Lees hieronder de đź“– handleiding in het Nederlandse voor Phoenix Gold RX500.1 (16 pagina's) in de categorie Receiver. Deze handleiding was nuttig voor 62 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/16
© 2017 Phoenix Gold • www.phoenixgold.com
Features CaractĂ©ristiquesCaracterĂsticas:
• High and Low Pass Crossovers
• Audiophile BiPolar Output Transistors
• High Level Inputs for easy OEM Integration
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• RBC- Remote subwoofer level control included
(RX250.1, RX500.1, RX1100.1, RX600.5)
• Filtres croisés passe-haut et passe-bas
• Audiophile Transistors de Bipolaire
• Le Niveau Supérieur entre pour l’intégration de
fabricant d’origine facile
• Alimentation électrique robuste non
réglementée
• Technologie de composant monté en surface
• Terminaux d’alimentation et de haut-parleurs Ă
insertion directe
• Vérication du contrôle de la qualité de la
précision audio
• Couvercle de plexiglas résistant aux
températures élevées
• RBC- Niveau de contrôle de passe-bas inclus
(RX250.1, RX500.1, RX1100.1, RX600.5)
• High and Low Pass Crossovers
• Transistores de salida BiPolar Audiophile
• Entradas de alto nivel para fácil integración
OEM
• Robusta y no regulada Fuente de Poder
• TecnologĂa “Surface Mount Component”
• Conexiones directas de terminales de poder y
de parlantes
• Control de vericación de calidad de precisión
de audio
• Cubierta de Plexiglás resistente a altas
temperaturas
• RBC -Control de nivel de Subwoofer remoto
incluido (RX250.1, RX500.1, RX1100.1, RX600.5)
Models: RX250.1, RX500.1, RX1100.1, RX400.4, RX600.5
Amplifier
Manual
Manual del Amplificador
Manuel de l’amplificateur
Amplifier Owner’s Manual
© 2017 Phoenix Gold • www.phoenixgold.com
RX250.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX500.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX1100.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Efciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
IMPORTANT: A power birth certicate is included for each amplier. RX ampliers are
conservatively rated and will exceed their RMS power rating shown here. All RMS power
ratings and measurements are at 14.4 volts with no more than 1% THD.
RMS Power Output 150w x 1 @ 4 ohms
250w x 1 @ 2 ohms
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 20a
Dimensions (Includes Feet): 9.4” L x 8.4” W x 2.1” H
238mm L x 213mm W x 53mm H
RMS Power Output 300w x 1 @ 4 ohms
500w x 1 @ 2 ohms
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 40a
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
RMS Power Output 800w x 1 @ 2 ohms
1100w x 1 @ 1 ohm
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 80a
Dimensions (Includes Feet): 11.75” L x 8.4” W x 2.1” H
298mm L x 213mm W x 53mm H
SPECIFICATIONS
© 2017 Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
RX400.4 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Crossover Range: 40Hz to 400Hz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo
Typical Efciency: 50%
Damping Factor: Greater than 200
RX600.5 SPECIFICATIONS
FRONT AND REAR CHANNELS:
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Front/Rear High Pass Crossover Range: 15Hz to 250Hz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo
Typical Efciency: 55%
Damping Factor: Greater than 200
SUBWOOFER CHANNEL:
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 85%
Damping Factor: Greater than 200
RMS Power Output 75w x 4 @ 4 ohms Stereo
100w x 4 @ 2 ohms Stereo
200w x 2 @ 4 ohms Bridged
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 30a
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
RMS Power Output 60w x 4 @ 4 ohms Stereo
80w x 4 @ 2 ohms Stereo
160w x 2 @ 4 ohms Bridged
RMS Power Output 200w x 1 @ 4 ohms
300w x 1 @ 2 ohms
Recommend Power Wire Fuse: 60a
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
SPECIFICATIONS
