With Installation Instructions for the Installer
Noncondensing 199,900 Btu/h, 180,000 Btu/h,
and 160,000 Btu/h Models
Do not destroy manual. Please read carefully and
keep in a safe place for future reference.
CERTIFIED
Print 2D
Bar Code
Here
w w w . a hr i d ir e c t o r y. o r g
ULTRA
Low NOx
Emissions
SCAQMD Rule 1146.2
WARNING:
If the information in these instructions is not
followed exactly, a fire or explosion may result,
causing death, personal injury, or property dam-
age.
For Your Safety!
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or
any other appliance. To do so may result in an
explosion or fire.
• Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
HIGH-EFFICIENCY NON-CONDENSING
TANKLESS WATER HEATER
USE AND CARE MANUAL
What to Do If You Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
• Do not return to your home until authorized by
the gas supplier or fire department.
AP22009 Rev 03
Safety
Important Safety Information
Safety Precautions 2 – 8 ����������������������������������������������������������
Product Information
Product Information 8 ���������������������������������������������������������������
Specifications ������������������������������������������������������������������ 9, 10
Flow Rate vs Pressure Drop RTGH-Series-3 �������������������������11
General Descriptions 12, 13 �������������������������������������������������������
Installation Instructions
Standards Compliance ����������������������������������������������������������15
Choosing a Location ������������������������������������������������������� 15, 16
Product Inspection 17 ���������������������������������������������������������������
Water Heater Installation 17 – 20 ����������������������������������������������
Venting and High-Altitude Adjustments 21 – 34 �����������������������
Water Quality/Supply 35 – 39 ���������������������������������������������������
Gas Supply 39 – 44 �������������������������������������������������������������������
Electrical Wiring ��������������������������������������������������������������������45
Remote Control Selection and Location ��������������������������������46
Remote Control Installation ��������������������������������������������������47
WiFi Remote Installation 48, 49 �������������������������������������������������
Insulation Blankets and Installation Precautions ������������������50
Installation Checklist �������������������������������������������������������������51
Using Your Water Heater
Activating the Water Heater ��������������������������������������������������52
Operating Instructions ����������������������������������������������������������53
Setting the Water Temperature ������������������������������������� 54 – 58
WiFi Set-up ��������������������������������������������������������������������������������������������58
Piping for Space Heaters ������������������������������������������������������59
Recirculation Pump Control 60 – 63 ����������������������������������������
Water Saving Control Option 64, 65 ������������������������������������������
Caring for Your Water Heater
Water Heater Inspections 66, 67 ����������������������������������������������
Care and Cleaning 68, 69 �����������������������������������������������������������
Preventive Maintenance ������������������������������������������������������� 70
Draining the Water Heater – ���������������������������������������������71 72
Freeze Protection 73 �����������������������������������������������������������������
Vacation and Extended Shutdown �������������������������������������� 74
Troubleshooting Chart 74, 75���������������������������������������������������
Service Error Code Chart 76, 77 ����������������������������������������������
Call for Assistance ����������������������������������������������������������������77
Maintenance Notice Option 78, 79 ���������������������������������������������
If You Need Service
Parts Ordering 80, 81 ����������������������������������������������������������������
Warranty Information������������������������������������������������������82, 83
2
CONTENTS
READ THE SAFETY INFORMATION
Your safety and the safety of others are very important. There
are many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
This is the safety alert symbol. Recognize this
symbol as an indication of Important Safety
Information! This symbol alerts you to potential
hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol
and either the word “DANGER,” “WARNING,” “CAUTION,”
or “NOTICE.”
These words mean:
IMPORTANT SAFETY INFORMATION
!
WARNINGS:
• Improper installation, adjustment, alteration, service,
or maintenance can cause death, personal injury, or
property damage. Follow the instructions in this manual.
READ ALL INSTRUCTIONS
BEFORE USING.
Be sure to read and understand the entire Use and Care Manual
before attempting to install or operate this water heater� It may
save you time and money� Pay particular attention to the Safety
Instructions� Failure to follow these warnings could result
in death or serious bodily injury� Should you have problems
understanding the instructions in this manual, or have any
questions, STOP and get help from a qualified service technician
or the local gas utility�
!
DANGER:
NOTICE:
!
CAUTION:
!
WARNING:
!
An imminently hazardous
situation that will result in
death or serious injury.
A potentially hazardous
situation that can result in
death or serious injury and/or
damage to property.
A potentially hazardous
situation that may result in
minor or moderate injury.
Attention is called to observe a
specified procedure or maintain
a specific condition.
Safety
3
D A N G E R
FLAMMABLES
Flammabl pore Va s
Water heater has a main
burner flame.
