LMF219
INSTRUCTION MANUAL
Para Español ver página 10
WE’RE HERE TO HELP
Our live, US-based install
experts are standing by to help.
Call us at:
1-855-734-7805
Get it right the first time!
HeightFinder shows you
where to drill.
Use it now at:
SANUS.com/2850
Want to watch a video that
shows how easy this is?
Watch it now at:
SANUS.com/3064
2
55 lb
(24.9 kg)
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service 1-855-734-7805.
CAUTION: Avoid potential personal injuries and property damage!
This product is designed ONLY to be installed into wood studs, solid concrete or concrete block.
— DO NOT INSTALL INTO DRYWALL ALONE — DRYWALL ALONE WILL NOT HOLD THE WEIGHT OF YOUR TV .
This product is designed for .INDOOR USE ONLY
The wall must be capable of supporting five times the weight of the TV and mount combined.
Do not use this product for any purpose not explicitly specified by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
TV Weight Limit
(including accessories)
DO NOT EXCEED
If your TV (including accessories) exceeds
this weight, this mount is NOT compatible.
Visit SANUS.com or call customer service to
find a compatible mount.
1-855-734-7805
Call Customer Service
1-855-734-7805
Tools Needed
Wall
Construction
ONLY install on
these acceptable
wall types. Drywall alone
will NOT hold
the weight of
your TV.
Unsure?
Wood concretestuds Solid or
concrete block
Perfect!
Wood Stud Install
Concrete Install
Awl
Pencil Level Tape
Stud
Finder
ScrewdriverTape
Measure
Drill Bit
Electric
Drill
Hammer
1/2 in.
(13 mm)
Socket
Wrench
Drill Bit
3/8 in.
(10 mm)
Concrete
CAUTION:
DO NOT install
in drywall alone
Concrete Anchor Kit
#CMK1 is required
(not included)
Contact Customer Service
to inquire about the
CMK1 Concrete Anchor Kit.
7/32 in.
(5.5 mm)
Wood
3
6.89 in
175.1mm
8.21 in
208.5mm
WALL IS ON TOP
WALL IS ON RIGHT WALL IS ON RIGHT
WALL IS ON TOP
SIDE VIEW RETRACTED
3-D
TOP VIEW - EXTENDED
WALL PLATE
TV INTERFACE
SIDE VIEW - EXTENDED
FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED
400mm
15.75 in
MAX
15.75 in
400mm
MAX
75mm
2.95 in MIN
2.95 in
75mm MIN
490.3mm
19.30 in
17.85 in
453.4mm
1.99 in
50.5mm
2.14 in
54.4mm )/$76&5((179
6,08/$7('
50° 50°
15° DOWN
5° UP
19.09 in
484.9mm
Dimensions
BEFORE YOU BEGIN
Remove the stand
from your TV if attached.
Install any accessories
you may have purchased, if they
require TV removal prior to assembly.
The TV is removable for future
accessory purchases.
Soft clean surface
Protect the face
of your TV when laying it
down for installation.
