Wireless-N Wifi Repeater

Introduction：

Power Indicator

Wireless Indicator

WPS Indicator (Optional)

LAN Indicator

WPS Button (Optional)

RJ45 Port

Reset

Power Indicator

WPS Indicator(Optional)

Wireless Indicator

LAN Indicator

WPS Button(Optional)

RJ45 Port

Reset

English-01

You will need WiFi

AP/Router Internet access

You will need broadband

Router Internet access

Connect the WiFi-Repeater

to your Router/Switch with

RJ-45 Cable

Getting Started

Wireless Repeater Mode

Wireless AP Mode

Before you starting to use this router, please check if

there’s anything missing in the package, and contact

your dealer of purchase to claim for missing items:

· 1 x Wireless-N Repeater

· 1 x RJ-45 Networking Cable

· 1 x Quick installation Guide

Package Contents

For a typical wireless setup at home (as shown below), please do the following:

Setting up a Wireless Infrastructure Network

Wireless-N Wifi RepeaterEnglish-02

Open Source Code

This product includes software codes developed by third parties. These software

codes are subject to either the GNU General Public License (GPL), Version 2, June

1991 or the GNU Lesser General Public License (LGPL), Version 2.1, February

1999. You can copy, distribute, and/or modify in accordance with the terms and

conditions of GPL or LGPL.

The source code should be complete, if you think our need to provide any additional

source code files under GNU General Public License (GPL), please contact us. We

are committed to meeting the requirements of the GNU General Public License

(GPL). You are welcome to contact us local office to get the corresponding software

and licenses. Please inform us your contact details and the product code. We will

send you a CD with the software and license for free.

Please refer to the GNU GPL Web site for further information.

http://www.gnu.org/licenses/licenses.en.html.

The WiFi Repeater is a combined wired/wireless network connection device

designed specifically for small business, office, and home office networking

requirements. It allows a wireless network to be expanded using multiple access

points without the need for a wired backbone to link them. It also works well with

other 11b/g and 11n protocol wireless products.

NOTE: reset

If you need to the Wi-Fi Repeater, you need press and hold the reset

button inside the tiny hole for seconds.

A1. Plug the Wi-Fi Repeater to a wall socket.

How to configure the Wi-Fi Repeater

A2. Click on the network icon ( or )

on the right bottom of your desktop. You will

find the signal from the . Wi-Fi Repeater

Click on ‘ ’ and wait for a few Connect

seconds.

A3. Open web browser and type

http://192.168.10.1 in the browser's

address box. This number is the default IP

address for this device.

Note: Please check whether the WiFi-Repeater accord with factory default settings

once you can’t download If you are still not sure what reasons, http://192.168.10.1.

you can reset the WiFi-Repeater, just need to press the button for seconds,

then try again.

reset 10

You can configure the Wi-Fi Repeater by connecting it with your computer/laptop with

enclosed RJ45 cable or wirelessly.

A. Configure the Wi-Fi Repeater wirelessly.

A4. The login screen below will appear. Enter the “User Name” and “Password”

then click “ ” to login. The default User name is “ ” and Password is “ ”.OK admin admin

A5. RepeaterAfter logging in, you will see the web page below: Click on ‘ ’ to continue.

Wireless-N Wifi Repeater English-03 Wireless-N Wifi RepeaterEnglish-04

Product specificaties

Merk:	Sabrent
Categorie:	Wifi-repeater
Model:	NT-WRPT
Kleur van het product:	Zwart
Stroomvoorziening:	100 - 230
LED-indicatoren:	Ja
Connectiviteitstechnologie:	Bedraad
Frequentieband:	2.4 GHz
Aantal Ethernet LAN (RJ-45)-poorten:	1
Netwerkstandaard:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ondersteunde beveiligingsalgoritmen:	128-bit WEP, 64-bit WEP, WPA, WPA2
Maximale overdrachtssnelheid van gegevens:	300 Mbit/s
Antenne:	Ja
Datalink-protocollen:	IPv4