Th maine burner flame:
1. come which n ca on
at any time dan
2. will ignite flammable
vapors.
Vapors:
1. cannot be seen,
2. ar e heavie thanr air,
3. go a y long wa on the
floor and
4. ca n be carried from
other rooms to the
main burner flame by
air .currents
Vapors from flammable
liquids will explode and
catch fire causing death or
severe burns.
Do not us ore store flammable
products such as gasoline,
solvents or adhesives in the
same room or area near the
water .heater
K :eep flammable products
1. away far from heater,
2. in approved containers,
3. closed tightly and
4. reach ou oft children's .
Installation:
Do not install water heater
wher flammabl productse e will
be stored or used unless the
main burner flame is at least
18 abov" e e th floor. This will
reduce but eliminate,, not the
risk of vapors being d ignite
by main the burner flame.
Read heater and and follow water warnings instructions. If
owners manual missing, the retailer or manufacturer.is contact
Water Heater Venting Safety
!
DANGER:
• Failure to install and properly vent the water
heater to the outdoors as outlined in the
“Venting” section of the Installation Instructions
in this manual will result in death from fire,
explosion, or asphyxiation from carbon
monoxide. NEVER operate this water heater
unless it is properly vented and has an adequate
air supply for proper operation.
• Be sure to inspect the vent terminal, the air intake, and
the coaxial vent system on the water heater for proper
installation at initial start-up and at least annually thereafter.
Refer to the “Care and Cleaning” section of this manual for
more information regarding coaxial vent system inspection.
!
WARNINGS:
• Gasoline and other flammable liquids, materials,
and vapors (including paint thinners, solvents,
and adhesives) are extremely dangerous.
DO NOT handle, use, or store gasoline or other
flammable or combustible materials anywhere
in the vicinity of a water heater or any other
appliance. Be sure to read and follow the labels
on the water heater, as well as the warnings
printed in this manual. Failure to do so can result
in death, bodily injury, or property damage.
• Combustible construction refers to adjacent
walls and ceilings and should not be confused
with combustible or flammable products and
materials. Combustible materials, such as
clothing, cleaning materials, or flammable
liquids, should never be stored in the vicinity of
this or any gas appliance. Fire or explosion can
occur causing death, personal injury, and/or
product damage. See page 16 for clearances to
combustible materials.
• Follow vent manufacturer’s instructions for
venting installation, including additional
clearances from combustibles, to avoid
conditions that can lead to death, personal
injury, and/or property damage.
• Use tankless water heater manufacturer-
approved Category III Stainless Steel vent
material only. No other vent material is
permitted.
• Moisture in the flue gas will condense as it
leaves the vent terminal. In cold weather this
condensate can freeze on the exterior wall,
under the eaves, and on surrounding objects.
Some discoloration to the exterior of the building
is to be expected. However, improper location or
installation can result in severe damage to the
structure or exterior finish of the building.
• For multiple-unit installation, a minimum
distance between vent terminations must be
maintained to prevent recirculation of vent gases.
Maintain a center-to-center distance between
vent terminations of 19 in. (48 cm) for two-unit
installation. Maintain a center-to-center distance
between vent terminations of 21 in. (53 cm) for
installation of three or more units.
!
CAUTIONS:
• Ensure that the appliance vent is securely
attached to the water heater collar.
• Condensate must drain away from the water
heater and should not be allowed to drain back
into any part of the vent system.
• DO NOT operate without the condensate trap
connected to the vent and routed to the proper
drain.
• Follow the vent manufacturer’s installation
instructions because the design might vary from
manufacturer to manufacturer.
IMPORTANT SAFETY INFORMATION
Product specificaties
Merk: | Rheem |
Categorie: | Ketel & boiler |
Model: | RTG-84DVLN-3 |
Heb je hulp nodig?
