4-593-103-11 (2)
© 2016 Sony Corporation
Data
Projector
Operating Instructions
Before operating the unit, please read this manual and supplied Quick Reference Manual
thoroughly and retain it for future reference.
VPL-DX270/DX240/DX220
VPL-DW240
Not all models are available in all countries and area. Please check
with your local Sony Authorized Dealer.
2Table of Contents
Table of Contents
Overview
Location and Function of Controls .... 3
Main Unit ..................................... 3
Terminal Panel .............................. 4
Remote Commander and Control
Panel Keys ................................. 5
Preparation
Connecting the Projector ................... 7
Connecting a Computer ................ 7
Connecting a Video equipment .... 8
Connecting to an external
device ........................................ 9
Supplying the power to the external
device ........................................ 9
Projecting an Image
Projecting an Image ......................... 10
Adjusting the Projected image ... 11
Turning Off the Power ................ 15
Adjustments and Settings
Using a Menu
Using a MENU ................................ 17
The Picture Menu ............................. 18
The Screen Menu ............................. 19
The Function Menu .......................... 23
The Operation Menu ........................ 24
The Connection/Power Menu .......... 25
The Installation Menu ...................... 27
The Information Menu ..................... 28
Others
Indicators ..........................................29
Messages List ...................................31
Troubleshooting ................................32
Replacing the Lamp ..........................34
Cleaning the Air Filter ......................36
When Using the Projector by Mounting
It to a Ceiling ................................37
Removing the lens cap ................37
Attaching the dust cover .............37
Cleaning the air filter and its
surroundings ............................38
Carrying the unit ...............................38
Specifications ...................................39
Projection Distance ...........................44
Dimensions .......................................49
Index .................................................52
3
Location and Function of Controls
Overview
BOverview
Location and Function of Controls
aFocus ring (page 11)
bZoom ring (page 11)
cLens
dRemote control detector
eFoot adjust button (page 13)
fFront foot (adjustable) (page 13)
gAir filter cover/Ventilation holes
(intake) (page 36)
hRear feet (page 13)
iVentilation holes (exhaust)
Do not place anything near the ventilation
holes as this may cause internal heat
buildup. Do not place your hand near the
ventilation holes and the circumference as
this may cause injury.
jLamp cover (page 34)
kTerminal panel (page 4)
lSecurity bar
Connects to a commercially available
security chain or wire.
mSecurity lock
Connects to an optional security cable
manufactured by Kensington.
For details, visit Kensington’s web site.
http://www.kensington.com/
nControl panel keys (page 5)
oVentilation holes (intake)
pSpeaker
qWARNING indicator (page 29)
rON/STANDBY indicator
(page 29)
Main Unit
5
qg
4
3
2
1
qg
6
7
8
9
qh
qa
qs
0
qd
q
f
qj
qk
qg
Caution
