

For more information, visit

https://www.tp-link.com/easymesh/.

IN T ER N E T

SAME

Network Name & Password

for seamless roaming

Method 1: Via the Tether App

1. Connect your smartphone to the extender‘s or router’s network.

2. Launch the Tether app, select your extender, and log in.

3. View or change extender settings as needed.

Access Extender Settings

After setup, you can access extender settings via any of the methods below.

You can reselect main network, change extended network settings and more.

Note: If your extender and router use the same network name, is recommended.Method 1

Wi-Fi

TP-Link_Extender

CHOOSE A NETWORK...

< Settings

My Devices

Local Device

RExxx

XX-XX-XX-XX-XX-XX

Q3. How do I reset the extender?

With the extender powered on, use a pin (provided) to press the button for RESET

5 seconds to reset the extender to its factory default settings.

TP-Link hereby declares that the device is in compliance with the essential requirements and other

relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.

The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce

TP-Link hereby declares that the device is in compliance with the essential requirements and other

relevant provisions of the Radio Equipment Regulations 2017.

The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca

For technical support, replacement services, user manuals and other information,

please visit https://www.tp-link.com/support, or simply scan the QR code.

To communicate with TP-Link users or engineers, please join the TP-Link Community

at https://community.tp-link.com.

Safety Information

• Keep the device away from water, re, humidity or hot environments.

• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.

• Do not use the device where wireless devices are not allowed.

• Do not use damaged charger or USB cable to charge the device.

• Do not use any other chargers than those recommended.

• Adapter shall be installed near the equipment and shall be easily accessible.

Please read and follow the above safety information when operating the device. We cannot

guarantee that no accidents or damage will occur due to improper use of the device. Please use this

product with care and operate at your own risk.

If you need more setup help, please visit

https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.

AX3000 Wi-Fi 6 Air Range Extender Archer Air E5Model:

Tether

Method 2: Via a Web Browser

1. Connect your computer or smartphone to the extender’s network

If you are

using a computer, unplug the Ethernet cable if any.

2. Launch a web browser, enter http://www.tplinkrepeater.net in the address

bar, and log in.

3. View or change extender settings as needed.

http://www.tplinkrepeater.net

LED Explanation

LED Status Indication

The extender is connected with a weak signal. Try

relocating it closer to your router.

Solid red

The extender is connected to the router’s wireless network

and is in a suitable location.

Solid blue

The extender is not powered or not powered by a standard

power source.

O

WPS Connection is in progress

Scan for Setup Video

Slowly

pulsing blue

Slowly

pulsing red

The extender is not connected to the router’s wireless

network.

The system is starting up or rmware upgrade is in progress.

Quickly

pulsing blue

Quickly

pulsing red

WPS connection failed. The extender will return to

unconnected status in one minute.
