Start with Internet Recovery

This guide provides the information required to format your OWC SSD, as well as options for installing the Mac operating system and

migrating your data. The process starts by booting into Internet Recovery, using one of the keyboard shortcuts listed below. Because the

shortcut used and the speciﬁc Mac determine the OS used by Recovery it is worthwhile to determine the latest compatible OS for your

Mac before choosing a method. We have included Apple’s oﬃcial compatibility lists for the last several OS versions (see below).

Recovery Option 1: Cmd-Opt-R (Recommended)

Power on the Mac then immediately press and hold Cmd-

Opt-R until you see a screen similar to the one at right (in

some cases it may be grey). If you see a Wi-Fi menu, choose

your preferred network to continue; you may need to provide

network credentials.

This Recovery option ensures that later in the process, if you use

the ‘Reinstall macOS’ function (i.e. a clean OS install) the latest

compatible version will be used.

Recovery Option 2: Cmd-R

Power on the Mac then immediately press and hold Cmd-R

until you see a screen similar to the one shown above (in

some cases it may be grey). If you see a Wi-Fi menu, choose

your preferred network to continue; you may need to provide

network credentials.

This option ensures that if you use the ‘Reinstall macOS’ function (i.e. a clean install) later, the most recently installed OS version will be used.

Exception: If you recently had your Mac logic board replaced during a repair, Recovery might instead oﬀer the latest compatible OS.

Additional Notes:

• If you want to verify the OS version that you booted into before you go further, you can use the Terminal. From the main menu at

the top of the Recovery screen, choose Utilities > Terminal, then type the command sw_vers and press Return. The OS version that

you have booted into will be displayed. If it’s the version you expected based on the information provided earlier, you can continue.

• If not, you can try again by choosing Apple Menu > Restart, waiting till the screen turns black and then pressing and holding a

diﬀerent Recovery shortcut, to see if you get the result you want. If you do not it is possible the version of the OS you are looking for

is no longer available for your speciﬁc Mac.

Formatting, OS Installation, and Migration Guide

OWC Aura Pro X2 SSD

Important Notes

• This process requires a working internet connection on the host computer.

• This guide assumes that the was already followed and completed. SSD installation process

• IMPORTANT: macOS 10.13 High Sierra (or later OS) must be installed on the host computer BEFORE installing this SSD

for the rst time. These OS versions include an EFI ﬁrmware update for your Mac. Without the update, the computer will not

recognize the SSD. This process is separate from and should precede the other processes described here. Note that when

installing the OS onto the drive itself (later in this document), macOS 10.13 or later is also required.

• If the SSD is installed on a laptop, make sure the power adapter is connected before you begin the steps below.

• • • macOS 10.15 Catalina-compatible macOS 10.14 Mojave-compatible macOS 10.13 High Sierra-compatible

Formatting the SSD

Once you have booted into Recovery, use the built-in Disk Utility to format the SSD. Please note: the drive labels or information shown in

one or more sections of this document may diﬀer from what you see, but the overall processes won’t change.

• If you need to start from the beginning, please continue with the Disk Utility process below.

• If you have already formatted the drive and are ready to review OS and data migration options, skip to page 5.

Formatting Steps: 10.13-10.15

Step 1 – from the macOS Utilities window, select the Disk Utility option and click Continue.

Step 2 – to ensure that all internal devices and volumes are shown from the start, open the View menu widget near the top-left corner of

the Disk Utility window and choose ‘Show All Devices’.

Step 3 – in the sidebar area at left, select the icon or label for the physical disk (item A below) Note: some SSDs may also include a factory-

formatted volume, listed beneath the physical disk item; this factory volume — or any others on the drive — will be permanently erased.

Step 4 – click the ‘Erase’ button (item B below) to continue.

Step 5 – a sheet will open containing the settings needed to format the drive. From the ‘Scheme’ menu (item A below) set the value to

‘GUID Partition Map’ if it’s not already selected (required).

Step 6 – from the ‘Format’ menu (item B below) choose ‘APFS’. This is the recommended format for Mac SSDs for 10.13 and later.

Step 7 – type a name for your new system volume in the ﬁeld supplied (item C). the volume names shown in later sections will not Note:

match the one shown here because the examples are from diﬀerent sources. However, whatever volume name you choose at this step,

will be applicable when choosing a destination for your system and/or data ﬁles during the migration process, as well.

Step 8 – click the ‘Erase’ button (item D) to format the drive. In many cases it will only take a few seconds.

During the format process, by default the screen will look similar to what you see below. Note that it is possible to see the details of the

formatting process by clicking the ‘Show Details’ widget (item A), but it is not necessary to complete the process.

Product specificaties

Merk:	OWC
Categorie:	Solid state drives (ssd)
Model:	Aura Pro X2
Gewicht:	8 g
Breedte:	22 mm
Diepte:	89 mm
Hoogte:	2.6 mm
Meegeleverde kabels:	USB
Interface:	PCI Express 3.1
Duurzaamheidscertificaten:	RoHS
Temperatuur bij opslag:	-40 - 85 °C
Ondersteunt Mac-besturingssysteem:	Mac OS X 10.13 High Sierra
SSD capaciteit:	480 GB
ECC:	Ja
SSD-vormfactor:	M.2
Mean time between failures (MTBF):	1500000 uur
Type geheugen:	3D TLC
Leessnelheid:	3282 MB/s
Schrijfsnelheid:	2432 MB/s
Component voor:	Notebook
Schokbestendigheid (buiten gebruik):	1500 G
Bedrijfstemperatuur (T-T):	0 - 70 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Code geharmoniseerd systeem (HS):	84717070
Hardware encryptie:	Ja
S.M.A.R.T. support:	Ja
NVMe:	Ja
NVMe versie:	1.3
TRIM support:	Ja
Stroomverbruik (lezen):	5.7 W
Stroomverbruik (schrijven):	5.7 W
NCQ (Native command queuing):	Ja
Optische drivecontroller:	SMI SM2262
Stroomverbruik (idle):	0.3 W
PCI Express interface data lanes:	x4
TBW-classificatie:	225
Externe opslag drivebehuizing:	Ja
