WASHING MACHINE
Before operating the washing machine, please read this manual
thoroughly, and retain it for future reference.
The Owner’s instructions is for normal use.
Making use of the Owner's Instructions is dependent on your washing machine model.
Owner’s Instructions
WT6500/WT6700/WT7800WT8600/WT8700
PRECAUTIONS 1
CONTROL PANEL 1
DESCRIPTION AND CLEANING OF PARTS 2
INSTALLATION 2
Location 2
Connecting the drain hose 2
WASHING PROCEDURE 3
To Wash 3
To Spin dry 3
To Rinsing 3
Overflow rinse 4
Additional rinse 4
LAUNDRY GUIDE 4
MAINTENANCE 4
TROUBLE SHOOTING 4
SPECIFICATIONS
IF YOU NEED HELP.
Do not hesitate to call your local Samsung Service Center.
They will be pleased to help you. Be sure to give them your name,
address, telephone number and the purpose of the call.
SPECIFICATIONS
DIMENSIONS (WxDxH)
WATER PRESSURE
WEIGHT
EXTRACTION EFFICIENCY
STANDARD QUANTITY
OF WATER
RATING TIME
WT6500/ WT6700
776 x 434 x 920mm
0.05~0.3 MPa
(
0.5 ~ 3.0kg ●f/cm2
)
25 kg
50 %
50l
Washing 1 Hour /
Spinning 15 minutes
WT7800
799 x 476 x 926mm
0.05~0.3 MPa
(
0.5 ~ 3.0kg ●f/cm
2
)
29 kg
50 %
54l
Washing 1 Hour /
Spinning 15 minutes
WT8600/ WT8700
820 x 490 x 980mm
0.05~0.3 MPa
(
0.5 ~ 3.0kg ●f/cm
2
)
30 kg
50 %
65l
Washing 1 Hour /
Spinning 15 minutes
Code No. DC68 -01783A
•Don't use adapter or extension cord to
supply power to your washing machine.
•Don't allow electrical parts to come into contact
with water.
(This may risk electric shock.)
•Don't attempt to repair or reconstruct your
washing machine unit in case of malfunction.
(Ask the nearest Samsung authorized
service center to undertake repairs.)
•Don't expose your washing machine to high
heat (direct sun light) and high humidity.
(Heat can damage the external surfaces.)
•Don't open inner lid until spin tub has
come to a compete stop. Even if spin
tub rotation slows down it can still cause injuries.
•When spinning, always ensure that the the
spinning cap is pressed tightly against the
clothes, maintaining horizontal level.
•Don't put clothes with gasoline, benzene,
thinner, alcohol or other inflammable
substances into the wash tub and the spin tub.
•Don't put hot objects, lighted candles or any
flaming objects on or near the washing machine
as these are fire hazards.
•Don't let sprays (insecticide, perfume etc.)
come in contact with the switch controls.
(It might cause timers to warp or damage
plastic parts.)
•Don't use vinyl chloride covers.
•Don't use detergent in excess of amount
indicated in the package. (This will result in
insufficient rinsing.)
•While the washing machine is in operation, don't
insert hand, foot, or anything under the base.
•Don't step on the washing machine or put heavy
things on it.
•Don't allow children to peep into the wash tub
or spin tub, as it could result in their falling in
and getting injured.
•Don't allow cord to be clamped by the unit or by
other heavy objects.
•When power cord and plug are damaged, contact
the nearest authorized service center to undertake
repairs.
•Unplug the washing machine when not in use.
Pull out the plug and not done by pulling the cord.
Always make sure that your hands are dry.
•Don't use the washing machine if the power cord is
damaged or if the wall mount socket is loose.
•Don't severely twist, bundle, bend or do
anything else that can damage the power cord.
1. WASH SELECTOR
This is used to select wash action.
2.WASH TIMMER
This is used to set the
wash time, 1-15 minutes.
This is used to set
wash time,1-35 minutes
3. CYCLE SELECTOR
This is used to set the
Washing or Draining.
This is used to set the
Washing or Draining,
and to select wash action.
4.SPIN DRY TIMER
This is used to set the
spin time, 1-5 minutes.
5. WATER SELECTOR
During washing,
WATER SELECTOR KNOB
should be selected to Wash.
During spin rinsing,
WATER SELECTOR KNOB
should be selected to Spin.
CONTROL PANEL
PRECAUTIONS
1
0
3
1
42
5
SPIN DRY TIMER
WT6500/6700/7800
WT6500/6700/7800
WT6500/6700/7800
WT8600/8700
WT8600/8700
WT6700/7800/8600/8700
Wa sh/R in se
Dr ain
CYCLE SEL ECTOR
Wa sh/H eav y
Dr ainNo rma l
CYCLE SEL ECTOR
WATER SELECTOR
Wash Spin
WATER SELECTOR
Wash Spin