Als je hulp nodig hebt met Rheem RTG-84DVLN-3 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Ketel & boiler Rheem
11 November 2024
11 November 2024
11 November 2024
11 November 2024
11 November 2024
11 November 2024
11 November 2024
11 November 2024
20 Februari 2024
16 Februari 2024
Handleiding Ketel & boiler
- Ketel & boiler Electrolux
- Ketel & boiler Bosch
- Ketel & boiler Philips
- Ketel & boiler Panasonic
- Ketel & boiler AEG
- Ketel & boiler ATAG
- Ketel & boiler BEKO
- Ketel & boiler Inventum
- Ketel & boiler Junkers
- Ketel & boiler Nefit
- Ketel & boiler Remeha
- Ketel & boiler Siemens
- Ketel & boiler Vaillant
- Ketel & boiler Whirlpool
- Ketel & boiler A.O. Smith
- Ketel & boiler ACV
- Ketel & boiler Adler
- Ketel & boiler Arcelik
- Ketel & boiler Atlantic
- Ketel & boiler AWB
- Ketel & boiler Buderus
- Ketel & boiler Buffalo
- Ketel & boiler Bulex
- Ketel & boiler Burco
- Ketel & boiler Daalderop
- Ketel & boiler Daikin
- Ketel & boiler De Dietrich
- Ketel & boiler Dimplex
- Ketel & boiler Dometic
- Ketel & boiler Easypix
- Ketel & boiler Eccotemp
- Ketel & boiler Edilkamin
- Ketel & boiler Elco
- Ketel & boiler ETA
- Ketel & boiler Fagor
- Ketel & boiler Fakir
- Ketel & boiler Ferroli
- Ketel & boiler Franke
- Ketel & boiler GE
- Ketel & boiler Gorenje
- Ketel & boiler Haier
- Ketel & boiler Hisense
- Ketel & boiler Hitachi
- Ketel & boiler Hotpoint
- Ketel & boiler Intergas
- Ketel & boiler Kelvinator
- Ketel & boiler La Nordica
- Ketel & boiler LEMET
- Ketel & boiler Midea
- Ketel & boiler Morco
- Ketel & boiler Nibe
- Ketel & boiler Plieger
- Ketel & boiler Qlima
- Ketel & boiler Quantum
- Ketel & boiler Quooker
- Ketel & boiler Rommelsbacher
- Ketel & boiler Sencor
- Ketel & boiler Sentry
- Ketel & boiler Solac
- Ketel & boiler Stiebel Eltron
- Ketel & boiler Taurus
- Ketel & boiler Technika
- Ketel & boiler Teka
- Ketel & boiler Thermor
- Ketel & boiler Truma
- Ketel & boiler Viessmann
- Ketel & boiler Waeco
- Ketel & boiler Wahlbach
- Ketel & boiler Wesen
- Ketel & boiler Wijas
- Ketel & boiler Ygnis
- Ketel & boiler Jocel
- Ketel & boiler Camry
- Ketel & boiler Concept
- Ketel & boiler Elba
- Ketel & boiler Guzzanti
- Ketel & boiler Khind
- Ketel & boiler Orbegozo
- Ketel & boiler Vox
- Ketel & boiler Kunft
- Ketel & boiler Aspes
- Ketel & boiler Corberó
- Ketel & boiler Infiniton
- Ketel & boiler Respekta
- Ketel & boiler Svan
- Ketel & boiler Eldom
- Ketel & boiler HTW
- Ketel & boiler Mora
- Ketel & boiler Cata
- Ketel & boiler Tesy
- Ketel & boiler Rommer
- Ketel & boiler Baxi
- Ketel & boiler Worcester
- Ketel & boiler Rinnai
- Ketel & boiler Clage
- Ketel & boiler Cointra
- Ketel & boiler IQE
- Ketel & boiler Keston
- Ketel & boiler Sime
- Ketel & boiler Biasi
- Ketel & boiler Duwaco
- Ketel & boiler Masterwatt
- Ketel & boiler OSO
- Ketel & boiler Ariston Thermo
- Ketel & boiler Cola
- Ketel & boiler TTulpe
- Ketel & boiler Noveen
- Ketel & boiler Joven
- Ketel & boiler Country Comfort
- Ketel & boiler Rheinstrom
- Ketel & boiler Thermoflow
- Ketel & boiler Wagaparts
- Ketel & boiler SolarEdge
- Ketel & boiler LERAN
- Ketel & boiler Dux
- Ketel & boiler Intellihot
- Ketel & boiler Airthereal
- Ketel & boiler IStore
- Ketel & boiler Apricus
- Ketel & boiler Aquamarin
- Ketel & boiler Hydrotherm
- Ketel & boiler Kospel
- Ketel & boiler Amtrol
- Ketel & boiler Neopower
- Ketel & boiler Gleamous
- Ketel & boiler AquaMAX
- Ketel & boiler My-PV
- Ketel & boiler EvoHeat
- Ketel & boiler Mission Air
- Ketel & boiler Solahart
- Ketel & boiler ENEFT
- Ketel & boiler AquaTech
- Ketel & boiler Imarflex
- Ketel & boiler MicroHeat
- Ketel & boiler Noritz
Nieuwste handleidingen voor Ketel & boiler
12 November 2024
5 November 2024
5 November 2024
5 November 2024
3 November 2024
3 November 2024
3 November 2024
3 November 2024
3 November 2024
3 November 2024
