Pagina 1/2

– 1 – – 2 –

– 3 – – 4 –

1. Verify the Contents Inside the

Package Box

The package should contain the following items plus VGW

series.

Model Package Description

VGW-120FS

VGW-220FS

VGW-420FS/420FO

VGW-820FS/820FO

VGW-824

 Quick Installation Guide x 1

 Power Adapter x 1

 RJ11 Cable x 1

 RJ45 Cable x 1

VGW-1620FS/1620FO

VGW-1628

VGW-2420FS

VGW-3220FS

 Quick Installation Guide x 1

 Power Cord x 1

 RJ11 Cable x1

 RJ45 Cable x 1

 RJ45 to RS232 Cable x 1

 Ground Wire x 1

 Rack-mounting Brackets with

Attachment Screws x 1

Note

If any of the above items are damaged or missing,

please contact your dealer immediately.

2. Basic Operation

The VGW series supports basic operation through standard

analog phone set. With an analog phone set, the users can dial

the service codes to maintain their gateway. The service code

list is shown below:

Service Code Operation Notice

*158# Check LAN port IP address

*159# Check WAN port IP address

*114# Check port account

*115# Check port group account

*160*1# Enable Web access through WAN port

*165*000000#

Restore to factory default values of Web

LAN port IP addresses

*166*000000# Restore to default factory settings

*111# Restart device

3.BasicSystemCongurations

The VGW series is easy to install by following the steps below.

Step 1: Connect a computer to a on the VGW LAN port

series. Your PC must be set to 192.168.0.X, the same

domain as that of the VGW series.

Step 2: Start a web browser. To use the user interface, you

need a PC with Internet Explorer (version 8 or

higher), Firefox, or Safari (for Mac).

Step 3: Enter the default IP address of the VGW series:

http://192.168.0.1 into the URL address box.

Step 4: Enter the default user name admin and the default

password admin and then click Login to enter Web-

based user interface.

Default WAN IP 172.16.0.1

Default Subnet Mask 255.255.0.0

Default Gateway 172.16.0.254

Default LAN IP 192.168.0.1

Default Subnet Mask 255.255.255.0

Default Login User Name admin

Default Login Password admin

– 5 – – 6 –

5.FurtherInformation

For more information, please refer to the VGW series user

manual.

https://www.planet.com.tw/en/support/downloads?&method=ke

yword&keyword=VGW&view=2#list

If you have any other question, please contact the dealer

where you purchased this product or you can contact.

PLANET directly at the following email address:

support@planet.com.tw

4. Installation Check

In this step, we should check VGW series when power is on.

But before this, you should ensure that all other things are

done (such as cable connection, and power connection).

Then you can refer to the following steps:

Keep device power on, and check whether the power indi-

cator (PWR) is on or not. If so, it indicates that device’s

power is ready; otherwise, please check the connection of

the power plug or power adaptor.

Check Ethernet port (WAN/LAN) LED status. When port LED

is blinking, it indicates that network is ready. Otherwise,

check network connection.

Check phone port status LED. When device’s (Line) LED is

blinking at the time you pick up the phone and the phone

port LED is on, it indicates telephone port is ready, otherwise

check the telephone connection.

Product specificaties

Merk:	Planet
Categorie:	Niet gecategoriseerd
Model:	VGW-420FO
Kleur van het product:	Zwart
Gewicht:	853 g
Breedte:	242 mm
Diepte:	152 mm
Hoogte:	35 mm
Certificering:	CE, FCC
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
Temperatuur bij opslag:	-20 - 80 °C
Bedrijfstemperatuur (T-T):	0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
