Pagina 1/4
GO SOLO
High-Denition Audio/MIDI Interface for Mobile Devices
Connect GO SOLO to a computer, phone or
tablet using the included cables. If using the
provided lightning cable, insert a pair of AA
batteries to power GO SOLO, or connect a 5V power
supply (not included) to power GO SOLO and charge
your iOS device.
Connect microphone, instrument or line-level
source to the input using XLR or ¼" cables.
Plug a pair of headphones into the HEADPHONE
output. Set LEVEL control to minimum to start.
To enable phantom power move the 48 V
power switch to the ON position. The 48 V LED on
the front panel will light blue.
While speaking into the microphone or playing
your instrument, turn up the GAIN wheel. The SIG
LED should light green to indicate a signal present.
If the SIG LED lights red, turn the GAIN wheel down
to avoid clipping.
Connect MIDI devices to the mini 2.5 mm input
and output jacks using the included adapter cables.
Download your favorite TC Helicon app to
begin experimenting with eects.
Quick Start Guide
Getting started
Analog Connections
Microphone 1 x XLR balanced
Impedance approx 2.3 k
Instrument input 1 x ¼" TS unbalanced
Impedance approx 470 k
Headphones 1 x ⁄" TRS, stereo
Digital Connections
Mobile device / computer Mini USB 10 pin
Driver USB Audio 1.0 Class Compliant
Controls
Input gain 0 to +50 dB, adjustable
Phantom power O / on, switchable
Voltage +48 V
MIDI
Connectors 2 x 2.5 mm (cables included)
System Processing
A/D – D/A conversion 24-bit @ 44.1 kHz, 48 kHz
Frequency response 20 Hz to 20 kHz, +0/-3 dB
Dynamic range > 98 dBA
Power
Power source USB bus power, DC power supply, battery power
Power supply 5 V DC, ≥2.5 A, center positive (not included)
Batteries 2 x AA (included)
Dimensions / Weight
Dimensions (H x W x D) 40 x 45 x 128 mm (1.6 x 1.8 x 5")
Weight 0.28 kg (0.62 lbs)
Specications FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: Music Tribe Commercial NV Inc.
Address: 5270 Procyon Street
Las Vegas, NV 89118
USA
Phone Number: +1 702 800 8290
GO SOLO
This equipment has been tested and found to comply with the limits for a ClassB digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
TC Helicon
GO SOLO
Music Tribe accepts no liability for any loss which may be suered by any person who relies
either wholly or in part upon any description, photograph, or statement contained herein.
Technical specications, appearances and other information are subject to change without
notice. All trademarks are the property of their respective owners. Midas, Klark Teknik,
Lab Gruppen, Lake, Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera,
Auratone and Coolaudio are trademarks or registered trademarks of Music Tribe Global
Brands Ltd. © Music Tribe Global Brands Ltd. 2019 All rights reserved.
For the applicable warranty terms and conditions and additional information regarding
Music Tribe’s Limited Warranty, please see complete details online at musictribe.com/warranty.
Zhongshan Eurotec Electronics Limited
No. 10 Wanmei Road, South China Modern Chinese Medicine Park, Nanlang Town, 528451,
Zhongshan City, Guangdong Province, China
LEGAL DISCLAIMER
LIMITED WARRANTY
