Sanus MFLF1 Handleiding


Lees hieronder de 📖 handleiding in het Nederlandse voor Sanus MFLF1 (48 pagina's) in de categorie Niet gecategoriseerd. Deze handleiding was nuttig voor 36 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Pagina 1/48
Texto en español, página 24 Deutscher Text Seiten 30 Svensk text sida 36
中文文字说明请参见第 42
Texte français page 27 Nederlandse tekst op pagina 33
Русский текст: стр. 39 日本語は 45
MFLF1-B2
Universal Large Full-Motion
TV Wall Mount
Compatible with Amazon Fire TVs
INSTRUCTION MANUAL
SANUS.com/3010 SANUS.com/2567
Want to watch a video that shows
how easy this DIY project will be?
Get it right the first time. Height-
Finder™ shows you where to drill.
Our install experts are standing by
to help.
US: +1 (800) 359-5520
EMEA: +31 (0) 495 580 852
UK: +44 (0) 800 056 2853
2
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS
Before getting started, lets make sure this mount is perfect for you!
No
Perfect!
Yes
This mount is NOT compatible. Visit MountFinder.sanus.com or call
US: +1 (800) 359-5520 | EMEA: +31 (0) 495 580 852 | UK: +44 (0) 800 056 2853 to find a compatible mount.
Do you have
all the tools
needed?
1
2
3
4
What is your
wall made of?
110 lb
(49.8 kg)
Ready to begin?
Does your TV
(including accessories)
weigh more than 110
lb (49.8 kg)?
Drywall with
wood studs?
Solid concrete or
concrete block?
Perfect!
Wood Stud Install
Concrete Install
Awl
Pencil Level Stud Finder
Screwdriver
Tape
Measure
7/32 in.
(5.5 mm)
Wood
Drill Bit
Electric Drill
Hammer
1/2 in.
(13 mm)
Socket
Wrench Drill Bit
3/8 in.
(10 mm)
Concrete
Unsure?
Call Customer Service: US: +1 (800) 359-5520 |
EMEA: +31 (0) 495 580 852 | UK: +44 (0) 800 056 2853
CAUTION:
DO NOT install
into drywall
alone
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Also check your TV owners manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact
Customer Service at US: +1 (800) 359-5520 | EMEA: +31 (0) 495 580 852 | UK: +44 (0) 800 056 2853.
CAUTION: Avoid potential personal injury or property damage!
This product is designed for use in wood stud, solid concrete, and concrete block walls - DO NOT install into drywall alone
The wall must be capable of supporting five times the weight of the TV and mount combined
Do not use this product for any purpose not explicitly specified by manufacturer
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
Concrete kit CMK1 (not included)
3
7.87in
200mm
MIN
23.62in
600mm
MAX
7.87in
200mm
MIN
15.75in
400mm
15.75in
400mm
4.74in
120.5mm
6.12in
155.5mm
19.73in
501.2mm
16.00in
406.4mm
21.65in
549.9mm
22.59in
573.9mm
10.24in
260mm
LATERAL SHIFT
12 deg 5 deg
3.13in
79.5mm
SIMULATED 55"
FLAT SCREEN TV
TV INTERFACE
WALL PLATE
TOP VIEW - EXTENDED
3-D
SIDE VIEW - EXTENDED
SIDE VIEW RETRACTED
TOP VIEW - RETRACTED
FULLY ASSEMBLED MOUNT
11.81in
300mm
11.81in
300mm
16.07in
408.1mm
18.32in
465.2mm
23.62in
600mm
MAX
28 deg 28 deg
Dimensions
