1. Introduction

Thank you for purchasing PLANET H.265 Smart IR PoE IP Camera.

The “ICA-x80 series” is used as an alternative name in this Quick

Installation Guide. The following is the ICA-x80 series:

ICA-3280 H.265 1080p Smart IR Bullet IP Camera

ICA-4280 H.265 1080p Smart IR Dome IP Camera

ICA-A3280 H.265 1080p Smart IR Bullet IP Camera with

Articial Intelligence

ICA-A4280 H.265 1080p Smart IR Dome IP Camera with

Articial Intelligence

ICA-M3580P H.265 5 Mega-pixel Smart IR Bullet IP Camera

with Remote Focus and Zoom

ICA-M4580P H.265 5 Mega-pixel Smart IR Dome IP Camera

with Remote Focus and Zoom

2. Package Contents

Open the box of the ICA-x80 series and carefully unpack it. The

box should contain the following items:

zThe IP Camera x 1

zQuick Installation Guide x 1

zScrew Package x 1

zWaterproof Connector Package x 1

zDrill Template x 1

If any item is found missing or damaged, please contact your local

reseller for replacement.

3. Requirements

zWorkstations running Windows XP/2003/2008/Vista/7/8/10, MAC

OS X or later, Linux, UNIX, or other platforms are compatible

with TCP/IP protocols.

zWorkstations are installed with Ethernet NIC (Network Interface

Card).

zEthernet Port Connection

Network cables -- Use standard network (UTP) cables with

RJ45 connectors.

The above PC is installed with Web browser.

Note

It is recommended to use Internet Explorer 8.0

or above to access the ICA-x80 series. If the Web

interface of the ICA-x80 series is not accessible, please

turn off the anti-virus software or firewall and then try

it again.

4. Starting Web Management

The following shows how to start up the Web Management of the

ICA-x80 series. Note the ICA-x80 series is congured through an

Ethernet connection. Please make sure the manager PC must be

set to the same IP subnet address.

User PC

(192.168.0.X)

Ethernet Switch IP camera

Figure 4-1: IP Management Diagram

Note

1. The ICA-x80 series supports IEEE 802.3af; be

reminded to power either from AC to DC adapter or

802.3af PoE switch.

2. The AC to DC adapter is not included in the package.

For example, the ICA-x80 series default network type is DHCP

Client; to search the current IP address of the ICA-x80 series,

follow the procedure below:

1. Download the “PLANET Search Tools” utility from the following

PLANET website link: http://www.planet.com.tw/en/support/down

loads?method=keyword&keyword=PLANET+Search+Tools&view=

6#list

2. Install the “PLANET Search Tools” utility.

3. After the camera utility is launched, all cameras found in your

local area network will be displayed.

4. The existing ICA-x80 series in the local network.

5. Search the ICA-x80 series in the network.

6. Modify the IP parameters of the selected ICA-x80 series.

7. Select the ICA-x80 series you want to congure and double-click

on it.

8. You will be connected to the ICA-x80 series via web browser

automatically.

Figure 4-2: PLANET Search Tools Utility Screen

►

ICA-x80 series

H.265 Smart IR PoE IP Camera

– 5 – – 6 –

– 7 – – 8 –

Figure 5-1: Reset Button

Note

For ICA-3280 and ICA-4280 only.

Customer Support

Thank you for purchasing PLANET products. You can browse our

online FAQ resource and User’s Manual on PLANET Web site rst

to check if it could solve your issue. If you need more support

information, please contact PLANET support team.

PLANET online FAQs:

http://www.planet.com.tw/en/support/faq?method=category&c1=8

Support team mail address:

support@planet.com.tw

9. Without DHCP server, the ICA-x80 series default IP address

is 192.168.0.20, then the manager PC should be set to

192.168.0.x (where x is a number between 1 and 254, except

20), and the default subnet mask is 255.255.255.0.

Logging in to the ICA-x80 Series

When the following dialog box appears, please enter the default

user name and password . The login screen in Figure 4-3 “admin”

appears.

Default Username: admin

Default Password: admin

Figure 4-3: ICA-x80 series Web Login Screen

Note

The following web screen based on ICA-M4580P will

be the same as that of ICA-x80 series.

After entering the username and password, the main screen

appears as Figure 4-4 shows.

Figure 4-4: Web Main Screen of ICA-x80 series

Now, you can use the Web management interface to continue the

ICA-x80 series management.

Please refer to the user’s manual for more.

5. Recovering Back to Default

 Conguration

IP Address has been changed or admin password has

been forgotten –

To reset the network type to the default with IP “DHCP Client”

address “192.168.0.20” or reset the login password to default

value, press the hardware-based reset button for about 10

seconds. After the ICA-x80 series is rebooted, you can log in the

management Web interface within the factory default mode.

ICA-x80 Series User’s Manual:

https://www.planet.com.tw/en/support/downloads?&method=keywo

rd&keyword=ICA-x80+series&view=3#list

Android APP IOS APP

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy savings, please remove the power cable to disconnect the device from the power

circuit. Without removing the power cable, the device will still consume power from the power source. In view of Saving the Energy and reducing the unnecessary

power consumption, it is strongly suggested to remove the power cable from the device if this device is not intended to be active.

PLANET Technology Corp.

2011-AB8200-001

10F., No. 96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan

Wa i :rn ng

This device is compliant with Class A of CISPR 32.

In a residential environment this device may cause radio interference.

Product specificaties

Merk:	Planet
Categorie:	Bewakingscamera
Model:	ICA-M4580P
Kleur van het product:	Wit
Gewicht:	800 g
Soort:	IP-beveiligingscamera
Internationale veiligheidscode (IP):	IP67
Vormfactor:	Dome
Ondersteuning voor plaatsing:	Binnen & buiten
Connectiviteitstechnologie:	Bedraad en draadloos
Montagewijze:	Plafond
Diameter:	131 mm
Type stroombron:	DC, PoE
Nachtvisie:	Ja
LED-type:	IR
Type beeldsensor:	CMOS
Lengte:	93 mm
Temperatuur bij opslag:	-20 - 60 °C
Luchtvochtigheid bij opslag:	5 - 95 procent
Aantal lenzen:	1
Nachtkijker afstand:	30 m
Aantal effectieve pixels (H x V):	2616 x 1964 Pixels
Bedrijfstemperatuur (T-T):	-20 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
