Phoenix Gold RX1100.1 Handleiding
Phoenix Gold
Receiver
RX1100.1
Lees hieronder de đź“– handleiding in het Nederlandse voor Phoenix Gold RX1100.1 (16 pagina's) in de categorie Receiver. Deze handleiding was nuttig voor 36 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/16
© 2017 Phoenix Gold • www.phoenixgold.com
Features CaractĂ©ristiquesCaracterĂsticas:
• High and Low Pass Crossovers
• Audiophile BiPolar Output Transistors
• High Level Inputs for easy OEM Integration
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• RBC- Remote subwoofer level control included
(RX250.1, RX500.1, RX1100.1, RX600.5)
• Filtres croisés passe-haut et passe-bas
• Audiophile Transistors de Bipolaire
• Le Niveau Supérieur entre pour l’intégration de
fabricant d’origine facile
• Alimentation électrique robuste non
réglementée
• Technologie de composant monté en surface
• Terminaux d’alimentation et de haut-parleurs Ă
insertion directe
• Vérication du contrôle de la qualité de la
précision audio
• Couvercle de plexiglas résistant aux
températures élevées
• RBC- Niveau de contrôle de passe-bas inclus
(RX250.1, RX500.1, RX1100.1, RX600.5)
• High and Low Pass Crossovers
• Transistores de salida BiPolar Audiophile
• Entradas de alto nivel para fácil integración
OEM
• Robusta y no regulada Fuente de Poder
• TecnologĂa “Surface Mount Component”
• Conexiones directas de terminales de poder y
de parlantes
• Control de vericación de calidad de precisión
de audio
• Cubierta de Plexiglás resistente a altas
temperaturas
• RBC -Control de nivel de Subwoofer remoto
incluido (RX250.1, RX500.1, RX1100.1, RX600.5)
Models: RX250.1, RX500.1, RX1100.1, RX400.4, RX600.5
Amplifier
Manual
Manual del Amplificador
Manuel de l’amplificateur
Amplifier Owner’s Manual
© 2017 Phoenix Gold • www.phoenixgold.com
RX250.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX500.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX1100.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Efciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
IMPORTANT: A power birth certicate is included for each amplier. RX ampliers are
conservatively rated and will exceed their RMS power rating shown here. All RMS power
ratings and measurements are at 14.4 volts with no more than 1% THD.
RMS Power Output 150w x 1 @ 4 ohms
250w x 1 @ 2 ohms
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 20a
Dimensions (Includes Feet): 9.4” L x 8.4” W x 2.1” H
238mm L x 213mm W x 53mm H
RMS Power Output 300w x 1 @ 4 ohms
500w x 1 @ 2 ohms
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 40a
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
RMS Power Output 800w x 1 @ 2 ohms
1100w x 1 @ 1 ohm
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 80a
Dimensions (Includes Feet): 11.75” L x 8.4” W x 2.1” H
298mm L x 213mm W x 53mm H
SPECIFICATIONS
© 2017 Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
RX400.4 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Crossover Range: 40Hz to 400Hz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo
Typical Efciency: 50%
Damping Factor: Greater than 200
RX600.5 SPECIFICATIONS
FRONT AND REAR CHANNELS:
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Front/Rear High Pass Crossover Range: 15Hz to 250Hz
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo
Typical Efciency: 55%
Damping Factor: Greater than 200
SUBWOOFER CHANNEL:
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 85%
Damping Factor: Greater than 200
RMS Power Output 75w x 4 @ 4 ohms Stereo
100w x 4 @ 2 ohms Stereo
200w x 2 @ 4 ohms Bridged
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 30a
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
RMS Power Output 60w x 4 @ 4 ohms Stereo
80w x 4 @ 2 ohms Stereo
160w x 2 @ 4 ohms Bridged
RMS Power Output 200w x 1 @ 4 ohms
300w x 1 @ 2 ohms
Recommend Power Wire Fuse: 60a
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
SPECIFICATIONS
