Pagina 1/9
Sauter GmbH
Ziegelei 1
D-72336 Balingen
e-mail: info@kern-sohn.com
Phone : +49-[0]7433- 9933-0
Fax: +49-[0]7433- - 9933 149
Internet: www.sauter.eu
Instruction Manual Digital Coating
Thickness Gauge
SAUTER TE
Version 2.0
04/2020
GB
TE- -e-2020 BA
PROFESSIONAL MEASURING
2 - -e-2020 TE BA
GB
Thank you for purchasing a digital coating thickness gauge from SAUTER. We hope
you will be very satised with the high quality of this measuring device and its extensive
functionality. For any questions, wishes and suggestions please do not hesitate to
contact us.
Table of contents:
1. Introduction .................................................................................................... 3
2. Functions ........................................................................................................ 3
3. Technical data ................................................................................................ 3
4. Description of the control panel ................................................................... 5
5. Measuring procedure .................................................................................... 5
6. Adjustment ..................................................................................................... 6
7. Battery replacement ...................................................................................... 7
8. Adjustment Foils ............................................................................................ 7
9. Correct handling of coating thickness measurement with external sensors
7
10. General notes ................................................................................................. 8
11. Restore factory settings ................................................................................ 8
12. Notes ............................................................................................................... 8
TE- -e-2020 3 BA
1. Introduction
1.1 General description
This coating thickness gauge is small, light and handy. Although it has complex and
advanced equipment, it is convenient and easy to use.
Its robustness allows it to be used for many years, provided that all instructions in this
manual are carefully followed.
Therefore please keep them always within reach!
Note: It is strongly recommended to adjust the new meter before rst use, as
described in chapter 6. This will result in a higher measurement accuracy from
the beginning.
2. Functions
"This device complies with ISO 2178 and ISO 2361, as well as DIN, ASTM and BS
standards. This means that it can be used both under laboratory conditions and under
rough environmental conditions "in the eld".
"The F probe is used to determine the thickness of non-magnetic layers, e.g. paint,
plastic, enamelled porcelain, copper, zinc, aluminium, chrome, lacquer layers, etc.
These layers should be on magnetic metals such as steel, iron, nickel etc. This test
method is often used to measure the thickness of galvanised layers, lacquer layers,
enamelled porcelain layers, phosphorescent layers, copper plates, aluminium plates,
alloys, etc.
"The N- measuring probe is used to determine the thickness of non-magnetic and
insulating layers on non-magnetic metals.
It is used to measure anodizations, lacquer layers, glazes, colours, enamel, plastic
layers, powder coating etc. These should be on non-magnetic substrates such as
aluminium, sheet metal, non-magnetic stainless steel and others.
"Manual or automatic switch-o to conserve battery power.
"Two measurement modes: -single and continuous
"Conversion of units metric/imperia
"Wide measuring range and high resolution
"The backlit display allows accurate reading
" Can be connected to a PC for data transfer via RS 232 interface for statistical
purposes. Cable and software are available as optional accessories (ATC-01).
3. Technical data
TE 1250-0.1F
TE 1250-0.1FN
TE 1250-0.1N
Display
4 digits, 10mm LCD display with backlight
Measuring range
0 to 1250 m / 0 to 50 mil (standard) μ
Resolution
0,1 µm (0 to 99,9 µm), 1 µm (over 100)
