Pagina 1/8
manual
Unleash headphone’s full potential
3
3
3
333
SPECFICATION
Unleash headphone’s full potential
INTRODUCTION
For audiophiles, getting the most out of their high-end headphones is more than just about getting
the best source or music format. High-end headphones often have higher resistance so if the equipment
connected to them are subpar, the sound quality will suffer. With the Ensemble EB03, SilverStone aims
to provide the power and quality necessary to unleash the full potential of headphones.
EB03’s excellent sound amplification is produced by its internal studio-quality IC (integrated circuit)
with premium Op-amp, current buffer, and enhanced power delivery. For discerning users, it also has an
extra bypass connection for use with an additional amplifier or receiver. Finished with classic aluminum
design that defines SilverStone’s longstanding tradition of excellent metal works, the EB03 is the perfect
companion to high quality headphones.
Besides using the EB03 on its own, users may also pair it with SilverStone’s own similarly styled
EB01-E DAC to create a great looking, and sounding computer audio system!
FEATURES
Premium amplifier designed to deliver full sound to headphones
Classic SilverStone Ensemble exterior design
Extra RCA bypass connection included for easy pairing with additional device
Studio-quality IC with THAT 1646W16-U & 1512S14-U
Independent volume control knob
ITEM
Model
Color
Material
Overall Dimension
Dimension w/o knob & feet
Input
Output
IC
Headphone resistance
SST-EB03B (black) SST-EB03S (silver)、
Black or silver
Aluminum top cover, SECC steel chassis
152mm (W) x 82mm (H) x 176mm (D), 2.19 liters
152mm (W) x 55mm (H) x 156mm (D), 1.30 liters
RCA
φ6.3mm standard stereo connector, RCA connector
(for bypass)
THAT 1646W 16-U & 1512S14-U
16-600 ohm
VALUE
RCA IN
L R
,
MENU
ADAPTER
1.
Installation steps
Connect sound source to RCA connectors labeled “IN” on the EB03
using the included RCA cable or RCA to 3.5mm adapter.
Verbinden Sie die Audioquelle mit dem RCA-Anschluß mit der Aufschrift „IN“
am EB03 unter Nutzung von einem RCA-Kabel oder einem RCA zu 3,5mm - Adapter.
Connectez la source sonore aux connecteurs RCA de l'EB03 marqués "IN"
en utilisant le câble RCA ou l’adaptateur RCA vers 3.5mm fournis.
Conecte la fuente de sonido a los conectores RCA marcados “IN” en
el EB03 usando el cable RCA incluido ó el adaptador RCA a 3,5mm.
Collegare la fonte audio ai connettori RCA denominati “IN” sull’EB03 usando
il cavo RCA incluso o RCA a un adattatore di 3.5mm.
Подключите источник звука к меченому разъему ВХОД на с RCA " " EB03
помощью прилагаемого кабеля или до мм адаптером RCA RCA 3,5 .
附属のRCAケーブルまたはRCA-3.5mmアダプタで、サウンドソースをEB03側の
「IN」というラベルの付いたRCAコネクタに接続します。
RCA케이블을 포함 또는 RCA를 사용하여 사운드 소스를 EB03에 “IN”
이라고 표기된 RCA 컨넥터에 연결하고3.5mm 접합기에 연결.
使用隨附RCA線或RCA 轉3.5mm 插孔轉接線，接上訊源
（後方標示為IN的RCA插座）。
使用随附RCA线或RCA 转3.5mm 插孔转接线，接上讯源
（后方标示为IN的RCA插座）。
2.
Connect the included AC adapter to EB03’s DC connector.
Verbinden Sie das im Lieferumfang enthaltene Netzteil mit der
Netzgerätebuchse des EB03.
Branchez l'adaptateur secteur fourni au connecteur CC du EB03.
Conecte el adaptador de CA incluido al conector CC del EB03.
Collegare l’adattatore incluso AC al connettore DC di EB03.
Подключите поставляемый адаптер переменного тока ,
к разъему постояного тока EB03.
附属のACアダプタをEB03のDCコネクタに接続します。
포함된 AC 접합기를 EB03의 DC 컨넥터에 연결.
將隨附的變壓器接上（後方標示為DC的插孔）。。
将随附的变压器接上（后方标示为DC的插孔）。
,
MENU
ADAPTER
