Pagina 1/8
When contacting a OTSEIN or one of its Technical Assistance
Centre always refer to the model (see control panel) and the
registration and series numbers which are indicated at the bottom of
the machine under the lower panel or on the warranty certificate. That
is to say, everything that appears in the box.
Providing this information will ensure a faster and more efficient service.
36 37
INTRODUCTION
Read this manual carefully as it offers practical advice to help you get the most from your
washing machine.
This Instruction Manual
contains everything you need to
know about the everyday
running of your machine. Keep
it for future reference.
An Installation and
Maintenance Manual is also
provided which you should
consult during the installation
and routine maintenance of
your washing machine. The ma-
nual also contains information
about possible working
problems, advice about the
wash load, an explanation of
label symbols and hints about
how to remove stubborn stains.
1.- CONTROL PANEL
2.- LID
3.- DRUM
4.- DETERGENT COMPARTMENT
5.- FILTER DOOR
6.- FILTER
7.- WHEEL TROLLEY
INDEX
TECHNICAL DATA .......................................................................
38
OPENING THE LID – LOADING ................................................
39
DETERGENT DISPENSER ........................................................
40
SAFETY AQUABLOCK................................................................
41
VARIABLE CAPACITY .................................................................
41
PROGRAMME SELECTION .......................................................
41
CONTROL DESCRIPTION
- LTO 86 B ................................................
42
- LTO 106 A - 126 A ...................................
45
TABLE OF PROGRAMMES
- LTO 86 B ................................................
48
- LTO 106 A - 126 A ...................................
50
page
EN
38 39
TECHNICAL DATA
Load capacity ..................................................
kg.
Voltage ...............................................................
V.
Wash motor power rating ..................................
W.
Spin motor power rating ....................................
W.
Electropump power rating .................................
W.
Heating element power rating ...........................
W.
Max. power input ...............................................
W.
Fuse ..................................................................
A.
Water pressure ..............................................
MPa
Spin speed ........................................
r.p.m./min
Water consumption (60º C programme)............
lit.
Energy consumption (60º C programme).....
kWh
Energy efficiency rating ..........................................
4,5
230
125
340
30
1.850
2.200
10
0,05 min.
0,8 max.
1200
59
0,85
A
LTO 126 A
4,5
230
175
300
30
1.850
2.200
10
0,05 min.
0,8 max.
800
69
1,03
B
4,5
230
175
400
30
1.850
2.200
10
0,05 min.
0,8 max.
1000
59
0,85
A
LTO 86 B LTO 106 A
OPENING THE DRUM
1.
Lift the lid and open completely. Next open the drum(A)
door following these instructions:
2.
Press catch and kept it pressed down.(B)
Press the first shutter to unlock the two shutters (C) (C)
and .(D)
3.
Open the second shutter . Open the first shutter (D) (C).
Place the washing in the drum.
4.
Close the first shutter (C).
Close the second shutter so that the catch on the first(D)
shutter fits correctly into the slot. Release.
5.
Ensure that both shutters are perfectly aligned and properly
closed.
IMPORTANT: IT IS IMPORTANT TO MAKE SURE THAT
THE DRUM IS CAREFULLY CLOSED BEFORE
OPERATING THE MACHINE, OTHERWISE THE MACHINE
OR LAUNDRY COULD GET DAMAGED.
2 min. IMPORTANT: A SPECIAL
SAFETY DEVICE PREVENTS
THE LID FROM BEING
OPENED IMMEDIATELY
AFTER THE WASH HAS
FINISHED. ONCE THE SPIN
CYCLE HAS FINISHED, WAIT
FOR 2 MINUTES BEFORE
TRYING TO OPEN THE LID.
FRONT OF THE
WASHING
MACHINE
D
C
FRONT OF THE
WASHING
MACHINE
D
C
FRONT OF THE
WASHING
MACHINE
C
B
D
WASHING
MACHINE LID
A
FRONT OF THE
WASHING
MACHINE
C
D
III
MAX.
MAX.
MAX.
40 41
DETERGENT DISPENSER
The detergent dispenser is divided into 4 compartments:
• Compartment I, is for prewash powder detergent. The recommended quantity is 60
gm of detergent (for 4,5 kg of laundry).
• Compartment II, is for wash powder detergent. The recommended quantity is 120
gm of detergent (for 4,5 kg of laundry).
• The compartment is for bleach. The recommended quantity is 70 c.c.
• The compartment is for fabric conditioners, scenting agents and special
additives. The recommended quantity is 50 c.c.
The detergent compartment has two guidance lines:
• RECOMMENDED (lower line). This indicates the recommended level for the prewash
and wash compartments.
• MAX. should never be exceeded. This indicates the maximum level which
MAXIMUM
(wash)
MAXIMUM
(bleach and scenting agent)
MAXIMUM
(prewash)
RECOMMENDED
VARIABLE CAPACITY
This washing machine automatically adapts the water level to the type and quantity of clothes
to be washed. So it is possible to obtain a «customised» wash, even in terms of energy. This
system reduces water and energy consumption and provides an appreciable reduction in
wash time.
PROGRAMME SELECTION
WHEN SELECTING A PROGRAMME, ENSURE THAT THE START/STOP BUTTON IS NOT
ACTIVATED.
To select a programme:
• Programmes are selected by means of the corresponding control knob (A). See the
table of programmes.
• Select the wash temperature by means of the corresponding control knob.
• Select the spin speed by means of the corresponding control knob.
• Select the different options available by pressing the corresponding buttons.
SAFETY AQUABLOCK
(Mod. LTO 126 A)
This appliance is fitted with a safety system , which ensures(aquablock)
maximum freedom from anxiety for users. A water leak detector sensor
located along the inlet pipe and the devoce fitted to the tap, automatically
block the flow of water in the case of accidental leaks. Even without
electricity supply.
