Pagina 1/16
© Phoenix Gold • www.phoenixgold.com
Features
•Full range capable Class-D
Topology
•POWER SHIFT® ability for partial
power from front channels to be
redirected to rear channels for
active setups or system exibility
•Double tier power supplies
•Remote bass and phase
controller with BASS SHIFT®
(RBPC)
•Switchable balanced or
unbalanced inputs
Models: Ti3 1600.6 Ti3 1200.4 Ti1300.1
Amplifier
Manual
POWER
•Auto-turn on circuit (defeatable)
•Tri-light LED amplier status
indicators
•Short circuit, thermal and voltage
protection
•Front mount connections
•RMD ready – Remote monitoring
display port
(RMD sold separately)
Amplifier Owner’s Manual
© Phoenix Gold • www.phoenixgold.com
A Power Brand of AAMP Global.
15500 Lightwave Drive, Suite 202
Clearwater, Florida 33760
P: 866-788-4237
info@phoenixgold.com
www.phoenixgold.com
Designed and Engineered in the USA
Made in China
Phoenix Gold Product Warranty
LIMITED WARRANTY ON AMPLIFIERS
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) years from the original
date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer
in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or
malfunction, Phoenix Gold will (at its discretion) repair or replace the defective product with new or remanufactured product at no
charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse, product modication or neglect, failure
to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover incidental or
consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal
wear and tear is not covered under warranty.
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by
Phoenix Gold. Consumers needing service or warranty information for these products must contact that country’s reseller for information.
© Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
TI3 1600.6
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 6
1Ω: N/A
2Ω: 175W x 4 + 350W x 2
4Ω: 125W x 4 + 250W x 2
Number of Channels: 5
1Ω: N/A
2Ω: 175W x 4 + 700W x 1 @ 4Ω
4Ω: 125W x 4 + 700W x 1 @ 4Ω
POWER SHIFT® Active:
Number of Channels: 6
2Ω: 125W x 2 + 225W x 2 + 350W x 2
4Ω: 75W x 2 + 175W x 2 + 250W x 2
Number of Channels: 5
2Ω (1-4) / 4Ω (5+6): 125W x 2 + 225W x 2 + 700W x 1
4Ω (1-6): 75W x 2 + 175W x 2 + 700W x 1
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FLAT/HPF/LPF/BPF
55Hz - 4kHz @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : Yes
Low EQ 0-6dB boost: Yes
Input Selection: Balanced/ Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): -84dB
Frequency Response: 10Hz- 30kHz @ +/-1.0dB
Efciency (Average): 80%
Auto-Turn On: Yes
Damping Factor: Greater than 200
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 150A
Average Current Draw @ 14.4v Music: 58A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green - Over Voltage Warning
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions (L x W x H): 23.75” x 9” x 2”
SPECIFICATIONS
POWER
IMPORTANT: A power birth certicate is included for each amplier. Ti3 ampliers are
conservatively rated and will exceed their RMS power rating shown here.
All RMS power ratings and measurements are at 14.4 volts with no more than 1% THD.
2.0in / 51mm
RMD
POWER S HIFT
REMGND
Ti3 1600.6
INPUT CH
6 4 2 OFF ON
POWER SHI FT
ON
4
LINE INPUTS
6
5
18.62in / 600mm
9.0in / 229mm
2 4
BRIDGE BRIDGE BRIDGE
-
- -
1 3 -
5
- - 6-
23.75in / 603mm
